  • Page 2 Manual Advantech MIO-5152 3,5” Single-Board Computer with Elkhart Lake Intel® Atom® x6000E series and Celeron® N and J series processor The information contained in this document has been carefully researched and is, to the best of our knowledge, accurate. However, we assume no liability for any product failures or damages, immediate or consequential, resulting from the use of the information provided herein.
  • Page 3 User Manual MIO-5152 Intel® Atom™ x6000E series and Intel® Celeron® N and J series 3.5"...
  • Page 4 Copyright The documentation and the software included with this product are copyrighted 2021 by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right to make improvements in the products described in this manual at any time without notice.
  • Page 5 Product Warranty (2 years) Advantech warrants the original purchaser that each of its products will be free from defects in materials and workmanship for two years from the date of purchase. This warranty does not apply to any products that have been repaired or altered by persons other than repair personnel authorized by Advantech, or products that have been subject to misuse, abuse, accident, or improper installation.
  • Page 6 Declaration of Conformity This product has passed the CE test for environmental specifications when shielded cables are used for external wiring. We recommend the use of shielded cables. This type of cable is available from Advantech. Please contact your local supplier for ordering information.
  • Page 7 Packing List Before you begin installing your card, please make sure that the following materials have been shipped: 1 x MIO-5152 SBC  1 x SATA cable 30 cm (11.8 in) (p/n: 1700006291)  1 x SATA power cable 35 cm (13.77 in) (p/n: 1700031583-01) ...
  • Page 8 MIO-5152 User Manual...

  • Page 9: Table Of Contents

    Contents Chapter General Information ......1 Introduction ....................2 Specifications .................... 2 Block Diagram................... 4 Chapter Mechanical ...........5 Introduction ....................6 Board Layout: Dimensions ................ 6 Figure 2.1 MIO-5152 Mechanical Diagram (Top Side) ....6 Figure 2.2 MIO-5152 Mechanical Diagram (Bottom Side) ... 6 Figure 2.3 MIO-5152 Mechanical Diagram (Coastline) ....
  • Page 10 3.4.23 Key E Connector................. 32 3.4.24 Key M Connector ................ 34 3.4.25 RTC Battery Connector .............. 36 Chapter AMI BIOS Setup......... 37 Entering Setup ..................39 4.1.1 Main Setup.................. 39 4.1.2 Advanced BIOS Features Setup..........40 4.1.3 Chipset Configuration ..............64 4.1.4 Security..................

  • Page 11: Chapter 1 General Information

    Chapter General Information This chapter details background information on the MIO-5152. Sections include:  Introduction  Specifications  Block diagram...

  • Page 12: Introduction

    Introduction Advantech MIO-5152 is a 3.5” form factor SBC (compact series, 146 x 102 mm; 5.7 x 4.01 in). Powered by Intel® Atom® x6000E series and Intel® Celeron® N and J series processors, it provides embedded iManager 3.0, SUSI 4.0, and Advantech’s WISE-DeviceOn to monitor and control system operation effectively and remotely.
  • Page 13 SATA 1 x SATA GenIII 6.0Gbps USB 2.0 Serial Bus I2C (support 400Kbit/s) 2 x RS-232/422/485 (support 1Mbps), 4 x RS-232 COM Port (115.2kbps) GPIO 8-bit general purpose input output I/O Internal I/O Audio Realtek ALC888s, Line-in/Line-out/MIC Inverter 12V/5V SPI Bus eSPI 4-wire smart fan Front Panel Con-...

  • Page 14: Block Diagram

    Block Diagram External I/O Internal I/O Opt. Func. DDR4-3200 IBECC, 1-CH, 8/16/32GB SO-DIMM Up to 32GB PCIe RTL8111H GbE #1 RJ-45 LVDS Dual Channel PTN3460 PCIe RTL8111H GbE #2 RJ-45 Diodes HDMI 1.4 PI3HDX1204B1ZHIEX SATA SATA DP1.4 SATA M.2 M-Key 2242 Intel Elkhart Lake (10+14nm)

  • Page 15: Chapter 2 Mechanical

    Chapter Mechanical This chapter details mechanical information on the MIO-5152. Sections include:  Mechanical Diagrams  Assembly Diagrams...

