Sinnis motorcycles TERRAIN 125 Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

125
OWNER'S MANUAL
https://www.motomanuals.net/

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TERRAIN 125 and is the answer not in the manual?

Questions and answers

Related Manuals for Sinnis motorcycles TERRAIN 125

Summary of Contents for Sinnis motorcycles TERRAIN 125

  • Page 1 OWNER’S MANUAL https://www.motomanuals.net/...
  • Page 2 TERRAIN 125 (MY21 EURO5) The Motorcycle pictured in this owner’s manual may not fully match your actual SINNIS motorcycle. https://www.motomanuals.net/...
  • Page 3 Join our EXCLUSIVE Sinnis Owners Club Facebook Page, where YOU as a Sinnis owner can share your riding stories, queries and photos. Check out our @sinnis_motorcycles Instagram page for the latest pictures of show events, lifestyle and new models. Watch our Team’s video diaries, reviews and maintenance tips on our Sinnis Motorcycles YouTube Channel. https://www.motomanuals.net/...

  • Page 4: Table Of Contents

    TERRAIN 125 (MY21 EURO5) CONTENTS MOTORCYCLE SAFETY OPERATION GUIDE P 19 MAINTENANCE P 29 INFORMATION P 58 SPECIFICATIONS P 64 https://www.motomanuals.net/...

  • Page 5: Motorcycle Safety

    TERRAIN 125 (MY21 EURO5) MOTORCYCLE SAFETY This section contains important information for safe riding of your SINNIS motorcycle. Please read this section carefully. Safety Guidelines Tyres and Drive Chain P 10 Riding Precautions P 11 Refuelling & Fuel Guidelines P 17 Accessories &...

  • Page 6: Safety Guidelines

    TERRAIN 125 (MY21 EURO5) Safety Guidelines Follow these guidelines to enhance your safety when riding your SINNIS motorcycle: Perform all routine and regular inspections specified in this manual. Stop the engine and keep any sources of ignition away when filling the fuel tank.
  • Page 7 TERRAIN 125 (MY21 EURO5) Ride Defensively Always pay attention to other vehicles around you and do not assume that other drivers see you. Be prepared to stop quickly or perform an evasive manoeuvre. Make Yourself Easy to See Make yourself more visible, especially at night, by wearing bright reflective clothing, positioning yourself so other road others can see you, signalling before turning or changing lanes and using your horn to alert other road users when necessary.
  • Page 8 TERRAIN 125 (MY21 EURO5) Keep Your SINNIS in Safe Condition It’s important to keep your motorcycle properly maintained and in safe riding condition. Inspect your motorcycle before every ride and perform all recommended maintenance, never exceed load limits and do not modify your motorcycle or install accessories that would make your motorcycle unsafe.
  • Page 9 TERRAIN 125 (MY21 EURO5) Accessories and Loading The stability and handling of your SINNIS motorcycle may be affected by the addition of accessories and luggage. Read carefully the instructions contained in the user’s manual and installation guide before installing any accessories.

  • Page 10: Tyres And Drive Chain

    TERRAIN 125 (MY21 EURO5) Tyres and Drive Chain Cold Tyre Pressure: 250 kPa / 36 PSI / 2.5 Bar Tyre Size: Front: 100/80 – 17 (52S) Rear: 120/80 – 17 (61S) Chain Adjustment: Free Play 15 - 25mm (Keep chain lubricated)

  • Page 11: Riding Precautions

    TERRAIN 125 (MY21 EURO5) Riding Precautions Protective Apparel Make sure that you and any passenger are wearing an approved motorcycle helmet, eye protection and high- visibility protective clothing. Ride defensively in response to weather and road conditions. Helmet; Safety-standard certified, high-visibility and appropriate size for your head. Should fit comfortably but securely, with the chain strap fastened.
  • Page 12 TERRAIN 125 (MY21 EURO5) Running in Your New SINNIS Motorcycle After purchasing a new motorcycle there is a ‘running in’ period for the engine. It is vitally important that the motorcycle is successfully managed through this running in period as it will have a direct impact on the service life motorcycle.
  • Page 13 TERRAIN 125 (MY21 EURO5) Brakes Observe the following guidelines: Avoid excessively hard braking and downshifting. Sudden braking can reduce the motorcycle’s stability. Where possible, reduce speed before turning; otherwise, you risk sliding out. Exercise caution on low traction surfaces. Tyres can slip more easily, and braking distances are greatly increased.
  • Page 14 TERRAIN 125 (MY21 EURO5) Engine Braking Engine braking helps slow your motorcycle down when you release the throttle. For further slowing action, downshift to a lower gear. Use engine braking with intermittent use of the brakes to reduce speed when descending long steep slopes.
  • Page 15 TERRAIN 125 (MY21 EURO5) Riding in Wet Weather Conditions In wet or foggy weather, there will be low visibility and poor adhesion between the tyres and the road. Check tires for wear and check there is sufficient tread for optimum grip. When riding into low visibility or on slippery roads, keep to a safe speed and do not accelerate, brake or turn suddenly.
  • Page 16 TERRAIN 125 (MY21 EURO5) Parking Try to park on a firm level surface. If you must park on a slight incline or loose surface, park so that your SINNIS motorcycle cannot move or fall over. Make sure that high-temperature part cannot come into contact with flammable materials.

