Summary of Contents for M. Bartels SA-3
- Page 1 Operation Manual Shoe Attachment for SA-3...
- Page 3 CONTENTS TO EXCHANGE THE SLIDE BLOCK ......3 HOW TO PUT ON THE SHOE ATTACHMENTS (FOR STANDARD WHEELCHAIR) .
- Page 4 1. How to exchange the Slide Block 1. take the Spring Pin Ø 4 from both the Slide Airms. Remove the Stopper from Take off the Spring Pin 4 the end of Slide Arms on from both Slide Arm. both side. 2.
- Page 5 2. How to put on the Shoe Attachment (for normal width wheelchair) 1. Tools Spanner 13mm (open-end type is better) 2 pcs. Spanner 17mm (open-end type is better) 1 pc. (Adjustable wrenches 24mm over is also OK) Hexagon Socket Screw Keys 6mm 1pc (standard accessary) Get loose the red screw to withdraw and use Hexagon Socket Screw.
- Page 6 3. Put on the Shoe Attachment as shown in following. Take off the square cap. Push the Shoe Attachment until this point comes to end. 4. Bolt with Double Nuts Follow the procedure 4.1.- 4.4. 4.1. Get tighten the Bolt by Hexagon Socket Screw 6mm.
- Page 7 Installation of the Shoe Attachments is completed. (for normal width wheelchair) 3. How to put on the Shoe Attachment (for wider width wheelchair) *additional 40mm x both side = totally 80mm wider 1. Tools Spanner 13mm (Open-end type is better) 2pcs. Spanner 17mm (Open-end type is better) 1pc.
- Page 8 3. How to put the Extension Bolt on. the Extension Bolt & the Spring Washer 16mm Get the Extension Bolt by spanner 24mm. Slide in the Shoe Attachment until it touches the Extention Pipe. 4. Bolt with Double Nuts Follow the procedure 4.1. - 4.4. 4.1 Get tighten the Bolt by Hexagon Socket Screw 6mm.
- Page 9 5. Bolt with plane washer and Nord-Lock washer. Put plane washer and Nord-Lock washer to make the surface show- ing bigger wedge pitch on the Nord-Lock meet to the Bolt. Get the Bolt tighten by the Hexa- gon Socket Screw 6mm. Installation of the Shoe Attachments is completed.
- Page 10 5. How to set wheelchair on the Shoe Attachment 1. Confi rm that SA-3 is on fl at surface. 2. Tilt the Handle of SA-3 up as shown in the picture and then, confi rm whether the Handle keeps its position without any support.
- Page 11 3. Put wheelchair on the Shoe Attachment ensuring wheelchair in center. At this mo- ment, confi rm that the wheels are touch the Adjustable Stopper. And confi rm that wheelchair‘s brake works. 4. Confi rm whether the Forks are touch the frame of wheelchair and tighten the Knob on left and right side.
- Page 12 NOTES NOTES...
- Page 13 NOTES NOTES...
- Page 14 6. DEALER Austria/Czech Germany Latvia Lehner Lifttechnik GmbH S alling 8 Perfekta-Lift GmbH E levet SIA 4724 Neukirchen am Walde Glehner Heide 1 Vestienas street 20 P hone: +43 7278 3514 41352 Korschenbroich LV 1035 Riga F ax: +43 7278 3514-12 P hone: +49 2182 886060 Phone: +371 25708022 office@lehnerlifttechnik.at F ax: +49 2182 8860610 Fax: +371 67574023 www.lehner-lifttechnik.at ...
- Page 15 Slovenia JR Product d.o.o. S tegne 7 1000 Ljubljana Phone: +386 1511 4482 F ax: +386 1511 4483 info@jr-product.si www.jr-product.si Spain Stannah Incisa S.L.U. c/ Eduard Marquina 26 08911 Badalona Phone: +34 93 4646770 F ax: +34 93 3891534 otecnica@stannah.es www.stannah.es Spain Enier Av. De Franca 205 17840 Sarrià de Ter Phone: +34 972 171374 Fax: +34 972 170678 enier@enier.com w ww.enier.com Switzerland ...
- Page 16 M. BARTELS Reha Im - & Export GmbH Fangdieckstr. 68 22547 Hamburg Tel. +49 (0) 40 | 54 75 33 33 m.bartels@reha-europe.com www.reha-europe.com Presented by:...