  • Page 16: Introduction

    Introduction The MI/O compact form factor SBC is a new-generation SBC designed- with a variety of mechanical improvements. Here is the quick installation guide for the thermal design and MIOe module. This chapter includes board dimension and assembly instructions for the standard thermal solution. Board Layout: Dimensions Figure 2.1 MIO-5152 Mechanical Diagram (Top Side) Figure 2.2 MIO-5152 Mechanical Diagram (Bottom Side)
  • Page 17 Figure 2.3 MIO-5152 Mechanical Diagram (Coastline) Figure 2.4 MIO-5152 Mechanical Diagram with Heatsink (Top Side) MIO-5152 User Manual...
  • Page 18 Figure 2.5 MIO-5152 Mechanical Diagram with Heatsink (Bottom Side) Figure 2.6 MIO-5152 Mechanical Diagram with Heatsink (Coastline) MIO-5152 User Manual...

  • Page 19: Quick Installation Guide

    Quick Installation Guide There is a Heatsink in the white box inside the package. Please assemble it by fol- lowing the diagrams below. Remember to remove the plastic on the thermal pad before you assemble the mechanical parts. 2.3.1 Heatsink MIO-5152 User Manual...
  • Page 20 MIO-5152 User Manual...

  • Page 21: Chapter 3 Installation

    Chapter Installation This chapter explains the setup procedures of the MIO-5152 hard- ware — including instructions on setting jumpers and connecting peripherals, switches, and indica- tors. Be sure to read all safety pre- cautions before you begin the installation procedure.

  • Page 22: Jumpers & Switches

    Jumpers & Switches The MIO-5152 has a number of jumpers that allow you to configure your system to suit your application. The table below lists the functions of the various jumpers. Table 3.1: Jumpers and Switches JCMOS1 CMOS Clear Switch VDD1 Panel Voltage Selection RI_VDD1...

  • Page 23: Locating Connectors

    Locating Connectors SATAP1 JCMOS1 DIMMA1 SMB1 AUDIO1 LVDS1 SATA1 FAN1 PSON1 VDD1 COM2 COM5 GPIO1 COM3 COM1 COM4 COM6 RI_VDD1 DCIN1/2 LAN1 LAN2 USB1 USB2 USB56 HDMI 1 Figure 3.1 MIO-5152 Connector Locations (Top Side) SIM1 BAT1 M2_M1 M2_B1(*optional) M2E1_1 Figure 3.2 MIO-5152 Connector Locations (Bottom Side) MIO-5152 User Manual...

  • Page 24: Setting Jumpers

    Setting Jumpers You may configure your card to match the needs of your application by setting jump- ers. A jumper is a metal bridge used to close an electric circuit. It consists of two metal pins and a small metal clip (often protected by a plastic cover) that slides over the pins to connect them.

  • Page 25: Panel Voltage Selection (Vdd1)

    3.4.2 Panel Voltage Selection (VDD1) Function Jumper Setting Panel Voltage Setting: +V3.3 (Default) Panel Voltage Setting: +V5 Panel Voltage Setting: +V12 Signal Pin Definition +V3.3 +V_LVDS_LCD +V12 3.4.3 COM RI# pin 5V/12V Selection (RI_VDD1) Function Jumper Setting RI# Voltage Setting: +V5 RI# Voltage Setting: +V12 RI# Voltage Setting: RI# (Default) MIO-5152 User Manual...

  • Page 26: Atx/At Mode Selection

    Signal Pin Definition COM1_z_RI# COM_RI# COM1_z_RI# +V12 COM1_z_RI# 3.4.4 ATX/AT Mode Selection Function Jumper Setting BIOS setting to AT mode BIOS setting to ATX mode 3.4.5 DC Input Connector Signal Pin Definition +V12_DC_IN +V12_DC_IN MIO-5152 User Manual...

  • Page 27: Dc Input Connector (Adapter)

    3.4.6 DC Input Connector (Adapter) Signal Pin Definition +V12_DC_IN 3.4.7 Internal USB Connector Signal Pin Definition +USBV3 +USBV3 USB2_D6- USB2_D5- USB2_D6+ USB2_D5+ N24172033 MIO-5152 User Manual...

  • Page 28: Com Port Connector (Rs232+Rs422+Rs485)

    3.4.8 COM Port Connector (RS232+RS422+RS485) Signal Pin Definition COM1_Z_RI# COM1_DTR# COM1_CTS# COM1_TXD COM1_RTS# COM1_RXD COM1_DSR# COM1_DCD# MIO-5152 User Manual...