  • Page 17: Refuelling & Fuel Guidelines

    TERRAIN 125 (MY21 EURO5) Refuelling & Fuel Guidelines When refuelling your SINNIS motorcycle, use Unleaded fuel with a minimum octane rating of 92. Fuel Tank Maximum Capacity: 14 Litres / 3.07 Imperial Gallons Refuelling Turn off the engine when refuelling, then turn the ignition switch to the OFF position.

  • Page 18: Accessories & Modifications

    TERRAIN 125 (MY21 EURO5) Accessories & Modifications We strongly advise that you do not add any accessories that were not specifically designed or approved for your motorcycle by SINNIS or make modifications to your motorcycle from its original design. Doing so can make it unsafe.

  • Page 19: Operation Guide

    TERRAIN 125 (MY21 EURO5) OPERATION GUIDE Lock & Instrument Display P 20 USB Port P 21 Left & Right Handlebar Controls P 22 Operation Controls P 23 Starting & Warm-Up P 25 Riding Operation P 27 https://www.motomanuals.net/...
  • Page 20 TERRAIN 125 (MY21 EURO5) Lock & Instrument Display NAME SPECIFICATION Ignition on Turn the ignition key clockwise to provide power to the ignition. Ignition off Turn the ignition key anti-clockwise to turn the power off. Steering lock With the handlebars at full lock to the left, turn the key anti-clockwise to engage the steering lock.
  • Page 21 TERRAIN 125 (MY21 EURO5) USB Port To the right of the Dashboard is a USB port which can be used for the charging or powering of common electrical accessories. https://www.motomanuals.net/...
  • Page 22 TERRAIN 125 (MY21 EURO5) Left & Right Handlebar Controls NAME SPECIFICATION Passing Light Button When signalling to other road-users, press button to flash the Headlight High-Beam. Hi-Beam Switch Move switch to this postion to use the Headlight High-Beam function. Low-Beam Switch Move switch to this positon to return the Headlight to the Low-Beam function.
  • Page 23 TERRAIN 125 (MY21 EURO5) Operation Controls NAME SPECIFICATION Throttle Controls the Air/Fuel intake of the engine. (Causing RPM to increase or decrease) Gear Selector This motorcycle has 5 independent gears (1 Down, 4 Up). Reduce throttle input when changing gears.
  • Page 24 TERRAIN 125 (MY21 EURO5) CAUTION This motorcycle has a manual clutch system. When starting the motorcycle, ensure the motorcycle is in Neutral or hold the clutch lever in until ready to move. If the clutch system cannot fully engage or disengage (often referred to as ‘clutch slip’) then it is advised that you take the motorcycle to your nearest dealer for professional adjustment.
  • Page 25 TERRAIN 125 (MY21 EURO5) Starting & Warm Up When starting the motorcycle using the electric starter system, it should take no longer than approximately 5 seconds for the motorcycle to start. If the motorcycle is unable to start after 5 seconds, allow at least 10 seconds before the next attempt to start the motorcycle.
  • Page 26 TERRAIN 125 (MY21 EURO5) CAUTION This motorcycle has a manual clutch system. When starting the motorcycle, ensure the motorcycle is in Neutral or hold the clutch lever in until ready to move. If the clutch system cannot fully engage or disengage (often referred to as ‘clutch slip’) then it is advised that you take the motorcycle to your nearest dealer for professional...
  • Page 27 TERRAIN 125 (MY21 EURO5) Riding Operation The below guide assumes the engine is fully warmed and in neutral. Fully pull-in the clutch lever on the left handlebar. Select 1 gear by pushing down on the gear selector leaver on the left side of the motorcycle. (There should be an obvious feel of the gear engaging) Put your right foot on the rear brake.
  • Page 28 TERRAIN 125 (MY21 EURO5) CAUTION Once moving and the engine RPM continues to increase, change up through the available gears prior to the engine RPM reaching it’s maximum level in order to prevent damage to the engine due to excessive RPM.

