Summary of Contents for Silent Angel Bremen B2
- Page 1 Quick Start Guide Bremen B2...
-
Page 2: Table Of Contents
Catalog Catalog Package Contents Front Panel Rear Panel Signal Connections Audio Applications Power Connection Power On Install “VitOS Lite” App on a Pad or Phone Using iOS device to connect Using Android device to connect Bluetooth Connection Use Another Device to Connect Bluetooth... -
Page 3: Package Contents
Package Contents B2 x1 Power Cord x1 Dual RCA Audio Cable x1 Quick Start Guide x1 Warranty Card x1... -
Page 4: Front Panel
Front Panel ① ② ③ ④ ⑤ ⑥ ⑦ ① Previous Track Button When you touch the previous song button，the current playing song will switch to the previous song in the playlist ② Pause / Play Button When you touch the pause button, the current playing song will pause When you touch the play button, the song will start playing On / Off light bar button When the light bar is on, press and hold for 3 seconds to turn it off. -
Page 5: Rear Panel
Rear Panel AC INPUT ON / OFF DIGITAL OUTPUT ANALOG OUTPUT M-IO For continued protection against risk of fire,replace ONLY AES / EBU with fuse of the specified type and current ratings. COAXIAL RESET FUSE TYPE: T0.5A250VAC ⑰ ⑧ ⑨ ⑩... - Page 6 ⑬ COAXIAL Port Digital audio output, via 75 ohm coaxial cable transmitting S / PDIF digital audio signal ⑭ RCA (L+R) Port Analog audio output，with AC 2V ⑮ M-IO Port For expansion peripherals ⑯ Reset Button Wi-Fi Connection Mode： Short press：switch to Bluetooth mode Press and hold for more than 5 second：reset Wi-Fi settings to default Bluetooth Connection Mode：...
-
Page 7: Signal Connections
Signal Connections Make sure all audio devices are powered off. B2 supports Wi-Fi and Fast Ethernet connections. Therefore, when it’s connected to Ethernet network, Wi-Fi connection will be turned off; when it’s not connected to Ethernet network, the Wi-Fi connection will turn on ①... -
Page 8: Audio Applications
Audio Applications ① Headphone ② Active Speaker... - Page 9 ③ Speaker AES / EBU COAXIAL AES / EBU COAXIAL Amplifier...
- Page 10 ④ Headphone AES / EBU COAXIAL AES / EBU COAXIAL Headphone Amplifier...
-
Page 11: Power Connection
Power Connections AC INPUT ON / OFF DIGITAL OUTPUT ANALOG OUTPUT M-IO For continued protection against risk of fire,replace ONLY AES / EBU with fuse of the specified type and current ratings. COAXIAL RESET FUSE TYPE: T0.5A250VAC Power Cord AC Outlet Power On AC INPUT ON / OFF... -
Page 12: Install "Vitos Lite" App On A Pad Or Phone
Install “VitOS Lite” App on a Pad or Phone Use below QR code to install “VitOS Lite” app on a pad or phone. -
Page 13: Using Ios Device To Connect
With Fast Ethernet Connection Found B2 in Press "Browse" to "Devices" page enter main menu With Wi-Fi Connection Use the VitOS Lite to discover and setup the Wi-Fi setting of Bremen B2. Press Press Press "Add Device" "OK" "Allow Once"... - Page 14 Press Enter password Press "Indicator is blinking" and press "Next" "Setup this device" Indicator Found B2 in Press"Browse" to Wait for B2 to connect "Devices" page enter main menu to the Wi-Fi network...
-
Page 15: Using Android Device To Connect
② Using Android device to connect With Fast Ethernet Connection Press "Browse" to Finding B2 in enter main menu "Device" page With Wi-Fi Connection Searching and configuring Bremen B2’s Wi-Fi settings with VitOS Lite Press "OK" Press "Add Device"... - Page 16 Press "OK" Press "Once" Press "indicator is blinking" Press "Setup this device"...
- Page 17 Enter Wi-Fi password, Wait for the connection then press "Next" completed Finding B2 in Press "Browse" to "Device" page enter main menu...
-
Page 18: Bluetooth Connection
Bluetooth Connection After processing,go to "Setting" on your phone to discover and connect Press "Bluetooth" to setup the available "Bremen B2 XXXX" Press the "RESET" button on the rear panel, and hold for 5 seconds 00:05 AC INPUT ON / OFF... -
Page 19: Use Another Device To Connect Bluetooth
Use Another Device to Connect Bluetooth Go to "Setting" on your phone to Press "Bluetooth" to discover Bluetooth Device enter Bluetooth mode "Bremen B2 XXXX" and connect Press the "RESET" button at rear panel, and hold for 5 seconds to process 00:05... - Page 20 Trademark Attribution Notice Windows is a trademark or registered trademarks of Microsoft Corporation in the United States and other countries. iOS is a trademark or registered trademark of Cisco in the U.S. and other countries.Android is a trademark of Google LLC, registered in the U.S. and other countries.Mac and macOS are trademarks of Apple Inc., registered in the U.S.