  • Page 29: Com Port Connector (Rs232+Rs422+Rs485)

    3.4.9 COM port Connector (RS232+RS422+RS485) Signal Pin Definition COM2_RI# COM2_DTR# COM2_CTS# COM2_TXD COM2_RTS# COM2_RXD COM2_DSR# COM2_DCD# MIO-5152 User Manual...

  • Page 30: Com Port Connector (Rs232)

    3.4.10 COM Port Connector (RS232) Signal Pin Definition COM3_RI# COM3_DTR# COM3_CTS# COM3_SOUT COM3_RTS# COM3_SIN COM3_DSR# COM3_DCD# MIO-5152 User Manual...

  • Page 31: Com Port Connector (Rs232)

    3.4.11 COM Port Connector (RS232) Signal Pin Definition COM4_RI# COM4_DTR# COM4_CTS# COM4_SOUT COM4_RTS# COM4_SIN COM4_DSR# COM4_DCD# MIO-5152 User Manual...

  • Page 32: Com Port Connector (Rs232)

    3.4.12 COM Port Connector (RS232) Signal Pin Definition COM5_RI# COM5_DTR# COM5_CTS# COM5_SOUT COM5_RTS# COM5_SIN COM5_DSR# COM5_DCD# MIO-5152 User Manual...

  • Page 33: Com Port Connector (Rs232)

    3.4.13 COM Port Connector (RS232) Signal Pin Definition COM6_RI# COM6_DTR# COM6_CTS# COM6_SOUT COM6_RTS# COM6_SIN COM6_DSR# COM6_DCD# MIO-5152 User Manual...

  • Page 34: Audio Connector

    3.4.14 Audio Connector Signal Pin Definition LOUTR LINR LOUTL LINL MIC1R MIC1L 3.4.15 LVDS Connector Signal Pin Definition +V_LCD +V_LCD +V_LCD +V_LCD MIO-5152 User Manual...
  • Page 35 LVDS1_0_D0- LVDS1_1_D0- LVDS1_0_D0+ LVDS1_1_D0+ LVDS1_0_D1- LVDS1_1_D1- LVDS1_0_D1+ LVDS1_1_D1+ LVDS1_0_D2- LVDS1_1_D2- LVDS1_0_D2+ LVDS1_1_D2+ LVDS1_0_CLK- LVDS1_1_CLK- LVDS1_0_CLK+ LVDS1_1_CLK+ LVDS1_0_D3- LVDS1_1_D3- LVDS1_0_D3+ LVDS1_1_D3+ LVDS1_VCON MIO-5152 User Manual...

  • Page 36: Smb Connector

    3.4.16 SMB Connector Install the I2C driver manually  Go from Device Manager to System device. Then go to Intel® Serial IO I2C Controller #2 — 4B7A. Right click to update driver from the specified I2C driver folder. How to enable I2C ...

  • Page 37: Hdd Power Connector

    3.4.18 HDD Power Connector Signal Pin Definition 3.4.19 Panel Inverter Connector Signal Pin Definition +V12_1_INVERTER_0 LVDS1_Z_ENABKL EC_LVDS1_Z_PWM +V5_1_INVERTER_0 MIO-5152 User Manual...

  • Page 38: Gpio Connector

    3.4.20 GPIO Connector Signal Pin Definition SIO_GPIO7 SIO_GPIO2 SIO_GPIO6 SIO_GPIO1 SIO_GPIO5 SIO_GPIO0 SIO_GPIO4 +V5A_GPIO SIO_GPIO3 MIO-5152 User Manual...

  • Page 39: Power/Led/Case Open/Buzzer Connector

    3.4.21 Power/LED/Case Open/Buzzer Connector Signal Pin Definition BUZZER- BUZZER+ RDC_CASEOPEN SATA_EXT_LED# FP_A_PSIN# FP_A_RST# +3.3V MIO-5152 User Manual...