  • Page 29: Maintenance

    TERRAIN 125 (MY21 EURO5) MAINTENANCE Importance of Maintenance P 30 Braking System Inspection & Adjustment P 51 Maintenance Schedule Adherence P 31 Checking the Side Stand P 54 Maintenance & Service Schedule P 32 Checking the Throttle P 55 Pre-Ride Inspection...
  • Page 30 TERRAIN 125 (MY21 EURO5) Importance of Maintenance Keeping your motorcycle well-maintained is absolutely essential to your safety and to protect your investment, obtain maximum performance, avoid breakdowns and reduce the environmental impact of your motorcycle. Maintenance is the owner’s responsibility. Be sure to inspect your motorcycle prior to each ride and perform periodic check specified in the Maintenance Schedule.
  • Page 31 TERRAIN 125 (MY21 EURO5) Maintenance Schedule Adherence The maintenance schedule specifies the maintenance requirements necessary to ensure safe, dependable performance and proper emission control. Maintenance work should be performed in accordance with SINNIS standards and specifications by properly trained and equipped technicians. Your dealer meets all of these requirements. Keep an accurate record of maintenance to help ensure that your motorcycle is properly maintained.
  • Page 32 TERRAIN 125 (MY21 EURO5) Maintenance & Service Schedule TIMING RUN-IN PERIODIC SERVICING PRE-RIDE ANNUAL 3000KM 9000KM 12000KM 1000KM 6000KM CHECK CHECK ITEM 600MILES 1800MILES 3600MILES 5400MILES 7200MILES VALVE CLEARANCE SPARK PLUG AIR FILTER OIL FILTER ENGINE OIL OIL STRAINER FUEL LINES...
  • Page 33 TERRAIN 125 (MY21 EURO5) TIMING RUN-IN PERIODIC SERVICING PRE-RIDE ANNUAL 1000KM 3000KM 6000KM 9000KM 12000KM CHECK CHECK ITEM 1800MILES 5400MILES 7200MILES 600MILES 3600MILES BRAKING SYSTEMS Discs / Pads / Calipers / Lighting Switches / Fluid CLUTCH SYSTEM Lever / Cable...

  • Page 34: Pre-Ride Inspection

    TERRAIN 125 (MY21 EURO5) Pre-Ride Inspection ITEM INSPECTION Fuel system Check for any leaks and tank is not overfilled. Check the level of the oil is within the specified range. Electrical system Check dashboard and electrical switches are functional. Battery Check battery visually for leaks and any corrosion.

  • Page 35: Replacing Parts

    TERRAIN 125 (MY21 EURO5) Replacing Parts Always use SINNIS Genuine Parts or their authorised equivalents to ensure reliability and safety. When ordering coloured components, specify the model name, colour and, if possible, code mentioned on the colour label. Battery Care Your SINNIS motorcycle has a maintenance-free type battery.

  • Page 36: Fuse Replacement

    TERRAIN 125 (MY21 EURO5) Fuse Replacement Fuses protect the electrical circuits on your SINNIS motorcycle. If something electrical on your motorcycle ceases to power on or loses function, check for and replace any blown fuses. To replace a fuse, first ensure the ignition of the motorcycle is in the off position. Identify the blown fuse and replace with a fuse of the same rating.

  • Page 37: Inspection & Replacement Of The Engine Oil P

    TERRAIN 125 (MY21 EURO5) Inspection & Replacement of the Engine Oil WARNING Engine oil is harmful to the environment and should be disposed of properly. Consult your local authorities for guidance on where to dispose. Checking If the engine is cold, idle the engine for 3 to 5 minutes.
  • Page 38 TERRAIN 125 (MY21 EURO5) WARNING Do not overfill above the upper-level mark. Check the oil level after each pouring of oil into the engine. Multiple short top-ups with checks are better for ensuring the correct oil level, rather than one large top up.
  • Page 39 TERRAIN 125 (MY21 EURO5) CAUTION Support the motorcycle with main stand to check the oil level, to ensure an accurate reading. It is advisable to get the engine oil replaced by a professional at your local Sinnis dealer, where possible. If carrying out this procedure yourself, use the engine oil recommended by your Sinnis dealer.
  • Page 40 TERRAIN 125 (MY21 EURO5) Drive Chain Inspection, Adjustment & Cleaning Check the drive chain slack at several points along the chain. If the slack is not constant at all points, some links may be kinked and binding. Have the chain inspected by your nearest SINNIS dealer.
  • Page 41 TERRAIN 125 (MY21 EURO5) Adjusting the Drive Chain Slack Adjusting the chain requires special tools. If you do not have access to these tools you should have the drive chain slack adjusted by your nearest SINNIS dealer. Shift the transmission into Neutral. Stop the engine.
  • Page 42 TERRAIN 125 (MY21 EURO5) Cleaning the Drive Chain Dirt should be cleaned from the chain using non-metallic bristled brushes and fabric cloths. Cleaning of the chain should be completed using chain-specific cleaning products. If cleaning the chain while installed in the motorcycle, be sure to wipe down any excess cleaning products from the brakes, tyres, wheels, engine and swingarm.

