Conforms to ANSI STD Z21.58-2018
Certified to CSA STD 1.6-2018
Outdoor Cooking Gas Appliance
IMPORTANT: Read all instructions and warnings before using this product! Use of this product, as with any
similar outdoor grill, will involve risks from high temperatures and from exposure to smoke and fumes.
Please exercise caution and common sense.
To installer or person assembling grill: Leave this manual with grill for future reference.
To consumer: Keep this manual for future reference as it contains important Warnings and Instructions.
FOR OUTDOOR USE ONLY
AFFIX SERIAL NUMBER
LABEL HERE
052022_V1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Wildfire Ranch Pro WF-PRO30G-RH Series
Summary of Contents for Wildfire Ranch Pro WF-PRO30G-RH Series
- Page 1 Conforms to ANSI STD Z21.58-2018 Certified to CSA STD 1.6-2018 AFFIX SERIAL NUMBER Outdoor Cooking Gas Appliance LABEL HERE IMPORTANT: Read all instructions and warnings before using this product! Use of this product, as with any similar outdoor grill, will involve risks from high temperatures and from exposure to smoke and fumes. Please exercise caution and common sense.
- Page 2 Ranch Pro 42" WF-PRO42G-RH-XX Welcome to Wildfire Outdoor Living Please read this manual carefully to understand all the instructions about how to install, operate and maintain your grill for your safety and for optimum performance and longevity. We know you’ll enjoy your new grill and thank you for choosing our product.
-
Page 3: Table Of Contents
Table of Contents & Critical DANGER Safety Warnings DANGER means if the danger is not avoided, it will cause death or serious injury. General Safety Instructions ....3 WARNING Limited Warranty ........5 Grill Models..........6 WARNING means if the warning is not heeded, it can cause death or serious injury. -
Page 4: General Safety Instructions
11. Installation and any repairs or replacement of parts should be performed by a qualified ser- 2. Wildfire grills are only intended for residential vice technician. If you are not qualified to install, use and are not intended for commercial use,... - Page 5 General Safety Instructions (continued) 18. NEVER heat any unopened glass or metal Let hot grease cool down before attempting to container of food on the grill. Pressure may build handle or dispose of it. After use and cool-down, up and cause the container to burst, possibly the drip tray should be cleaned on a regular resulting in death, serious personal injury, or basis and kept free of grease.
-
Page 6: Limited Warranty
This product has a limited lifetime warranty that starts at date of purchase and continues throughout the life of the product. Under this warranty, Wildfire has the option to repair or replace any defective part of the product during the warranty period. This warranty does not cover normal wear of parts, damage resulting from any of the following: negligent use or misuse of the product, use on improper fuel/gas supply, use contrary to operating instructions, or alteration by any person other than a factory service center. -
Page 7: Grill Models
Grill Models Ranch Pro 36" Ranch Pro 30" WF-PRO36G-RH-XX WF-PRO30G-RH-XX Ranch Pro 42" WF-PRO42G-RH-XX Product BTU/HR Hood Model No. Width (Main/Back) Burner(s) Light (inch/mm) WF-PRO30G-RH-XX 30" (762) 32,000/14,000 2 Cast Stainless Burners WF-PRO36G-RH-XX 36" (914) 48,000/14,000 3 Cast Stainless Burners WF-PRO42G-RH-XX 42"... -
Page 8: Locating The Grill
If you smell gas, check for gas leaks immediately. Check only with a soap and water solution. Never check for gas leaks with an open flame. Notice: We strongly recommend professional installation of your WILDFIRE Grill. These instructions pro- vide the measurements necessary to construct a masonry structure to house your outdoor gas grill. - Page 9 • FROM COMBUSTIBLE MATERIALS: Wildfire grills must have at least 24” clearance from any combusti- ble materials (in any direction) for the safety of the homeowner and for any Wildfire Warranty to remain in effect.
- Page 10 High Elevation Installation and Use Wildfire Grills are designed to operate most efficiently at 0-2000 feet above sea level. From 2000-4000 feet above sea level you will not notice any substantial decrease in your heat, although more gas is combust- ing within the burners due to less oxygen.
-
Page 11: Gas Requirements
Do not connect a Wildfire liquid propane gas grill to a natural gas supply, and do not connect a Wildfire natural gas grill to a liquid propane gas supply. • All pipe sealants must be an approved type and resistant to the actions of LP gas. Never use pipe sealant on flare fittings. -
Page 12: Liquid Propane Gas Supply
11" (279.4mm) water column (W.C.) when equipped with the correct propane orific- es on the valves and a propane regulator on the supply line regulated at the residential meter. A Wildfire liquid propane gas grill comes with a propane regulator that is designed to be used with a standard 20 lb. gas cylin- der and those cylinders must be constructed and marked in accordance with specifications of the US Depart- ment of Transportation for propane gas cylinders. - Page 13 • All L.P. gas cylinders used with this appliance shall be constructed and marked in accordance with the specifications for L.P. gas cylinders of the U. S. Department of Transportation (DOT) or the National Standard of Can- ada, CAN/CSA-B339, Cylinders, Spheres and Tubes for Transportation of Dangerous Goods;...
- Page 14 There is a major leak at the connection. Correct before proceeding by calling the Wildfire Customer Service line at 602-344-4840. 7. If no rushing sound, brush soapy solution onto areas where bubbles are shown in LP tank (Figure 2).
- Page 15 LP Gas Supply Cylinder Disconnection In order to disconnect the LP tank from the grill: 1. Turn the burner valves off. 2. Turn the tank valve off. (Turn shut-off clockwise to stop). 3. Detach the regulator assembly from the tank valve by turning the quick coupling nut counterclockwise. LP Tank Removal, Transport and Storage •...