  • Page 40: Key B Connector

    3.4.22 Key B Connector Signal Pin Definition +V3.3_DUAL +V3.3_DUAL +V3.3_DUAL M2B1_POWER_OFF#_R USB2_M2B1_P4+ M2B1_W_DISABLE#_R USB2_M2B1_P4- M2B1_LED1# M2B1_I2S_SCLK +V3.3_DUAL M2B1_I2S_TXD M2B1_WAKE_WWAN# M2B1_R_I2S_RXD M2B1_SAR_DPR_WWAN M2B1_GNSS_DISABLE#_R MIO-5152 User Manual...
  • Page 41 M2B1_I2S_SFRM_R UIM_RESET UIM_CLK UIM_DATA UIM_PWR M2B1_SATA_DEVSLP_R PCIE5_RX- PCIE5_RX+ M2PCIE_M2SATA_TX- M2PCIE_M2SATA_TX+ M2B1_PLTRST# M2B1_CLKREQ2#_R M2B1_CLK- M2B1_PCIE_WAKE# M2B1_CLK+ M2B1_RESET#_R M2B1_SUSCLK +V3.3_DUAL +V3.3_DUAL +V3.3_DUAL +V3.3_DUAL MIO-5152 User Manual...

  • Page 42: Key E Connector

    +V3.3_DUAL 3.4.23 Key E Connector Signal Pin Definition +V3.3_M2E1 USB2_M2E1_P9+ +V3.3_M2E1 USB2_M2E1_P9- M.2_WLAN_LED1# BT_I2S_SCLK BT_I2S_BCLK BT_I2S_SDO MIO-5152 User Manual...
  • Page 43 BT_I2S_SDI M.2_BT_LED2 UART_BT_WAKE#_R M2E1_UART_RXD M2E1_UART_TXD M2E1_UART_CTS# M2E1_PCIE_TX+ M2E1_UART_RTS# M2E1_PCIE_TX- M2E1_PCIE_RX+ M2E1_PCIE_RX- M2E1_CLK+ M2E1_CLK- M2E1_SUSCLK M2E1_PLTRST# M2E1_Z_CLKREQ1# M2E1_BT_DISABLE#_R WLAN_PCIE_WAKE# M2E1_WIFI_OFF#_R TP_M2E1_38P4M_REFCLK PLTRST_M.2# MIO-5152 User Manual...

  • Page 44: Key M Connector

    M2E1_PCIE_WAKE1# +V3.3_M2E1 +V3.3_M2E1 3.4.24 Key M Connector Signal Pin Definition +V3.3_M.2 +V3.3_M.2 MIO-5152 User Manual...
  • Page 45 M.2_LED# +V3.3_M.2 +V3.3_M.2 +V3.3_M.2 +V3.3_M.2 MPCIE_MSATA_RX+ MPCIE_MSATA_RX- MPCIE_MSATA_TX- MPCIE_MSATA_TX+ PLTRST_MKEY_BUFFER# M.2_PCIE_WAKE# MIO-5152 User Manual...

  • Page 46: Rtc Battery Connector

    M2_SATA_2_1B_PEDET +V3.3_M.2 +V3.3_M.2 +V3.3_M.2 3.4.25 RTC Battery Connector Signal Pin Definition (Key M) +VBAT_R MIO-5152 User Manual...

  • Page 47: Ami Bios Setup

    Chapter AMI BIOS Setup...
  • Page 48 AMIBIOS has been integrated into many motherboards for over a decade. With the AMIBIOS Setup program, you can modify BIOS settings and control the various sys- tem features. This chapter describes the basic navigation of the MIO-5152 BIOS setup screens. AMI’s BIOS ROM has a built-in setup program that allows users to modify the basic system configuration.

  • Page 49: Entering Setup

    Entering Setup Turn on the computer and check for the patch code. If there is a number assigned to the patch code, it means that the BIOS supports your CPU. If there is no number assigned to the patch code, please contact an Advantech application engineer to obtain an up-to-date patch code file.

