Summary of Contents for Lauda UWT Series
- Page 3 Operating instructions UWT circulation heat exchangers UWT 3000, UWT 6000, UWT 10000 LAUDA DR. R. WOBSER GMBH & CO. KG YAWE0029 Pfarrstraße 41/43 English 97922 Lauda-Königshofen Translation of the original operating instructions Germany Read the instructions prior to performing any task!
-
Page 5: Prefixed Safety Information
UWT circulation heat exchangers Prefixed safety information Before operating the equipment please read carefully all the instructions and safety notes. If you have any questions please phone us! Follow the instructions on setting up, operation etc. This is the only way to avoid incor- rect operation of the equipment and to ensure full warranty protection. -
Page 6: Table Of Contents
UWT circulation heat exchangers Contents Prefixed safety information ........................... 3 Contents ................................ 4 Safety notes ..............................5 General safety notes ..........................5 Other safety notes ............................. 6 Operating and functional controls ........................7 Unit description ..............................9 Environmental conditions .......................... 9 Unit types .............................. -
Page 7: Safety Notes
UWT circulation heat exchangers Safety notes General safety notes A circulation heat exchanger is used to cool and circulate heat transfer liquids as specified. This leads to hazards due to the emission of heat transfer liquid and / or of cooling liquid and to general hazards due to the use of electrical energy. -
Page 8: Other Safety Notes
UWT circulation heat exchangers Other safety notes Connect the unit only to grounded mains power (PE). Use suitable hoses. Protect tubing with hose clips against slipping off. Prevent kinking of tubing! Check tubing from time to time for possible material defects! ... -
Page 9: Operating And Functional Controls
UWT circulation heat exchangers Operating and functional controls Front of UWT 3000 Filling nozzle for heat transfer liquid Controller with temperature display and operating keys Mains switch with indicating lamp Light-emitting diodes: K 1: Lights when cooling water valve "open" K 2: Lights for overtemperature Red warning lamp for overtemperature Yellow warning lamp for low level... - Page 10 UWT circulation heat exchangers Back of UWT 3000 Mains cable Primary circuit (external) - inlet of coolant Primary circuit (external) - return flow of coolant Laboratory circuit - return pipe for load Laboratory circuit - return pipe for load Remote socket 15N with alarm outputs and remote switch-on Rating label Drain tap...
-
Page 11: Unit Description
UWT circulation heat exchangers Unit description Environmental conditions The operation of the thermostats is only allowed under the following conditions as specified in EN 61010-2-010:2003 and EN 61010-1:2001: Indoor use. Altitude up to 2000 m above sea level. ... -
Page 12: Temperature Display, Controller And Safety Devices
UWT circulation heat exchangers Temperature display, controller and safety devices The circulation heat exchanger can be switched on and off externally via contacts on the signal connect- or 15N. The units are equipped with a two-state controller on which the set-point temperature of the bath circuit can be set. -
Page 13: Unpacking
After unpacking, first check the unit and accessories for any transport damage. If contrary to expectations the unit is found to be damaged, the shipping company must be immediately in- formed so that verification can take place. Please also inform the LAUDA Service Constant Temperature Equipment (Contact 7.3). -
Page 14: Preparations
UWT circulation heat exchangers Preparations Siting and connection Site the unit on a level surface. The unit must not be put into operation if its temperature due to storage or transport has been reduced below the dew point. Wait approx. 1 hour. For operation, contacts 1 and 3 on the remote socket 15N must be joined. -
Page 15: Filling
UWT circulation heat exchangers Filling The circulation heat exchangers in the primary and laboratory circuits are designed for operation with water or a glycol/water mixture. Close the drain tap (located right at the bottom on the back panel). ... -
Page 16: Draining / Frost Protection
UWT circulation heat exchangers Draining / frost protection If the unit is to be taken out of operation for a longer period of time or if ambient temperatures below 0 °C are to be expected, the unit must be drained. This must be carried out in two steps: Draining the cooling liquid circuit: ... -
Page 17: Starting Up
UWT circulation heat exchangers Starting up Mains connection Compare the details on the rating label (back of the unit) with the mains voltage. Only connect units to sockets having a safety earth conductor (PE). No liability is accepted for incorrect mains connection. ... -
Page 18: Adjusting The Outflow Pressure With The Bypass Valve
UWT circulation heat exchangers Setting the switching threshold for overtemperature: Factory setting is 25 °C. Setting in the complete temperature range of the unit is possible. The setting takes place at the configuration level. Programming (setting) of the operating parameters is possible at the configuration level. -
Page 19: Maintenance
Withdraw the mains plug before all servicing and repair work! Have repairs in the control section carried out only by specialists! LAUDA circulation heat exchangers need practically no servicing. If the temperature stabilising liquid in the laboratory circuit becomes contaminated, it should be renewed. -
Page 20: Spare Parts Ordering And Rating Label
Telephone: +49 (0)9343 503-350 (English and German) Fax: +49 (0)9343 503-283 E-Mail service@lauda.de We are available any time for your queries, suggestions and criticism! LAUDA DR. R. WOBSER GMBH & CO. KG Pfarrstraße 41/43 97922 Lauda-Königshofen Germany Telephone: +49 (0)9343 503-0... -
Page 21: Technical Data And Circuit Diagram
UWT circulation heat exchangers Technical data and circuit diagram Technical data The figures were determined according to DIN 12876. UWT 10000 UWT 3000 UWT 6000 UWT 10000 with stronger pump 5 – 40 Ambient temperature range °C G ¾ with hose Primary circuit and laboratory olive for ¾... -
Page 22: Eu Conformity
The device complies with the basic health and safety requirements outline in the Directives listed below. Machinery Directive 2006/42/EC EMC Directive 2014/30/EU LAUDA DR. R. WOBSER GMBH & CO. KG – Pfarrstraße 41/43 – 97922 Lauda-Königshofen – Germany The device does not fall under Pressure Equipment Directive 2014/68/EU because the device is only classified as high as Category 1 and is covered by the Machinery Directive. -
Page 23: List Of Components With Circuit Diagram
UWT circulation heat exchangers List of components with circuit diagram Best.-Nr. Best.-Nr. Best.-Nr. Teil-Nr. Cat. No Cat. No Cat. No Part No. Bezeichnung Designation Désignation N° Réf. N° Réf. N° Réf. Piéce no. UWT 3000 UWT 6000 UWT 10000 Leiterplatte Printed circuit board Circuit imprimé... - Page 24 UWT circulation heat exchangers Technical data and circuit diagram YAWE0029 / 29 June 2018...
- Page 25 / Personne responsable Hiermit bestätigen wir, daß nachfolgend aufgeführtes LAUDA-Gerät (Daten vom Typenschild): We herewith confirm that the following LAUDA-equipment (see label): Par la présente nous confirmons que l’appareil LAUDA (voir plaque signalétique): Serien-Nr. Type / Type Serial no. / No. de série:...
- Page 28 LAUDA DR. R. WOBSER GMBH & CO. KG P.O. Box 12 51 · 97912 Lauda-Koenigshofen · Germany Phone: +49 9343 503-0 · Fax: +49 9343 503-222 E-mail: info@lauda.de · Internet: www.lauda.de...