  • Page 43: Inspecting The Drive Chain Sprockets

    TERRAIN 125 (MY21 EURO5) Inspecting the Drive Chain Sprockets If either of the sprockets on the motorcycle show any signs of wear or damage, they should be replaced by your nearest SINNIS dealer. WARNING Use of a new chain with worn sprockets will cause rapid chain wear.

  • Page 44: Tyre Condition

    TERRAIN 125 (MY21 EURO5) Tyre Condition Visually inspect your tyres and use an air pressure gauge to measure the air pressure at least once per month or any time you think the tyre does not look sufficiently inflated. Always check the pressure of your tyres when the tyres are cold.
  • Page 45 TERRAIN 125 (MY21 EURO5) Tread Depth Inspect the tread wear indicators. If they become visible, replace the tyres immediately. WARNING Riding on tyres that are damaged, excessively worn or improperly inflated can cause the motorcycle to perform inconsistently or unexpectedly and could result in a crash and harm to the rider, passenger or other parties.

  • Page 46: Air Filter Cleaning

    TERRAIN 125 (MY21 EURO5) Air Filter Cleaning A dusty and/or blocked air filter element will cause the motorcycle to operate with lower-than-expected power output, high fuel consumption and/or a high-fuel concentration of exhaust gas. The air filter should be inspected and cleaned periodically, as per the recommended maintenance schedule.
  • Page 47 TERRAIN 125 (MY21 EURO5) WARNING Do not clean the air filter components with any substances with flammable or alkaline properties. Do not start the motorcycle without the air filter system installed correctly. The poor running conditions for the engine may result in abnormal wear to engine components.

  • Page 48: Spark Plug Inspection & Adjustment

    TERRAIN 125 (MY21 EURO5) Spark Plug Inspection & Adjustment Spark plugs should be replaced according to the Maintenance Schedule. Use only the recommended type of spark plug in the recommended heat range. Disconnect the spark plug can from the spark plug.
  • Page 49 TERRAIN 125 (MY21 EURO5) Make sure the plug washer is in good condition. Install the spark plug. With the plug washer attached, thread the spark plug in by hand to prevent cross-threading. Tightening the spark plug: If the old plug is good, 1/8 turn after it seats.

  • Page 50: Electronic Fuel Injection (Efi) System

    TERRAIN 125 (MY21 EURO5) Electronic Fuel Injection (EFI) System The function of the EFI System is to regulate the mixture of air and fuel which enters the combustion chamber of the engine of the motorcycle. The EFI System is comprised of a system of inter-communicating components:...

  • Page 51: Braking System Inspection & Adjustment

    TERRAIN 125 (MY21 EURO5) Braking System Inspection & Adjustment Checking the Brake Fluid Place your motorcycle in an upright position on a firm, level surface. Check that the brake fluid reservoir is horizontal and that the fluid level is between the LOWER and UPPER markings.
  • Page 52 TERRAIN 125 (MY21 EURO5) Inspecting the Brake Pads Check the condition of the brake pad wear indicators. The pads need to be replaced if a brake pad is worn to the bottom of the indicator. If necessary, have the pads replaced by your nearest SINNIS dealership.
  • Page 53 TERRAIN 125 (MY21 EURO5) Inspecting the Brake Lever Free-Play Front Brake Measure the distance the lever travels to the point that the brake begins to engage. From its natural position to this point should be in the range of 10-20mm.

  • Page 54: Checking The Side Stand

    TERRAIN 125 (MY21 EURO5) CAUTION After adjusting transmission chain or dismantling rear wheel, recheck and adjust the free stroke of rear brake pedal. After adjusting rear brake, must read just rear brake light switch. Also check whether the wheel can rotate freely.

