Kramer K-CamHD Quick Start Manual

Scan for full manual
Step 1: Check what's in the box
K-CamHD PTZ Camera
Remote control transmitter with batteries
Power adapter and cord

Step 2: Get to know your K-CamHD

Step 3: Mount K-CamHD

You can mount K-CamHD on the wall, the ceiling or place it on a tabletop. The built-in gravity sensor automatically corrects the image orientation.
• Ensure that the environment (e.g., maximum ambient temperature, humidity & air flow) is compatible for the device.
• Avoid exposing the product to direct sunlight or any other heat source.
• Keep away from children – product includes small accessories and components.
• Avoid uneven mechanical loading.
• Do not insert any sharp objects into the product.
• Avoid dropping or hitting the product to avoid damaging the product.
• For maintenance, call tech support.
To attach K-CamHD onto a wall:
1. Find the correct location on the wall.
2. In the desired location, mark the hole locations, then
drill 4 holes 82mm and 60mm apart (using a 6mm
drill-bit) to fit the 4 holes of the wall-mounting bracket.
3. Insert the four expansion-plugs into the holes.
K-CamHD Quick Start
K-CamHD Quick Start Guide
This guide helps you install and use your
Go to www.kramerav.com/downloads/K-CamHD
upgrades are available.
4. Attach the wall bracket to the wall, using the four wall-
bracket screws.
Note that you can also attach the device upside
down, from under the bracket.
K-CamHD for the first time.
to download the latest user manual and check if firmware
Lens cover
Wall bracket
Screws set
# Feature
1 Camera
2 Tilting Mechanism
3 STANDBY LED
4 POWER LED
5 USB 3 Type B Port
6 LINE IN
7 RS-232 8- IN
pin DIN
Connectors
8 OUT Connect to a device with an RS-232 port
9 12V DC Power
Connector
P/N: 2 9 0 0 - 3 0 1 5 2 9 QS
1 USB 3.0 cable
1 Quick start guide
Function
High quality Camera.
Can be set to any of 255 preset positions.
Lights green when the camera is in
standby mode.
Lights blue when the power is on.
Connect to a PC.
Connect to a microphone.
Connect to a device with an RS-232 port
(for example, a system controller).
(for example, a camera).
Press and hold to toggle the
locking/release of the front panel buttons.
When storing or recalling presets, press to
store or recall the preset.
5. Attach the device to the wall bracket by fitting the
mortise (on the bracket) into the tenon (on the
camera).
6. Fix the camera by screwing (A) Nickel screw to the
center and (B) then tighten with 3 black screws.
Rev: 2