  • Page 50: Advanced Bios Features Setup

    4.1.2 Advanced BIOS Features Setup Select the Advanced tab from the MIO-5152 setup screen to enter the Advanced BIOS Setup screen. You can select any of the items in the left frame of the screen, such as CPU Configuration, to go to the sub menu for that item. You can display an Advanced BIOS Setup option by highlighting it using the <Arrow>...
  • Page 51 4.1.2.1 RC ACPI Settings Native PCIE Enable Enable/Disable PCIE Native Control reported in ACPI Table. Native ASPM Choose ASPM feature is controlled by OS or BIOS. MIO-5152 User Manual...
  • Page 52 4.1.2.2 CPU Configuration CPU Flex Ratio Override Enable/Disable CPU Flex Ratio Programming. Hardware Prefetcher This item allows users to enable or disable the hardware prefetcher feature. Adjacent Cache Line Prefetch This item allows users to enable or disable the adjacent cache line prefetch feature. Intel (VMX) Virtualization Technology When Enabled, a VMM can utilize the additional hardware capability provided by Vanderpool Technology.
  • Page 53 4.1.2.3 Power & Performance CPU – Power Management Control CPU – Power Management Control Options. GT – Power Management Control GT – Power Management Control Options. CPU - Power Management Control MIO-5152 User Manual...
  • Page 54 Boot Performance mode Select the performance state that the BIOS will set before OS handoff. Intel® SpeedStep® Allows more than two frequency ranges to be supported. Race to Halt (RTH) Enable/Disable Race to Halt feature. RTH will dynamically increase CPU frequency in order to enter pkg C-State faster to reduce overall power.
  • Page 55 Energy Efficient P-state Enable/Disable Energy Efficient P-state feature. Package Power Limit MSR Lock Enable/Disable locking of Package Power Limit 1 settings. Power Limit 1 Override Enable/Disable Power Limit 1 override. Power Limit 2 Override Enable/Disable locking of Package Power Limit 2 settings. Power Limit 2 Power Limit 2 value in Milli Watts.
  • Page 56 GT - Power Management Control  RC6(Render Standby) Check to enable render standby support. Maximum GT frequency Maximum GT frequency limited by user. Disable Turbo GT frequency Enabled/Disabled Turbo GT frequency. MIO-5152 User Manual...
  • Page 57 4.1.2.4 PCH-FW Configuration ME State When Disabled, ME will be put ME into Temporarily Disabled Mode. ME Unconfig on RTC Clear When Disabled, ME will not be unconfigured on RTC Clear. Core BIOS Done Message Enable/Disable Core BIOS Done message sent to ME. Firmware Update Configuration Configure Management Engine Technology Parameters.
  • Page 58 4.1.2.5 ACPI Settings Enable ACPI Auto Configuration Enable or disable BIOS ACPI auto configuration. Enable Hibernation Enables or disables the ability to hibernate (OS/S4 Sleep State). This option may not be effective with some OS. ACPI Sleep State Select the highest ACPI sleep state the system will enter when the SUSPEND button is pressed.
  • Page 59 4.1.2.6 NCT6126D Super IO Configuration Serial Port 1 Configuration Set Parameters of Serial Port 1. Serial Port 2 Configuration Set Parameters of Serial Port 2. Serial Port 3 Configuration Set Parameters of Serial Port 3. Serial Port 4 Configuration Set Parameters of Serial Port 4. Serial Port 5 Configuration Set Parameters of Serial Port 5.
  • Page 60 Serial Port 1 Configuration Serial Port Enable or disable Serial Port (COM). Change Settings Select an optimal settings for Super IO device. COM Mode COM port mode select. MIO-5152 User Manual...
  • Page 61 Serial Port 2 Configuration Serial Port Enable or disable Serial Port (COM). Change Settings Select an optimal settings for Super IO device. COM Mode COM port mode select. MIO-5152 User Manual...
  • Page 62 Serial Port 3 Configuration Serial Port Enable or disable Serial Port (COM). Change Settings Select an optimal settings for Super IO device. MIO-5152 User Manual...
  • Page 63 Serial Port 4 Configuration Serial Port Enable or disable Serial Port (COM). Change Settings Select an optimal settings for Super IO device. MIO-5152 User Manual...
  • Page 64 Serial Port 5 Configuration Serial Port Enable or disable Serial Port (COM). Change Settings Select an optimal settings for Super IO device. MIO-5152 User Manual...
  • Page 65 Serial Port 6 Configuration Serial Port Enable or disable Serial Port (COM). Change Settings Select an optimal settings for Super IO device. MIO-5152 User Manual...
  • Page 66 4.1.2.7 NCT6126D HW Monitor Smart Fan Function Enable or Disable Smart Fan. Smart Fan Function Enable or Disable Smart Fan. Digital I/O Configuration Configure the digital I/O Pins. ACPI CPU Shutdown Temperature Select the Critical Temperature value that OSPM must shutdown the system. Case Open Detection Enable or Disable Case Open Detect Function.
  • Page 67 Smart Fan Function System Fan Mode System Fan Mode Select. SYSFAN Temperature 1 Input the System Smart Fan IV Temperature 1. SYSFAN DC/PWM 1 Input the System Smart Fan IV DC/PWM 1 Value. SYSFAN Temperature 2 Input the System Smart Fan IV Temperature 2. SYSFAN DC/PWM 2 Input the System Smart Fan IV DC/PWM 2 Value.
  • Page 68 Digital I/O Configuration Digital I/O Pin 1/2/3/4/5/6/7/8 Configure Digital I/O Pin. MIO-5152 User Manual...
  • Page 69 4.1.2.8 Trusted Computing Security Device Support Enable or disable BIOS support for security device. SHA-1 PCR Bank Enable or disable SHA-1 PCR Bank. SHA256 PCR Bank Enable or disable SHA256 PCR Bank. SHA384 PCR Bank Enable or Disable SHA384 PCR Bank. Pending operation Schedule an operation for the security device.
  • Page 70 4.1.2.9 S5 RTC Wake Settings Wake system from S5 Enable or disable System wake on alarm event. Select FixedTime, system will wake on the hr:min:sec specified. MIO-5152 User Manual...
  • Page 71 4.1.2.10 Serial Port Console Redirection Console Redirection This item allows users to enable or disable console redirection for Microsoft Windows Emergency Management Services (EMS). Console Redirection This item allows users to configure console redirection detail settings. MIO-5152 User Manual...
  • Page 72 4.1.2.11 USB Configuration Legacy USB Support Enables Legacy USB support. AUTO option disables legacy support if no USB devices are connected. DISABLE option will keep USB devices available only for EFI applications. XHCI Hand-off This is a workaround for OS without XHCI hand-off support. The XHCI ownership change should be claimed by XHCI driver.
  • Page 73 4.1.2.12 Network Stack Configuration Network Stack Enable/Disable UEFI Network Stack. 4.1.2.13 NVMe Configuration MIO-5152 User Manual...

