Summary of Contents for Touch Dynamic QK22
- Page 1 USER MANUAL VERSION 1.0 June 2020 QK22 Panel PC...
- Page 2 Copyright 2020 All Rights Reserved Manual Version 1.0 The information contained in this document is subject to change without notice. We make no warranty of any kind with regard to this material, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose. We shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material.
- Page 3 Sécurité INSTRUCTIONS IMPORTANTES RELATIVES À LA SECURITE 1. Pour débrancher la machine de l’alimentation électrique, éteignez l’interrupteur d’alimentation et retirez le cordon d’alimentation de la prise murale. La prise murale doit être facilement accessible et à proximité de la machine. 2.
- Page 4 CAUTION ON LITHIUM BATTERIES There is a danger of explosion if the battery is replaced incorrectly. Replace only with the same or equivalent type recommended by the manufacturer. Discard used batteries according to the manufacturer’s instructions. Battery Caution Risk of explosion if battery is replaced by an incorrectly type. Dispose of used battery according to the local disposal instructions.
- Page 5 Pour équipements mobiles ayant une masse totale supérieure à 18 kg et pour tous les équipements FIXES : Les matériaux d’un équipement coupe-feu dans l’épaisseur de paroi retenue la plus significativement mince, doivent être des matériels de CLASSE V-1, doivent être de classe Matériel 5VB ou doivent passer le test de l’article A.1 LEGISLATION AND WEEE SYMBOL 2012/19/EU Waste Electrical and Electronic Equipment Directive on the treatment,...
- Page 6 Revision History Changes to the original user manual are listed below: Revision Description Date • Initial release June 2020...
-
Page 7: Table Of Contents
Table of Contents 1. Packing List ........1 1-1. Standard Items ..............1 1-2. Optional Items ..............2 2. System View ........3 2-1. Front & Side View ............3 2-2. Rear View .................3 2-3. I/O view ................4 2-4. Dimensions ..............5 3. System Assembly ......6 3-1. - Page 8 The page is intentionally left blank . viii...
-
Page 9: Packing List
Packing List 1-1. Standard Items a. System b. Power adapter c. Power cord d. RJ45-DB9 cable (x2, provided only for Kabylake/Skylake motherboard ) Note: Power cord will be supplied differently according to various region or country. -
Page 10: Optional Items
1-2. Optional Items... -
Page 11: System View
System View 2-1. Front & Side View 1. Touch screen 2. Built-in web cam 3. MSR cable hole 2-2. Rear View 4. VESA mounting holes 5. Safety label 6. Cable cover... -
Page 12: I/O View
2-3. I/O view Skylake/Kabylake Motherboard Item No. Description Mic in Line out COM4 USB 2.0(x2) COM port 1, 2, 3 (from left to right) DC in Power button DVI-D HDD slot USB 3.0(x4) Android Qualcomm Motherboard f g h Item No. Description USB 2.0(x2) USB 3.0(x2) -
Page 13: Dimensions
2-4. Dimensions 536mm 48mm... -
Page 14: System Assembly
System Assembly 3-1. Open the Chassis Cover The motherboard and RAM module can be replaced by opening the chassis cover, which is located on the back side of the system. Please follow the steps below to open the chassis cover. 1. -
Page 15: Ram Module Replacement
3-2. RAM Module Replacement To remove and replace the RAM module, please open the chassis cover firstly as steps dscribed in chapter 3-1. Removing a RAM module 1. Find the memory slot at the right side of the motherboard. (Refer to Chapter 5-1-1). -
Page 16: Hdd Replacement
3-3. HDD Replacement To remove and replace the HDD, please open the cable cover firstly as stpes dscribed in chapter 3-1-1. 1. Find the HDD located at the right side. 2. Pull the HDD tray from the system. For easier removal pull the plastic sheet (see picture) at the same time. -
Page 17: Specification
Specification Model Name QK22 Mainboard Skylake/Kabylake Android Intel SKYLAKE/Kabylake U CPU Celeron 3955U 2GHz, LLC 2M (15W) Qualcomm Snapdragon 450 i3-6100U/7100u 2.3GHz, LLC 3M Octa-core A53 (64bit) 8*1.8GHz i5-6300U/7200u 2.4GHz Chipset SoC built-in CPU DDR3L1600MHz (8GB Max), System memory 3GB LPDDR3... - Page 18 Model Name QK22 Mainboard Skylake/Kabylake Android Audio Speaker 2 x 2W Communication WiFi 802.11 b/g/n/ac WLAN card IEEE 802.11 a/b/g/n/ac Power Power adapter DC 19V / 90W DC 19V / 65W Environment EMC & Safety FCC/CE Class A/LVD/EN 60601-1-2 FCC, Class A, CE, LVD Operating temperature 0°C ~ 35°C (32°F ~ 95°F)
-
Page 19: Configuration
Configuration 5-1. Skylake/Kabylake Motherboard 5-1-1. Motherboard Layout SATA1 USB3 RJ45_1 SATA0 CN21 USB2 SKT1 CN19 CN22 CN15 USB1 CN23 MINI_PCIE1 CN10 CN20 SKT2 JP1 CN4 CN24 DDR3_A1 CN17 CN25... -
Page 20: Connectors & Functions
5-1-2. Connectors & Functions Connector Function Front I/O board Inverter connector LVDS connector HDD LED connector USB connector System FAN connector LPT port connector Smart device connector Debug port CN10 Speaker & MIC connector CN11 40 pin external connector CN12 Audio connector(right) CN13 Audio connector(left) -
Page 21: Jumper Setting
5-1-3. Jumper Setting Cash Drawer Power Setting Function ▲ +19V +12V COM1/COM2/COM3 Power Setting COM1, COM2 and COM3 can be set to provide power to your serial device. The voltage can be set to +5V or +12V in the BIOS. 1. - Page 22 LCD ID Setting LVDS Output Panel# Resolution Bits Channel Interface LVDS 800 x 600 Single Panel LVDS 800 x 600 Single Panel LVDS 1024 x 768 Single Panel LVDS 1024 x 768 Single Panel LVDS 1366 x 768 Single Panel LVDS 1366 x 768 Single...
-
Page 23: F16 Motherboard
5-2. Android Motherboard 5-2-1. Motherboard Layout CN40 CN32 CN10 CN24 CN10 CN33 CN16 CN17 CN19 CN18 CN20 CN21 CN22 COM1 COM2 FEDP1 USB3 RJ11_1 USB1 RJ45_1 USB2 PWR1/ PWR2... -
Page 24: Connectors & Functions
5-2-2. Connectors & Functions Connector Function Main display connector 40pin external connector Power LED connector MCU debug connector 2nd display connector Speaker_R connector WIFI 5G connector Speaker_L connector CN10 SATA power connector CN13 WIFI 2.4G connector CN16/18/19 USB port (internal) connector CN17 Front USB connector CN20... -
Page 25: Jumper Setting
5-2-3. Jumper Setting Speaker Watt Setting Function with FeDP cable ▲ without FeDP cable Speaker R/L Setting Function ▲R/L separated (two speakers) USB1.1 Jumper open Jumper short ▲ = Manufacturer Default Setting... - Page 26 COM1/COM2 Power Setting COM1 and COM2 can be set to provide power to your serial device. The voltage can be set to +5V or +12V by setting the Android APPS. 1. Enter APPS and double click on ComPowerSwitch. 2. To enable the power, pull the drop down menu to select the power for COM1 or COM2.
