Summary of Contents for Ecler essentials eSAM402
- Page 1 ANALOGUE MIXER Installation Analogue Mixer USER MANUAL 50-0296-0104 eSAM402 EN...
-
Page 2: Table Of Contents
INDEX IMPORTANT REMARK......................3 IMPORTANT SAFETY INSTRUCTIONS ................3 IMPORTANT NOTE ........................5 INTRODUCTION ........................5 INSTALLATION.......................... 6 INPUTS ............................7 OUTPUTS ............................ 8 STARTING UP ..........................9 EQUALIZATION ......................... 9 VU-METER ..........................9 GROUND LOOPS, BACKGROUND NOISE ................. 9 CLEANING .......................... -
Page 3: Important Remark
IMPORTANT REMARK The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance. - Page 4 9. Do not defeat the safety purpose of the polarized or grounding type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety.
-
Page 5: Important Note
Technical Services. Ecler eSAM402 comes with a 3-year warranty. INTRODUCTION The eSAM402 is an easy-to-use professional mixer designed for PA applications. Its main features are: • 3 MIC/LINE STEREO input channels. • 1 fourth STEREO LINE input channel •... -
Page 6: Installation
INSTALLATION The eSAM402 mixer has been specially designed to be installed in a standard 19" rack, taking up 1U. It has been designed to be operated by non-technical users. This is the reason why its tone controls are adjustable only with a screwdriver. On the opposite, input and output level controls use classic and easily accessible rotary knobs. -
Page 7: Inputs
INPUTS The eSAM402 supports two types of audio signals for each of its first three inputs (mono MIC or stereo LINE), selectable by a MIC/LINE switch on the rear panel: Microphone signal: 3 mixing channels offer a Euroblock connector for a nominal input level from –50dBV (3.16mV) to –20dBV (0.1mV), with a GAIN control on the rear panel... -
Page 8: Outputs
OUTPUTS The eSAM402 has a main stereo output (OUT L / OUT R), with electronically balanced Euroblock connectors. Connection is made according to the following diagram: The mixer's main output level (OUTPUT VOL) must be set in order to avoid your system power amp clipping indicators (CLIP) to be permanently lit. -
Page 9: Starting Up
This is directly done via the POWER mains switch. Even is the power-up noise of eSAM402 is minimal, we highly recommend to power up all equipment in the following order: sound sources, mixing units, equalizer, processors and finally power amplifiers. -
Page 10: Cleaning
the signal entering the mixing amplifier is weak, but even so it contains a background noise, so the signal/noise ratio is low (low signal). When the output amplifier equally amplifies both parts as a whole, the output has a very high background noise. In the second case, as the channel VOL control is set to the maximum, the signal received by the mixing amplifier has a high level and therefore also a high (good) signal/noise ratio, so when this signal reaches the output VOL control and is amplified, the signal/noise... -
Page 11: Diagram And Function List
DIAGRAM and FUNCTION LIST 1 Channel volume control, VOL 10 Micro input, MIC 2 Talkover switch, TK 11 Micro line selector 3 Bass control, BASS 12 Line input, LINE 4 Midrange control, MID 13 Input sensitivity adjust, ADJ 5 Treble control, TREBLE 14 Recording output, AUX/REC 6 Output main volume control, OUTPUT 15 Mono-stereo switch, L+R... -
Page 12: Configuration Diagram
CONFIGURATION DIAGRAM... -
Page 13: Block Diagram
BLOCK DIAGRAM... -
Page 14: Technical Characteristics
TECHNICAL CHARACTERISTICS eSAM402 Inputs Sensitivity (*) / Impedance LINE (1-3) 0dBV / 50kΩ LINE 4 -6dBV* / 50kΩ MIC 1-3 BAL 35dBV/>1kΩ Input sensitivity adjust MIC/LIN 1-3 ±15dB Outputs Level / Minimum load 0(+6)dBV */ 600Ω AUX/REC 0dBV/10kΩ Frequency response... - Page 15 product characteristics subject variation production tolerances. NEEC AUDIO BARCELONA S.L. reserves the right to make changes or improvements in the design or manufacturing that may affect these product specifications. For technical queries contact your supplier, distributor or complete the contact form on our website, Support / Technical requests.