  • Page 74: Chipset Configuration

    4.1.3 Chipset Configuration Select the Chipset tab from the MIO-5152 setup screen to enter the Chipset BIOS Setup screen. You can display a Chipset BIOS Setup option by highlighting it using the <Arrow> keys. All Plug and Play BIOS Setup options are described in this sec- tion.
  • Page 75 4.1.3.1 System Agent (SA) Configuration Memory Configuration Memory Configuration parameters. Graphics Configuration Graphics Configuration parameters. VT-d VT-D capability. X2APIC Opt Out Enable/Disable X2APIC Opt Out Bit. IGD VTD Enable Enable/Disable IGD VTD. Above 4GB MMIO BIOS assignment Enable/Disable above 4GB Memory Mapped IO BIOS assignment. MIO-5152 User Manual...
  • Page 76 Memory Configuration Max TOLUD Maximum value of TOLUD. SA GV System Agent Geysetville. Enable RH Prevention Actively prevent Row Hammer. Power Down Mode CKE Power Down Mode Control. Page Close Idle Timeout Page Close Idle Timeout Control. Memory Scrambler Enable/Disable Memory Scrambler support. Force ColdReset Force ColdReset OR Choose MrcColdBoot mode.
  • Page 77 Graphics Configuration Graphics Turbo IMON Current Graphics turbo IMON current values supported. GTT Size Select the GTT Size. Aperture Size Select the Aperture Size. PSMI Support Enable/Disable PSMI. DVMT Pre-Allocated Select DVMT 5.0 Pre-Allocated (Fixed) Graphics Memory size used by the Internal Graphics Device.
  • Page 78 Boot Display Control NXP Non-EDID Support NXP non-EDID support. Color Depth & Data Packing Color depth and data packing format for Non-EDID support. Dual LVDS Mode Select LVDS bus to single bus mode or dual bus mode. LVDS Panel Type This item allow user to select LVDS panel resolution type.
  • Page 79 4.1.3.2 PCH-IO Configuration PCI Express Configuration PCI Express Configuration settings. SATA Configuration SATA device options settings. USB Configuration USB Configuration settings. Security Configuration Security Configuration settings. HD Audio Configuration HD Audio susbsystem configuration settings. SerialIO Configuration SerialIO configuration settings. Onboard LAN1 Controller Select to Enable or Disable Onboard LAN1 Controller.
  • Page 80 PCI Express Configuration DMI Link ASPM Control This item controls Active State Power Management of the DMI Link. Port8xh Decode PCI Express Port8xh Decode Enable/Disable. Peer Memory Write Enable Peer Memory Write Enable/Disable. PCH PCI Express Clock Gating Enable/Disable PCH PCI Express Clock Gating For Each Root Port. PCIe function swap When Disabled, prevents PCIE root port function swap.
  • Page 81 SATA Configuration SATA Controller(s) Enable/disable SATA device. SATA Mode Selection Determine how SATA controller operate. Aggressive LPM Support Enabled PCH to aggressively enter link power state. SATA Controller Speed Indicates the maximum speed the SATA controller can support. MIO-5152 User Manual...
  • Page 82 USB Configuration XHCI Compliance Mode Option to enable Compliance Mode. USB3 Link Speed Selection This option is to select USB3 Link Speed GEN1 or GEN2. USB PDO Programming Select “Enabled” if Port Disable Override functionality is used. USB Overcurrent Select “Disabled” for pin-based debug. USB Overcurrent Lock Select “Enabled”...
  • Page 83 Security Configuration RTC Memory Lock Enable will lock bytes 38h-3Fh in the lower/upper 128-byte bank of RTC RAM. BIOS Lock Enable or Disable the PCH BIOS Lock Enable feature. Force unlock on all GPIO pads If Enabled BIOS will force all GPIO pads to be in unlock state. MIO-5152 User Manual...
  • Page 84 HD Audio Configuration HD Audio Control detection of the HD-Audio device. Disabled = HDA will be unconditionally dis- abled. Enabled = HDA will be unconditionally enabled. MIO-5152 User Manual...
  • Page 85 Serial IO Configuration I2C0 Controller Enable/Disables Serial IO Controller. MIO-5152 User Manual...

