Description
Magnet Mount
Note:
•
This product is intended to only be used in stationary locations not subject
to high g-force events or prolonged excessive vibration.
•
Do not exceed 15lbs total weight mounted to the device in vertically
mounted locations.
•
Ensure mounting surface is clean and flat. Paint, material type, and surface
imperfections on the mating surface will affect performance.
call us at 1-888-869-7652 | info@precisionmounts.com
Magnet Mount
User Guide
www.precisionmounts.com
Part Number
AS5.G001.001
1
Advertisement
Table of Contents
Related Manuals for PMT AS5.G001.001
Summary of Contents for PMT AS5.G001.001
- Page 1 Magnet Mount User Guide Description Part Number Magnet Mount AS5.G001.001 Note: • This product is intended to only be used in stationary locations not subject to high g-force events or prolonged excessive vibration. • Do not exceed 15lbs total weight mounted to the device in vertically mounted locations.
- Page 2 HARDWARE DESCRIPTION 4x Neodymium Magnets Base Plate 8x ¼-20 UNC threaded holes in 2x VESA 75mm patterns for attaching devices 4x ¼-20 nuts) 3/8” Counter sunk hole for attaching optional 4x M4x20mm button tilt/swivel devices. (Bolt head screws included with optional devices).
- Page 3 CONFIGURATION For use with PMT Universal Tablet Cradles: Step 1 – Place the 4x ¼-20 nuts over the threaded holes on the bottom of the cradle as shown Step 2 – Place the magnet mount assembly over the nuts as shown, and use the provided M4 x 20mm screws to fasten the Magnet Mount to the Cradle.
- Page 4 Depending on which laptop dock you are attaching to there may be slight variations in which holes and hardware is used. Step 1 – Remove the mounting plate from your PMT docking station and save the screws for a later step.
- Page 5 For use with PMT Tablet Docking Stations and Cradles: Step 1 – Remove the mounting plate from your PMT tablet docking station and attach to the Magnet Mount using the 4x provided ¼-20 button head screws.
- Page 6 CONFIGURATION Step 2 – Place your PMT tablet docking station in the mounting plate and fasten with the screws provided with your dock. Note: The Magnet Mount can be used with other manufacturers docks and cradles as well. Some units may require the threaded holes on the PMT Magnet Mount be drilled out to apx .257”...
- Page 7 To attach the tilt bracket to the Magnet Mount use the provided 3/8” flat head bolt assembly that comes with PMT tilt brackets.
