IONIC SP-12V4AH-S8 Manual

Hide thumbs

Advertisement

Quick Links

LithiumHub
Customer service at
(704)360-9311
info@lithiumhub.com
125 Tate Rd., Norris, SC 29667
Made in CHINA – US Patent number 9412994

Advertisement

loading
Need help?

Need help?

Do you have a question about the SP-12V4AH-S8 and is the answer not in the manual?

Questions and answers

Summary of Contents for IONIC SP-12V4AH-S8

  • Page 1 LithiumHub Customer service at (704)360-9311 info@lithiumhub.com 125 Tate Rd., Norris, SC 29667 Made in CHINA – US Patent number 9412994...
  • Page 2 STARTER BATTERY Manual SP-12V4AH-S8 STARTER BATTERY (500CA-300CCA) SP-12V9AH-S8 STARTER BATTERY (720CA-400CCA) SP-12V30AH-S8 STARTER BATTERY (1220CA-900CCA)

  • Page 3: Table Of Contents

    Manual Table of Contents Page 4. Important Notes Page 6. Starter Features Page 8. Starter Battery Instruction Page 9. Red Ionic Batteries APP Page 10. General Information Page 12. Battery Installation Page 13. Technical Specifications Page 16. Preventative Maintenance Page 18. Warranty...

  • Page 4: Important Notes

    Important Notes PLEASE READ THE ENTIRE INSTRUCTION MANUAL BEFORE OPERATING YOUR IONIC STARTER BATTERY. SAVE THESE INSTRUCTIONS. REVIEW ALL CAUTIONARY MARKINGS ON THIS PRODUCT AND IN THIS MANUAL. FULLY CHARGE THE BATTERY BEFORE FIRST USE AND CHARGE EVERY SIX MONTHS FOR OPTIMAL PERFORMANCE.
  • Page 5 STARTER Manual Thank Thank You for choosing IONIC Lithium-ion Starter batteries. IONIC batteries are a high quality, light weight, powerful, durable and portable power starter battery solution. Performance and safety are paramount in this innovative product. Our goal is to provide...

  • Page 6: Starter Features

    Starter Features ǪualityEngineering LITHIUMHUB Lithium Advantage LithiumHub’ s battery management LithiumHub’ s innovation laboratory The obvious advantages are weight system (BMS) is inside each battery prides itself on the design and savings, higher cycles and low self- case and uses high power MOSFETs construction of its batteries using discharge rate versus old lead acid technology.
  • Page 7 Battery Status Level. long pressing the start button or with low maintenance. Our batteries can be the “Ionic Red Battery” app. Please start installed in any orientation (upright or Battery Level LOW - Low engine right away when activated.

  • Page 8: Starter Battery Instruction

    • Charge level can be checked on the Starter Battery by short pressing the Function Button. • Exact charge level can be checked with the Ionic Red Batteries APP via Bluetooth. (Download Ionic Red Batteries APP from either Apple Store or Play Store.

  • Page 9: "Red Ionic Batteries" App

    STARTER Manual “Red Ionic Batteries” APP Using Your APP Starter Feature When the time comes to Starter Battery Dashboard Basic Info Page start your engine, open the Push Button for the APP, “Ionic Red Batteries”. Emergency Start Simply tap the circular...

  • Page 10: General Information

    General Information Starter versus Deep Cycle batteries? Starter batteries have high current cells and a Battery Management System(BMS) designed to handle the higher current required to start a vehicle or engine. Starter batteries deliver a large amount of current for only a short time and are not designed to be extended range energy storage devices.
  • Page 11 Charge (SOC) SOC shows approximately how much battery life remains on your Ionic Starter battery based what the voltage currently reads, also know as State of Charge (SOC). Note: The battery should be transported in 30% SOC. Battery Charge Remaining 14.6V...

  • Page 12: Battery Installation

    Battery Protection Circuit and “sleep” Mode NOTICE: Your Ionic battery has a protection circuit that will attempt to put the battery in “sleep mode” if you have an over/under voltage situation, have reversed the polarity or you pulled too much current(overload). The Battery Management System(BMS) may not be able to protect the battery from damage in all circumstances.
  • Page 13 STARTER Manual Circuit Protection Battery Protection Type Over-charge protection ~15.2V- Over-charge release ~14.4V- Overcharge Protection Over-charge release method ~<14.4V- Over-discharge protection ~10V- Over-discharge release Over Discharge Protection ~10.5V- Over-discharge release method ~<10.5V Discharge over current protection Battery Specific Over Current Protection Protection delay time Battery Specific Over current release method...
  • Page 14 Technical SPECIFICATIONS 12V4Ah 12V9Ah 12V30Ah Starter Battery Size Voltage 4Ah/ 51Wh 9Ah/ 115Wh 30Ah/ 384Wh Capacity LiFePO4 LiFePO4 LiFePO4 Chemistry 3.3lbs (1.5kg) 4.4lbs (2kg) 9lbs (4.1kg) Weight 7.7”x5.1”x6.1” 7.7”x5.1”x6.1” 7.7”x5.1”x6.1” Dimensions 196x130x155mm 196x130x155mm 196x130x155mm Life Cycles 3000 @ 80% DOD 3000 @ 80% DOD 3000 @ 80% DOD Max Charge Voltage...
  • Page 15 STARTER Manual Temperatures Many battery users are unaware that lithium-ion batteries cannot be charged below 0°C (32°F). Although the pack appears to be charging normally, plating of metallic lithium can occur on the anode during a sub-freezing charge. This is permanent and cannot be removed with cycling. Batteries with lithium plating are more vulnerable to failure if exposed to vibration or other stressful conditions.

  • Page 16: Preventative Maintenance

    Battery Preventative Maintenance Inspect the exterior Examine the outside appearance of the battery. The tops of the batteries and terminal connections should be clean and dry, as well as free of dirt and corrosion. The case should show no signs of cell expansion which could cause the case to bulge or split.
  • Page 17 STARTER Manual ™ Starting power wherever you need it!
  • Page 18 STARTER Manual Limited Warranty Five (5) year warranty Period of Coverage: This product is warranted to the original purchaser from the original purchase date for five (5) years and is subject to the Warranty Coverage described herein. Registration is required for warranty coverage.
  • Page 19 STARTER Manual Customer Commitment At LithiumHub we are committed to offering you the best value in the marketplace. If you have any questions or concerns, do not hesitate to contact us. If you need repair service, please contact us via phone or our website to make arrangements.
  • Page 20 WARNINGS 1. Keep out of reach of children. 2. Do not damage, drop or crush this product. Do not attempt to use this product if it has been dropped, punctured, run over or damaged in any way including damage to the clamp or cables. 3.

  • Page 21: Warnings

    STARTER Manual WARNING! RISK OF EXPLOSIVE GASES. Working in the vicinity of a lead acid battery is dangerous. Lead-acid batteries generate and vent explosive gases during normal operation. Always properly ventilated bilge or engine compartment before working in the vehicle’s engine compartment. DO NOT use this product near or in the presence of propane tanks, natural gas or any other explosive fumes.

This manual is also suitable for:

Sp-12v9ah-s8Sp-12v30ah-s8