  • Page 86: Security

    4.1.4 Security Select security setup from the MIO-5152 setup main BIOS setup menu. All Security setup options, such as password protection and virus protection are described in this section. To access the sub menu for the following items, select the item and press <Enter>: Change Administrator / User Password Select this option and press <ENTER>...

  • Page 87: Boot

    4.1.5 Boot Setup Prompt Timeout Number of seconds that the firmware will wait before initiating the original default boot selection. A value of 0 indicates that the default boot selection is to be initiated immediately on boot. A value of 65535(0xFFFF) indicates that firmware will wait for user input before booting.

  • Page 88: Save & Exit

    4.1.6 Save & Exit Save Changes and Exit This item allows you to exit system setup after saving the changes. Discard Changes and Exit This item allows you to exit system setup without saving any changes. Save Changes and Reset This item allows you to reset the system after saving the changes.

  • Page 89: System Assignments

    Appendix System Assignments This appendix contains detailed information. Sections include:  System I/O Ports  DMA Channel Assignments  1st MB Memory Map  Interrupt Assignments...

  • Page 90: System I/O Ports

    System I/O Ports Table A.1: System I/O Ports Addr. Range (Hex) Device 00h-1Fh DMA Controller 20h-2Dh Interrupt Controller 2Eh–2Fh Motherboard resources 30h-3Dh Interrupt Controller 40h-43h Timer/Counter 4Eh–4Fh Motherboard resources 50h-53h Timer/Counter 60h-6Fh 8042 (keyboard controller)/NMI Controller/Microcontroller 70h-7Fh Real-time Controller 80h-8Fh Debug Port/Reserved 90h-9Fh Debug Port/Reset Generator...

  • Page 91: Dma Channel Assignments

    DMA Channel Assignments Table A.2: DMA Channel Assignments Channel Function Available Available Available Available Direct Memory Access Controller Available Available Available 1st MB Memory Map Table A.3: 1st MB Memory Map Addr. Range (Hex) Device E0000h - FFFFFh System Board D0000h - DFFFFh PCI Bus C0000h - CFFFFh...
  • Page 92 www.advantech.com Please verify specifications before quoting. This guide is intended for reference purposes only. All product specifications are subject to change without notice. No part of this publication may be reproduced in any form or by any means, electronic, photocopying, recording or otherwise, without prior written permis- sion from the publisher.
  • Page 93 Our company network supports you worldwide with offices in Germany, Austria, Switzerland, the UK and the USA. For more information please contact: Headquarters Germany FORTEC Elektronik AG Augsburger Str. 2b 82110 Germering Phone: +49 89 894450-0 E-Mail: info@fortecag.de Internet: www.fortecag.de Fortec Group Members Austria Distec GmbH Office Vienna...