  • Page 55: Checking The Throttle

    TERRAIN 125 (MY21 EURO5) Checking the Throttle With the engine off, check that the throttle rotates smoothly from fully closed to fully open in all steering positions and throttle free play is correct. If the throttle does not move smoothly, close automatically, or if the cable is damaged, have the motorcycle inspected by your nearest SINNIS dealer.
  • Page 56 TERRAIN 125 (MY21 EURO5) Adjusting the Clutch Lever Free play Upper Adjustment Pull back the rubber dust cover. Loosen the upper lock nut. Turn the upper clutch cable adjuster until the free-play is 10-20mm. Tighten the upper lock nut and check the free-play again.

  • Page 57: Additional Electrical Accessories

    TERRAIN 125 (MY21 EURO5) Additional Electrical Accessories The electrical system of your SINNIS motorcycle has been designed such that it should not exceed 20w. Any aftermarket electrical items fitted, such as GPS, anti-theft alarms or additional lighting may overload the motorcycle’s electrical capacity and potentially cause fire.

  • Page 58: Informationp

    TERRAIN 125 (MY21 EURO5) INFORMATION Cleaning & Storage P 59 Serial Numbers P 62 SINNIS Support Contacts P 63 https://www.motomanuals.net/...
  • Page 59 TERRAIN 125 (MY21 EURO5) Cleaning & Storage Cleaning Frequent cleaning and polishing are important to ensure the life of your SINNIS motorcycle. A clean motorcycle makes it easier to spot potential problems. In particular, seawater and salts used to prevent ice on road promote the formation of corrosion on metallic parts.
  • Page 60 TERRAIN 125 (MY21 EURO5) CAUTION Do not use high-pressure washers, they can damage moving and electrical parts rendering them inoperable. Water may also be forced into the engine induction system. Do not direct water into the exhaust system. An exhaust system blocked with water can prevent the engine starting and will also corrode internal components.
  • Page 61 TERRAIN 125 (MY21 EURO5) Storage If you store your motorcycle outdoors, you should consider using a full-body motorcycle cover. If you know that you will not be riding your SINNIS motorcycle for an extended period, follow the below guidelines: Wash your motorcycle and wax all painted surfaces (except Matt painted surfaces). Coat metallic components with rust-inhibiting oil.
  • Page 62 TERRAIN 125 (MY21 EURO5) Serial Numbers The Vehicle Identification Number (VIN) is stamped on the head-tube of chassis The Name-Plate is riveted the head-tube of chassis. The Engine Number is stamped on the left side at the bottom of the crank-casing.
  • Page 63 TERRAIN 125 (MY21 EURO5) SINNIS Support Contacts Address SINNIS Motorcycles, Ocean View Business Park, Gardner Road, Southwick, BN411PL. Email parts@sinnis.co.uk Telephone 01273 020 965 Website sinnismotorcycles.com Online Parts Catalog & Spare Parts Ordering parts.sinnismotorcycle.com https://www.motomanuals.net/...

  • Page 64: Specifications

    TERRAIN 125 (MY21 EURO5) SPECIFICATIONS Main Components P 65 Service Data P 66 Fuses P 67 Torque Data P 67 Circuit Diagram P 68 https://www.motomanuals.net/...

  • Page 65: Main Components

    TERRAIN 125 (MY21 EURO5) Main Components DETAIL VALUE DETAIL VALUE ENGINE TYPE Single Cylinder 4-Stroke Water Cooled WHEELBASE 1370mm DISPLACEMENT SEAT HEIGHT 780mm 124.2cm BORE & STROKE 58mm x 47mm MINIMUM GROUND CLEARANCE 158mm COMPRESSION RATIO 12:1 FUEL CAPACITY 14 Litres...

  • Page 66: Service Data

    TERRAIN 125 (MY21 EURO5) Service Data https://www.motomanuals.net/...

  • Page 67: Fuses

    TERRAIN 125 (MY21 EURO5) Fuses Torque Data DETAIL VALUE Oil Drain Bolt 27 Nm / 19.9 ft-lb Rear Axle Nuts 70 Nm / 51.6 ft-lb Rear Chain Adjustment Nuts 19 Nm / 16.2 ft-lb Front Axle Nuts 70 Nm / 51.6 ft-lb Front Axle Pinch Bolts 18 Nm / 17.7 ft-lb...

  • Page 68: Circuit Diagram

    TERRAIN 125 (MY21 EURO5) Circuit Diagram https://www.motomanuals.net/...
