Axor ShowerSolutions 460/300 3jet Quick Start Manual

AXOR ShowerSolutions
Overhead shower 460/300 3jet with shower arm and square escutcheon
Surfaces: Brushed Brass___Article Number: 35282950

product features

· consists of: overhead shower, shower arm
· shower head size: 460 x 300 mm
· spray type: Rain, RainStream, Mono
· material spray disc: metal
· shower arm length 460 mm
· maximum flow rate at 3 bar: 18 l/min
· flow rate Rain spray (at 3 bar): 18 l/min
· flow rate RainStream spray (at 3 bar): 15 l/min
· flow rate Mono spray (at 3 bar): 18 l/min
· minimum flow pressure: 1,5 bar
· spray disc removable for cleaning
· overhead shower removable for cleaning
· installation: wall-mounted - for installation on iBox
· connection dimension: DN15
Product image
Technology
Scale drawing
