CABLE GLAND
INSTRUCTIONS
For Cable Gland Part Numbers
CG20P-G
CG30P-G
CG20A-B
CG30A-B
CG20-SS
CG30-SS
TOOLS NEEDED
2.5mm
1
Place the plastic base onto
the rubber base gasket.
Be sure to line up the four
screw holes.
CGM17P-G
CGM17A-B
CGM17-SS
Sudbury Elastomeric
Marine Sealant is
recommended. To
purchase call 800-655-7922
or visit
www.seaviewglobal.com
2
Drill pilot holes and secure
the base. Apply marine
adhesive sealant to the
threads of the screws.
5
Measure your cable diameter and select the appropriate drill tube provided.
3
Insert the rubber tapered
plug into the base.
Refer to website for most up to
date instructions and videos.
ww.seaviewglobal.com
4
Line up the Cable Gland
cover with the four holes in
the plastic base and screw
the bolts in with a 2.5mm
wrench, compressing the
rubber grommet.
Advertisement
Table of Contents
Summary of Contents for SeaView CG20P-G
- Page 1 CABLE GLAND INSTRUCTIONS For Cable Gland Part Numbers CG20P-G CG30P-G CGM17P-G Refer to website for most up to date instructions and videos. CG20A-B CG30A-B CGM17A-B CG20-SS CG30-SS CGM17-SS ww.seaviewglobal.com TOOLS NEEDED Sudbury Elastomeric Marine Sealant is recommended. To purchase call 800-655-7922 or visit www.seaviewglobal.com...
- Page 2 Take one of the four drill tubes (included with the Cable Gand). Double check to make sure the Insert drill tube into drill motor, and leave enough length to Apply small amount of tube is the right diameter for get through the tapered plug. soapy water to the tube and your installation.
