FIFE GUIDING SOLUTIONS

H3257 LED Light Source

User Manual

MI 1-921 1

Table of Contents

Need help?

Do you have a question about the H3257 and is the answer not in the manual?

Questions and answers

Summary of Contents for Maxcess H3257

Page 1 FIFE GUIDING SOLUTIONS H3257 LED Light Source User Manual MI 1-921 1...
Page 2: Table Of Contents
Sensor gap ......................4-1 Adjusting the light intensity ................. 4-2 Adjustment button ..................4-2 LED bar graph ....................4-2 DC light mode ...................... 4-3 Dual H3257 synchronization ................4-3 TROUBLESHOOTING MAINTENANCE Lens ........................5-1 Spare parts ......................5-1 Replacing a fuse ....................5-1...
Page 3: Introduction
All of the information herein is the exclusive proprietary property of Maxcess International, and is disclosed with the understanding that it will be retained in confidence and will neither be duplicated nor copied in whole or in part nor be used for any purpose other than for which disclosed.
Page 4 The H3275 LED Light Source is used as a backlight for an optical sensor or camera in a web or strip guiding system. The H3257 provides uniform LED light output through a diffusing lens, which is captured by a sensor or camera to provide information about the material position.
Page 5 Only persons who are acquainted with the installation, commissioning, operation, and maintenance of the system and who possess the necessary qualifications for their activities may work on the H3257. Note: The safety information may not be comprehensive. Please note the following: The content of these operating instructions ...
Page 6 DANGER – Danger due to voltage, electric shock Reference to danger of injury caused by electric shock due to voltage. WARNING – Danger due to cutting Reference to danger of injury caused by sharp edges Reference to important information www.maxcessintl.com Fife H3257 MI 1-921 1...
Page 7: Hazards
SAFETY Basic safety information Proper use The H3257 is intended to be installed indoors in proximity to a moving web or strip for the purpose of guiding the web material. Improper use Operation outside the technical specifications Operation in an Ex-area or intrinsically safe area...
Page 8 Damage to the equipment caused by failure to do so may void the product warranty. Decommissioning The H3257 must be disposed of in accordance with all the applicable national, state and local regulations. www.maxcessintl.com Fife H3257...
Page 9: Installation
Diffused LED Light Source 47" [46.96] [20.00] [3.48] 2336.8 990.6 177.8 290001197 Diffused LED Light Source 92" [92.00] [39.00] [7.00] Table 1. H3257 Part numbers and dimensions * E indicates number of mounting holes www.maxcessintl.com Fife H3257 MI 1-921 1...
Page 10: Power Supply, +24V
Ground to building ground bonding system per N.E.C. or local codes. Alternate power supply If using a different power supply, connect the H3257 using a See Table 2. 5-pin M12 female-to-flying-lead cable. You will need to determine how devices in your system will respond to the status signal.
Page 11: Components And Cable Connections
Install synchronization cable for dual light source 29LH6610-M4M-xS Use for connecting to power supply or another H3257. One DC mode plug is required for each H3257 LED Light Source Cable part numbers: x= length in meters Figure 2. Components and cable connections.
Page 12: Using The H3109 Discriminating Detector
Using the H3109 Discriminating Detector There are special considerations when the H3257 is used as a light source for the H3109 sensor. 1. Always set the H3257 to intensity 8 (default). 2. Always set the H3257 to operate in pulsed mode (default).
Page 13: Operation
OPERATION Operation LED intensity settings The H3257 functions as a stand-alone light source using factory calibrated light intensity/profile settings. Factory calibration sets the drive level of each LED to the See Table 3. same value for each of eight profile settings.
Page 14: Adjusting The Light Intensity
OPERATION Adjusting the light intensity The H3257 must be powered on to change the intensity. The device will retain the selected intensity level between power cycles. Adjustment button Adjust the intensity level with a small pushbutton located behind a hole plug on the front panel.
Page 15: Dc Light Mode
Enabling DC light mode By default, the light emitted from the H3257 is pulsed at 7.5 kHz. When the H3257 is used as a light source for line scan or array cameras, use DC light mode. To configure the H3257 for DC light mode, the DC Mode Plug...
Page 16: Troubleshooting
Damaged or broken lens H3257 faults and status contact The H3257 provides a contact closure in series with the 5- pin power connectors to indicate an internal fault to other devices in the system. The contact is closed during normal error-free operation.
Page 17: Spare Parts
In some environments, dust and dirt will build up on the lens of the H3257, reducing its effective light output. Daily Wipe the lens of the H3257 with a clean, damp, soft cloth. Use ordinary soap and warm water. Do not use abrasive materials or chemicals on the lens.
Page 18: Specifications
-20 to 50 °C (-4 to 122 °F) Lens material Polycarbonate Status output Contact closure indicates normal operation Connectors Two (2) for power One (1) for synchronizing two light sources Fuse 4A slow-blow (Littelfuse Inc / 0454004.MR) www.maxcessintl.com Fife H3257 MI 1-921 1...
Page 19: Service
Maxcess 222 West Memorial Rd. Oklahoma City, OK, 73114, USA Phone: +1.405.755.1600 Fax: +1.405.755.8425 Web: www.maxcessintl.com Fife-Tidland GmbH Max-Planck-Strasse 8 65779 Kelkheim Deutschland Telefon: +49.6195.7002.0 Fax: +49.6195.7002.933 Web: www.maxcess.eu www.maxcessintl.com Fife H3257 MI 1-921 1...
Page 20 AND AFRICA AND SE ASIA Tel +86.756.881.9398 Tel +91.22.27602633 Tel +81.43.421.1622 Tel +1.405.755.1600 Tel +49.6195.7002.0 Fax +86.756.881.9393 Fax +91.22.27602634 Fax +81.43.421.2895 asia@maxcessintl.com Fax +1.405.755.8425 Fax +49.6195.7002.933 info@maxcessintl.com.cn india@maxcessintl.com japan@maxcessintl.com www.maxcess.asia sales@maxcessintl.com sales@maxcess.eu www.maxcessintl.com.cn www.maxcess.in www.maxcess.jp www.maxcessintl.com www.maxcess.eu © 2015 Maxcess...