-
Page 16: Natural Gas Supply
Wildfire does not supply any gas fittings or lines, other than the regulator needed within the grill box. • All Wildfire LP grills come with a 20lb tank regulator. This regulator cannot be used or modified to work on any other setup. - Page 17 3. All Pipe threads need to have proper, gas-rated, outdoor-rated thread sealant. Flare ends do not need or utilize pipe sealant. 4. Your NG Wildfire grill comes with a ½” pressure regulator, find gas hose with NG pressure regulator on rear of grill.
-
Page 18: Connecting Electrical Transformer
Instruction for Connecting the Transformer Follow the pictures and insert the white male plug into the white female socket, on the left side of your grill and then plug the transformer into a standard 110v outlet. If you have any questions or concerns, please consult or use a qualified electrician. -
Page 19: Operating The Grill
Operating the Grill • Failure to open the lid prior to igniting the barbecue’s burners, or not waiting 5 minutes to allow the gas to clear if the barbecue does not light, may result in an explosive flame-up which can cause serious bodily injury or death. GENERAL RULES NEVER leave the grill unattended while cooking! •... -
Page 20: Lighting Your Grill
5 minutes before starting the process again. 5. If at this point the grill will still not ignite, contact Wildfire Customer Service at 602-344-4840, for further assistance to troubleshoot your grill. -
Page 21: Using Your Burners & Grilling Safely
Using Your Grill and Grilling Safely Your grill is designed to reach a temperature that you set by adjusting a valve that in-turn adjusts the amount of gas that goes through each burner. This valve is located behind the knob and is the key to your heat and fuel consumption. - Page 22 Never stand with your head directly over the Grill when preparing to light the Rotisserie burner, to prevent pos- sible bodily injury. Be sure to engage in safe food handling and preparation. Wildfire is not responsible for any injury or illness resulting from either under-cooking or over-cooking of meats, poultry, or other food.
-
Page 23: Care & Maintenance
Care & Maintenance All cleaning and maintenance should be done only when grill is cool & with the fuel supply turned off at the cylinder or source. Drip Tray The drip tray located below the grill should be cleaned periodically to prevent buildup of debris. NOTE: Allow the drip tray to cool before attempting to clean. - Page 24 5. If your grill has developed surface discoloration or surface rust, clean the unit as stated above and use a good third-party polish to remove or reduce the spots. Follow instructions provided on any third-party pol- ish products. Wildfire does not insure or guarantee the performance of or results from such products.
- Page 25 Ways to Avoid Rust on your Grill 1. Purchase a Wildfire Grill cover for your unit. This will ensure that your cover is a correct fit and breathable, while providing the protection needed to keep contaminants off of the surface.
- Page 26 ANNUAL CLEANING OF GRILL HOUSING Burn-off of the barbecue after every cookout will keep it ready for its next use. However, once a year, you should give the entire grill a thorough cleaning to keep it in top operating condition. 1.
-
Page 27: Troubleshooting Your Grill
If the grill does not function properly, use the chart below to assist in diagnosing the problem. Troubleshooting is for general purposes only. ALWAYS ERR ON THE SIDE OF SAFETY. If the problem still exists, contact our Wildfire Customer Service line at 602-344-4840. -
Page 29: Parts Listings
WF-PRO30G-RH Exploded Parts View... - Page 30 WF-PRO30G-RH Exploded Parts Chart 30" Description Part No. Hood 02-00305 Hood Handle 02-00306 Thermometer 09-00005 Thermometer Base 02-00307 Wind Guard 02-00308 Rear Hood 02-00309 Check Window for IR Burner 02-00310 Halogen Light 01-00086 Warming Rack 02-00312 IR Burner Lighting Box Bracket 02-00312 Hood Spring 02-00313...
- Page 31 WF-PRO36G-RH Exploded Parts View...
- Page 32 WF-PRO36G-RH Exploded Parts Chart 36" Description Part No. Hood 02-00325 Hood Handle 02-00326 Thermometer 09-00005 Thermometer Base 02-00307 Wind Guard 02-00327 Rear Hood 02-00328 Check Window for IR Burner 02-00310 Halogen Light 01-00086 Warming Rack 02-00329 IR Burner Lighting Box Bracket 02-00312 Hood Spring 02-00313...
- Page 33 WF-PRO42G-RH Exploded Parts View...
- Page 34 WF-PRO42G-RH Exploded Parts Chart 42" Description Part No. Hood 02-00338 Hood Handle 02-00339 Thermometer 09-00005 Thermometer Base 02-00307 Wind Guard 02-00340 Rear Hood 02-00341 Check Window for IR Burner 02-00310 Halogen Light 01-00086 Warming Rack 02-00342 IR Burner Lighting Box Bracket 02-00312 Hood Spring 02-00313...
- Page 35 NOTES _________________________________________________________________________________________ _________________________________________________________________________________________ _________________________________________________________________________________________ _________________________________________________________________________________________ _________________________________________________________________________________________ _________________________________________________________________________________________ _________________________________________________________________________________________ _________________________________________________________________________________________ _________________________________________________________________________________________ _________________________________________________________________________________________ _________________________________________________________________________________________ _________________________________________________________________________________________ _________________________________________________________________________________________ _________________________________________________________________________________________ _________________________________________________________________________________________ _________________________________________________________________________________________ _________________________________________________________________________________________...
- Page 36 OUR STAFF IS READY TO PROVIDE ASSISTANCE Copyright © 2022 RPG Brands (Wildfire Outdoor Living). All rights reserved. Products and specifications subject to change without notice. The product images shown are for illustration purposes only and may not be an exact representation of the product.
