Summary of Contents for FOVNO RS-03B3
- Page 1 吸盘车顶架说明书 Sucker Bike Rack Instructions...
-
Page 2: Product Display
Product Specs and Parts Product List Rear wheel Name Text Accessories suction foot Fork clamp ×1 Quick release Adapter ×2 Microfibre Lubricant ×1 Protection cap ×4 lever×1 cleaning bike cloth ×1 rack × × M6×18 Screw ×3 M6 Locknut ×3 4mm Allen key ×1 10mm Wrench ×1 25×4cm Crank strap ×1 Fork clamp ×2... -
Page 3: Installation Steps
Part Name Quick release lever Fork clamp Screw Adapter Suction foot Locknut Text Cylinder rod Installation Steps 5. Fix the crank with crank 9. Fix the rear wheel on 1. Install fork clamp straps the rack 2. Choose the right front 6. - Page 4 Fork Clamp Installation...
-
Page 5: Accessories Selection
Accessories Selection Adapter specification The roof rack comes fitted adaptors to suit quick release type fork. If the front fork is the thru-axle please measure the distance of the fork opening and the diameter of the thru-axle. Choose the appropriate adapter from the following five specifications adapter (to be purchased separately). The diameter of the thru-axle （9/12/15/20mm）... -
Page 6: Installation And Removal
Installation and Removal Crank fixing · To avoid the cranking or bumping of the cranks in the process of driving, the crank should be fixed to the bike frame with crank strap. · The crank should be fixed before the bike is put on the rack, to prevent the crank from rotating and scratching the paint. - Page 7 Rear suction foot installation method Clean up the suction foot and car surface with wet towel, be careful not to leave too much water to avoid the suction foot sliding off. Put it on the chosen place. Then press the suction foot vertically against the car roof with one hand while the other hand pushes the cylinder rod to extract the air until the white line is in the pump and make sure there is no obvious sign of rebound from the cylinder rod.
-
Page 8: Cylinder Maintenance
Attention Cylinder maintenance Cylinder maintenance oil is used to maintain the cylinder, make the cylinder more lubricated and seal better. There is no regular time for the cylinder maintenance. If it is used frequently, please check it once a month. If not, please check and ensure that the cylinder is lubricated before use. Due to the transport control issue, the maintenance oil is not included in the package, please find a normal silicone oil at local market or bike shop to replace it. - Page 9 Fovno Tech 搜索 关注我们 Search Follow us Facebook YouTube 新浪微博 微信公众号 安装教程 WeChat Official Accounts Installation Video Instagram 公司名称 : 义乌市风动科技有限公司 邮 箱 : fengdongyiwu@163.com 地 址 : 浙江省金华市义乌市义亭镇稠义西路168号 Company name : Yiwu Fengdong Technology Co., Ltd. Email : fengdongyiwu@163.com...
- Page 10 Made in China...
