Summary of Contents for BAB TECHNOLOGIE FLATTOUCH 101
- Page 1 < BAB TECHNOLOGIE GmbH FLATTOUCH Installation Manual Type 10.1“, 15,6“, 18,5” and 21.0“ Article Nr.: 04651s, 04655s, 04659s, 4661s Version I Stand 04/2022 Datum: 27. April 2022...
- Page 2 Table of contents Installation Manual BAB TECHNOLOGIE GmbH Hörder Burgstraße 18 44263 Dortmund info@bab-tec.de Tel.: +49 (0) 231 – 476 425 - 30 Fax.: +49 (0) 231 – 476 425 - 59 www.bab-tec.de BAB TECHNOLOGIE FLATTOUCH...
-
Page 3: Table Of Contents
Connect the FLATTOUCH......................9 Switch On – Off FLATTOUCH ..................... 10 Appendix ............................11 Article numbers and Identifiers ....................11 Dimensions ..........................11 ABLE OF IGURE < ......................................1 Figure 1 FLATTOUCH ................................4 Figure 2 Connections of the FLATTOUCH (15.6”) ......................9 FLATTOUCH BAB TECHNOLOGIE... -
Page 4: Figure 1 Flattouch
Panel becomes a central information point that can CONTROL T 2 be adjusted individually to the particular request. The FLATTOUCH comes equipped with Windows 10 IoT Enterprise on a 500 GB drive and is delivered ready to use. Figure 1 FLATTOUCH BAB TECHNOLOGIE FLATTOUCH... -
Page 5: Notes
• Ensure that the power supply unit supplied is adequately ventilated. Installation: • Make sure that is given sufficient ventilation on the backside of the panel. • Don´t cover or block vent holes of the panel. They are important for the (convection-) cooling of the panel! FLATTOUCH BAB TECHNOLOGIE... -
Page 6: Assembly
The wall mount consists of 2 parts. An adapter plate for the wall and another adapter plate for the FLATTOUCH. Please ensure that the holder is mounted horizontally. There is a corresponding marking on the adapter plates. (The picture shows both parts as they are hung into each other). BAB TECHNOLOGIE FLATTOUCH... -
Page 7: Moounting With Optional Vesa Mount
The correct position is marked by an arrow. The arrow is on both parts and must point upwards. Next, screw the adapter plate for the FLATTOUCH onto the back of the FLATTOUCH using the four screws provided. FLATTOUCH BAB TECHNOLOGIE... - Page 8 Installation Manual In the last step, the FLATTOUCH is hooked onto the wall bracket. In the following picture you can see how the adapter plate of the FLATTOUCH is hooked onto the adapter plate mounted on the wall. BAB TECHNOLOGIE FLATTOUCH...
-
Page 9: Commissioning
• Green arrow: RJ-45 socket (network connection). The network cable is connected here • Red arrow: 4* USB ports, e.g. to connect a keyboard and mouse for commissioning • Blue arrow: button to switch on the FLATTOUCH FLATTOUCH BAB TECHNOLOGIE... -
Page 10: Switch On - Off Flattouch
"Power Switch" FLATTOUCH (approx. 6 seconds). After the operating system has been started, the CONTROL T2 is started automatically. However, the start-up behaviour can be adjusted at any time. BAB TECHNOLOGIE FLATTOUCH... -
Page 11: Appendix
ARTICLE NUMBERS AND IDENTIFIERS FLATTOUCH 10.1” ..........................04651s FLATTOUCH 15.6” ..........................04655s FLATTOUCH 18.5” ..........................04659s FLATTOUCH 21.5” ..........................04661s Optional FLATTOUCH Wall Mount ........................04620 DIMENSIONS Width Height Depth Weight FLATTOUCH 101 FLATTOUCH 1560 245. FLATTOUCH 1850 FLATTOUCH 2150 FLATTOUCH BAB TECHNOLOGIE...
