Manufacturers of Reliable Centrifuges for the Metalworking Industry
INSTALLATION AND OPERATING INSTRUCTIONS FOR STANDARD BARRETT MODEL
Includes instructions for optional heaters and 45-gallon capture tank
This machine is designed to spin machining fluids (cutting oils, coolants, etc.) from industrial
sludge. Prior to using it on any other application you should contact Barrett Centrifugals Inc.
to determine if the machine can be used successfully and safely.
THIS EQUIPMENT MUST BE INSTALLED, WIRED, OPERATED AND SERVICED BY
QUALIFIED PERSONS ONLY. READ, UNDERSTAND AND COMPLY WITH THESE
INSTALLATION, OPERATING AND SAFETY INSTRUCTIONS BEFORE INSTALLING,
OPERATING OR SERVICING THIS EQUIPMENT.
SAFETY IS ESSENTIAL
To insure safe machine operation proper installation and thorough operator training are
required. Read and observe all instructions and specific precautions included in this manual
and most importantly, think before you act and be careful.
401 & 1101 COMBINATION EXTRACTORS
Serial No. 4010263-E
Motor No. 6R3467
#0-313A-SBA (6/01)
Page 1 of 14 pages
BARRETT CENTRIFUGALS INC.
1-800-228-6442
Advertisement
Table of Contents
Summary of Contents for Barrett 401
- Page 1 This machine is designed to spin machining fluids (cutting oils, coolants, etc.) from industrial sludge. Prior to using it on any other application you should contact Barrett Centrifugals Inc. to determine if the machine can be used successfully and safely.
-
Page 2: General Safety Precautions
This machine is not suitable for use with volatile or flammable liquids! This Barrett machine is not equipped for use in hazardous locations as defined by the National Fire Protection Association (NFPA). NFPA guidelines designate locations that may be hazardous due to ignitable atmospheres caused by generation of vapors from flammable or combustible liquids. -
Page 3: Machine Setup
On wooden floors, straddle the beams and use through bolts. On concrete floors, Barrett recommends the use of epoxy-set type anchors to secure the machine to the floor. The machine must be absolutely solid with the floor. Do not set in wet cement! Do not run machine without anchoring or vibration may allow it to move about and damage the electrical connections.! - Page 4 The motor cooling blower is set at the Barrett factory to remain on for 10 minutes after a cycle ends. ...
- Page 5 In the event of a power failure the solenoid is disabled. The lid may not be opened until power is supplied. If a momentary power loss occurs during a ‘run’ condition the latch will not unlock until the spindle coasts to a stop. #0-313A-SBA (6/01) Page 5 of 14 pages BARRETT CENTRIFUGALS INC. 1-800-228-6442...
-
Page 6: Duty Cycles
2.Adjust the cycle timer 1TRE. Barrett recommends an initial setting of three minutes for the 1101E (the SES will require a longer cycle time. Close and latch the control panel door. (Note: The required cycle time will vary with the application and must be determined through experimentation.) - Page 7 USE AND CARE OF FILTER ELEMENTS AND SPOKED PAN (SES MODEL MACHINE) Barrett SES type machines are equipped with special pans and filter elements that maximize the efficiency of the liquid extraction. The spokes on the pan create a path for liquid to escape.
- Page 8 If your machine is a model #401-SE or 1101-SE the pan proper contains no filter elements. If your machine is a model #401-SES or 1101-SES the pan should be lined with filter elements. The elements attached to the side of the pan need to be adjusted before...
- Page 9 Raise the cover so that it hovers over the loaded pan and the cover’s chains are slack enough to be connected to the pan. Attach safety hooks Lower pan into place #0-313A-SBA (6/01) Page 9 of 14 pages BARRETT CENTRIFUGALS INC. 1-800-228-6442...
-
Page 10: Starting And Stopping
(sludge, chips, dirt, etc.) off of the pan’s exterior or the pan may not seat correctly in the machine. Position the pan over the center of the Extractor. Loading a Sludge Extractor (models # 401 or 1101) Load pan cover onto spindle... -
Page 11: Emergency Operation
Level the tank by shimming at anchor bolt holes to insure full and solid support. Bolt the tank according to the type of floor, using through bolts or expansion shields. #0-313A-SBA (6/01) Page 11 of 14 pages BARRETT CENTRIFUGALS INC. 1-800-228-6442... -
Page 12: Preventive Maintenance
Fill with oil to the top of the oil cup and check the oil level weekly. Grease the lid hinge weekly. #0-313A-SBA (6/01) Page 12 of 14 pages BARRETT CENTRIFUGALS INC. 1-800-228-6442... - Page 13 The sensor’s sensitivity is set at an optimum level at the Barrett factory. It should not require adjustment. However, if it seems to be malfunctioning, check the following:...
- Page 14 If the sensor does not turn freely apply some WD-40 or similar lubricant to the threads. When the sensors are adjusted properly, tighten the jam nuts to approximately 48 inch pounds of torque. Fig. 4. Lid latch components #0-313A-SBA (6/01) Page 14 of 14 pages BARRETT CENTRIFUGALS INC. 1-800-228-6442...
-
Page 15: Repair Parts
Be sure to replace and securely fasten the sheet metal guard and enclosure cover when complete. BEARINGS The bearings in this machine are for centrifugal application having special internal fits and should be purchased from Barrett. REPAIR PARTS Repair parts are available from: Barrett Centrifugals Inc.
