PERDIX Bird Nesting Box Assembly Instructions

8mm Ratchet
or Box Spanner
BACK
2 x SIDE
Place the back onto a flat
1
surface with the screw
holes at the bottom
and the bevel as
shown.
Screw holes at the bottom
Turn over and put the final
4
two 40mm screws for fixing
the base.
PERDIX Wildlife Supplies. Unit 1 Hatton Rock Business Park,
Tel: +44 (0)1789 336123 www.perdixwildlifesupplies.com
Visit our site
PZ2 Pozi drive
Screw Driver
BASE
Attach the first side with 2 x
2
40mm screws, making sure it
is square with the
bevelled top.
Repeat with the
second
side.
Hatton Rock, Stratford-Upon-Avon, CV37 0BX. UK
Bird Nesting Box
Assembly Instructions
Optional PVA
Wood Glue
(Recommended on
all fixed edges)
WOOD
GLUE
ROOF DOOR
Using the two machine head
5
screws, nuts and washers
affix the mount post as in
the diagram.
Non-Toxic
Weatherproof
Finish
WOOD
FINISH
(Exterior of the
nest box only)
Machine Head Screws, Nut & Washer
x2
40 mm Wood Screws x 18
50 mm Wood Screws x 2 (for hanging)
Push in the base all the way
3
making sure it is flush with
back and sides. Then fix with
four 40mm screws.
x4
x2
Please
Recycle
