GPS HEAD UP DISPLAY
INSTRUCTION MANUAL
PLU: 621741

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 621741 and is the answer not in the manual?

Questions and answers

richard
February 26, 2025

how do I get into window 6

0
1 comments:
Mr. Anderson
May 14, 2025

To access window 6 (menu settings) on SCA part number 621741:

1. Perform a vertical long press (press the wave button inward) for 5 seconds to enter the menu settings.
2. Use a short inward press to move through the menu options until you reach window 6.
3. Use up or down movements on the wave button to adjust values.
4. After making adjustments, perform another vertical long press for 5 seconds to save and exit.

This answer is automatically generated

0

Summary of Contents for SCA 621741

  • Page 1 GPS HEAD UP DISPLAY INSTRUCTION MANUAL PLU: 621741...
  • Page 2 PLEASE READ BEFORE FIRST USE This system has been designed for simple DIY installation and can be installed into any vehicle with a 12V electrical system, by plugging into the vehicles accessory sockets. This Head Up Display (HUD) uses GPS signals to calculate the vehicle speed, therefore it WILL NOT WORK inside buildings, underground car parks or tunnels where a GPS signal is unavailable.

  • Page 3: Carton Contents

    • Cloudy and overcast conditions • Heavy rain / snow • Driving amongst high rise buildings / dense city areas • Operating HUD within areas of strong electrical interference (such as telecommunication towers / airports etc). Vehicle type and wheel sizes can also cause variations in the display speed vs the vehicle speedometer.
  • Page 4 SETUP AND OPERATION INSTRUCTIONS • Ensure dash surface and inside the windscreen are clean and free from any residue before installation. This includes plastic and upholstery "protectants", as these may react with the supplied sticky pad. PLEASE DO NOT USE ANY CLEANING CHEMICALS ON THE HUD UNIT.

  • Page 5: Display And Features

    DISPLAY AND FEATURES 1: Buzzer icon 2: Settings icon 3: Driving direction icon: West, North, East, South 4: Satellite signal icon - Light flashes from red (searching) to green (connected) to satellite 5: Speed 6: Light-sensor 7: Speed unit (KM/H or MPH)
  • Page 6 WAVE BUTTON FUNCTION 1. Vertical long press in for 5 seconds, enters into setting menu (menu 1-6). After finishing adjustment, vertical long press for 5 seconds to save and exit. 2. Short pull up: Increasing parameter values after entering into the menu settings.

  • Page 7: Menu Settings

    MENU SETTINGS Vertical long press in the wave button for 5 seconds to enter into the menu settings. Short press in the wave button to increase the menu value, up or down the wave button to increase/decrease parameter value. After adjustment, vertical long press 5 seconds to save and exit.
  • Page 8 MENU 3: BRIGHTNESS -Range adjustment: 0-5 -0 for automatic brightness adjustment -1 is darkest -2-5 is bright (the greater the number, the stronger the brightness -Default value: 0 MENU 4: SPEED UNIT -0 for KM/H -1 for MPH MENU 5: POWER ON/OFF VOLTAGE -Range adjustment: 100-150 Eg: Value 100 means 10.0V,...
  • Page 9 MENU 6: DISPLAY MODE -Range adjustment: 0-1 -0 is reflect on the windshield -1 is direct view -Default value: 0 POSITIONING THE REFLECTION FILM The HUD projects dashboard information on the vehicles front windscreen. Due to most vehicles windscreen being double layered, this may cause the user to see a double or blurred image.

  • Page 10: Troubleshooting Guide

    TROUBLE SHOOTING GUIDE Under normal operating conditions, if there are problems with the device, please refer to the following methods to resolve them. Problem: The HUD will not power on Solution: • Vehicle Accessory Socket - Check the vehicle accessory socket has power, simply plug another device and see if it powers up (or use a test light / multimeter to check for power).
  • Page 11 HUD SPECIFICATIONS Working voltage DC8-18V Working current 40mA Sleeping current 15mA Compass precision ±1° Speed range 0-400KM Satellite positioning time Cold start: 30s Hot start: 1s HUD size 90x54x12mm 12V car charger 1000mA HUD weight...

  • Page 12: Warranty

    WARRANTY Our product is guaranteed to be free from quality and manufacturing defects for a period of 12 months. If your product becomes defective during this period, SRGS PTY LTD will offer you either a replacement, credit or refund where a product is faulty;...
