双层自动合缝机
Automatic Denim Pocket Setter
（MB3005B-PS- EXT3216H）
使用说明书
Instruction Manual
常州智谷机电科技有限公司
CHANGZHOU WISDOM & VALLEY ELECTRICAL TECHNOLOGY CO.,LTD
在使用本设备之前请先阅读本使用说明书
Please read the operation manual of the touch
screen interface before using the device
请将本使用说明书放在便于查阅的地方保管
Please keep this operation manual of touch screen
版本信息/ Version
interface in convenient place for referenc
2021.01
Advertisement
Table of Contents
Summary of Contents for Wisdom MB3005B
- Page 1 Automatic Denim Pocket Setter （MB3005B-PS- EXT3216H） 使用说明书 Instruction Manual 常州智谷机电科技有限公司 CHANGZHOU WISDOM & VALLEY ELECTRICAL TECHNOLOGY CO.,LTD 在使用本设备之前请先阅读本使用说明书 Please read the operation manual of the touch screen interface before using the device 请将本使用说明书放在便于查阅的地方保管 Please keep this operation manual of touch screen 版本信息/ Version...
- Page 2 We are happy to receive suggestions and/or indications on ways we could improve this manual. 本机介绍说明分为两部分，具体请参照《MB3005B 双层自动合缝机-使用说明书》、《MB3005B 双层 自动合缝机-零件手册》。 The introduction of this machine is divided into three parts. For details, please refer to 《MB3005B Operation manual》 and 《MB3005B Parts Manual》 《MB3005B Touch screen interface operation instructions》...
- Page 3 ENGLISH...
-
Page 4: Table Of Contents
Catalog 1、Basic information of the equipment....................1 1.1.Basic information of equipment....................1 2、Technical parameters of equipment....................2 3、Safety precautions..........................3 4、Key function description........................5 4.1.Button function description..................... 5 5、Operating instructions......................... 7 5.1.Preparation before operation....................7 5.2.Operation process description....................7 6、Debugging method............................10 6.1.Interface description....................... -
Page 5: 1、Basic Information Of The Equipment
1、Basic information of the equipment 1.1.Basic information of equipment 1：PS-EXT3216H Machine head； 2：Seamer device； 3：Dust collecting device； 4：Control box； 5：Pedal； 6: Screen... -
Page 6: 2、Technical Parameters Of Equipment
2、Technical parameters of equipment MB3005B Side seamer Machine head PS-EXT3216H Maximum sewing speed/rpm 5000 Voltage/V AC220 Working pressure/Mpa Stitch length/mm Size/mm 1270L×890W×1270H Weight/kg... -
Page 7: 3、Safety Precautions
3、Safety precautions Considerations for safe use of automata 1. In order to prevent accidents caused by electric shock, please do not open the cover of the electrical box of the motor or touch the parts in the electrical box when the power is connected. 1. - Page 8 be careful not to pinch your fingers. 17. During folding operation, please be careful not to clip the cylinder to your finger when putting your finger into the folding machine. * important safety information: √ improper operation of the machine may cause personal injury. Please read this instruction carefully and operate correctly before operation.
-
Page 9: 4、Key Function Description
4、Key function description 4.1.Button function description （1）：Power switch: ventilate and power on the equipment after 90 ° rotation。 （2）：Pedal: sewing in front and lifting in back。 （3）：Microswitch: 1.1-2 sewing mechanism moves left or right after touching （4） : button --- button green light display button or micro switch can be used, press the button 1.1-2 to move the sewing mechanism left or right. - Page 10 a. Welcome interface b. Monitoring interface...
-
Page 11: 5、Operating Instructions
5、Operating instructions 5.1.Preparation before operation √ The machine head shall be in the stop state when the operator checks it √ Check whether the sewing thread has been put on correctly √ Check whether the needle has been installed √ Clean the sundries on the machine table to ensure that there are no sundries hindering the operation of the machine √... - Page 12 the micro switch with your foot to move the sewing mechanism to the right； 剪线吸风口 3) 3) When the front pedal is sewed to the position shown in the figure below, the sewing is completed, the air suction stops and the presser foot is raised. (Note: since the cutting thread is located behind the feeding tooth, the cutting piece needs to be sent to the rear of the cutting thread suction for the convenience of cutting thread)
- Page 13 c. Crotch position：Click turn to green 1) Step back on the pedal to lift the presser foot，Place the cloth in the work area， Step forward to the position shown in the figure below and stop，Touch the microswitch with your foot, and the sewing mechanism moves to the left (as shown in the figure below)；...
-
Page 14: 6、Debugging Method
6、Debugging method 6.1.Interface description 、 、 The function is shown in 5.2 operation process description； represent 、 automatic switching of two power sequences； Adjust the current maximum speed of the head； Click this button to open the interface shown in 6.2； Input and output detection interface, click this button to pop up the interface as shown in the figure below。... -
Page 15: Parameter Setting
6.2.Parameter setting P-11：Adjust the maximum rotation speed of the sewing end section； P-12：Adjust the number of stitches at low speed； P-13：Adjust the number of spacing needles from cloth off photoelectric switch to dust cleaning off； P-14：Adjust the number of stitches between the cloth leaving the photoelectric switch and the machine head closing under the automatic sewing state；... -
Page 16: Adjustment
6.4.Adjustment Limit block Adjust the left and right position of the limit block according to the size of the binding。... -
Page 17: 7、Electrical Wiring
7、Electrical wiring 7.1.Electronic control panel：... -
Page 18: Air Control Chart
7.2.Air control chart ：... -
Page 19: 8、Common Problems And Solutions
8、Common problems and Solutions 8.1. See the table below for common problems and Solutions Phenomenon Image Cause Analysis Solutions Adjust the stop The position of limit Over bound position according block is to the left to step 6.2 9、Daily maintenance requirements 9.1. -
Page 20: 10、Knowledge Product Protection Statement
10、Knowledge product protection statement MB3005B Side seamer was designed by Changzhou wisdom & valley Electric Technology Co., Ltd.。The intellectual property rights of this achievement belong to Changzhou wisdom & valley Electric Technology Co., Ltd. and are protected by national intellectual property laws and regulations.
