- Page 1 Sand Separator Hydrocyclone & Sedimentation Tank Installation & Operation Manual Yamit Filtration & Water Treatment Ltd.. PO Box 232, Moshav Tnuvot, 428300 Israel. Tel: +972-4-6220006 Fax: +972-4-6220042 e-mail: yamit@yamit-f.com www.yamit-f.com...
-
Page 2: Table Of Contents
Technical Data Initial Installation & Operation Sedimentation Tank Flushing Periodic Cleaning Maintenance IPB & Spare Parts description International Warranty ALL RIGHTS RESERVED, THIS MANUAL AND THE INFORMATION CONTAINED ARE NOT ALLOWED TO BE USED WITHOUT WRITTEN PERMISSION FROM YAMIT FILTRATION... -
Page 3: General Information & Operation
F700 1. General Information & Operation Applications: Sand separator for well applications Standard Characteristics: • Filter housing material of construction: Carbon Steel ST37.2 • Pre-treatment: sand blasting up to Sa 2.5 grade • Exterior & Interior coating: electrostatic oven baked polyester-epoxy powder coating with a thickness of 150-200 micron •... -
Page 4: Description
F700 2. Description A Hydrocyclone separates sand and other solid matter from water with very little head loss and 90% or better efficiency. There is no head loss build up and no clogging when the solids are separated. Hydrocyclones are easy to operate and maintain, and have no moving parts or screens. -
Page 5: Technical Data
F700 3. Technical Data & Specifications As a rule, the separation efficiency improves as the Hydrocyclone diameter decreases and the head loss increases. Miniature Hydrocyclones may be used for easy sampling of liquids, for determining filter (including larger Hydrocyclones) operation and efficiency and for testing the feasibility of operation for the problem at hand. - Page 6 F700 Filtration Grade Conversion Table MESH MICRON Pressure loss at 130 micron...
-
Page 7: Initial Installation & Operation
F700 4. Initial Installation & Operation General Based on the centrifuge principle, the particles are spun against the outside wall of the Hydrocyclone and gravitate towards the bottom into the Sedimentation Tank. The velocity at which the water flows through the Hydrocyclone determines the efficiency at which the particles are separated from the water. -
Page 8: Sedimentation Tank
F700 5. Sedimentation Tank 51 FLUSHING • The Sedimentation Tank can be flushed manually or automatically with an irrigation controller or backflush controller at periodic intervals. • When a manual valve is installed, drain the Sedimentation Tank at periodic intervals according to the recommendations. -
Page 9: Ipb & Spare Parts Description
F700 6. Illustrated Parts Breakdown... - Page 10 F700 Model Catalog No Description UNDER FLOW CHAMBER BODY F700#000# FT000 F710#001M FT001M TIGHTENING HANDLE 4" FOR F720#001M E6020104000 F115/215/FT001-2 F730#002M FT002M F740#005M FT005M F750#005M F750LF#010V FT010V F755#030M FT030M E6020106000 TIGHTENING HANDLE 6"/8" F770#150F FT150F F775#150F F780#300F FT300F F710#001M FT001M TIGHTENING BRACKET 4"...
- Page 11 F700 Model Catalog No Description BOLT HEX HEAD 5/16"NC*1.1/4" HOT F760#060F FT060F 4102110401-030 GALVANIZED WASHER 5/16" HOT GALVANIZED F760#060F FT060F 4122110401 F760#060F FT060F 4112110401 NUT 5/16"NC HOT GALVANIZED F710#001M FT001M F720#001M 4180056501 PLUG 1/2"BSP PLASTIC F730#002M FT002M F740#005M FT005M 4180076501 PLUG 3/4"BSP PLASTIC...
- Page 12 F700 Model Catalog No Description F710#001M F0710 E4200100300 STEEL INSERT 1"*1/2"BSP F710/720 F720#001M F0720 F730#002M F0730 E4200150300 STEEL INSERT 1.1/2"*3/4"BSP F730 F740#005M F0740 E4200200301 STEEL INSERT 2"*1"BSP F740/750 F750#005M F0750 F755#030M F0755 E4200200300 STEEL INSERT 2"*1.1/2"BSP F755 F750LF#010V F0750VLF 4150103000-01P QUICK COUPLING 3"...
-
Page 13: International Warranty
F700 7. International Warranty YAMIT Filtration & Water Treatment Ltd. (hereinafter -" YAMIT") guarantees to the customers who purchased YAMIT's products directly from YAMIT or through its authorized distributors, that such products will be free from defect in material and/or...
