EZ DCIT-0010-DC Quick Start Manual

ITEM #DCIT 0010 DC & #DCIT 0011 DC
EZ Digital Timer
Programming Guide
GETTING STARTED
1 Pull the sticker o the screen
2 Plug the timer into a grounded electrical outlet for 30
minutes to charge the battery
3 After 30 minutes, remove the timer from the outlet and
move to Step 1
STEP 1: TURN TIMER ON/OFF
DCIT 0010 DC
TIMER ON REPEAT OFF
DELAY START RUN TIME
DELAY START ON/OFF REPEAT RUN TIME
Reset
DCIT 0011 DC
TIMER ON REPEAT OFF
DELAY START RUN TIME
RANDOM DELAY START ON/OFF REPEAT RUN TIME
Use the ON/OFF button to switch between TIMER ON and Use the ON/OFF button to switch between TIMER ON and
TIMER OFF modes. TIMER OFF modes.
TIMER ON: when set to on, the timer will turn on/o the device TIMER ON: when set to on, the timer will turn on/o the device
plugged into the timer as programmed. plugged into the timer as programmed.
TIMER OFF: when set to o , the timer will not control the device TIMER OFF: when set to o , the timer will not control the device
plugged into the timer and the power in the outlet will remain plugged into the timer and the power in the outlet will remain
constant. constant.
STEP 2: SET DELAY START
DCIT 0010 DC
TIMER ON
DELAY START
DELAY START ON/OFF
Press the DELAY START button to set when the timer will turn on.
Each press of the button increases the delay by 1 minute. Press and
hold the button to scroll fast. Set from instantly on (00:00) up to a 24
hour delay (24:00).
Example: The current time is 7:30AM. You want the device plugged
into the timer to turn on at 6:30PM. Set the "DELAY START" to 11:00
(eleven hours from when you program the timer).
Countdown to when the timer will start begins 5 seconds after being set.
STEP 3: SET RUN TIME
DCIT 0010 DC
TIMER ON
DELAY START
DELAY START ON/OFF
Reset
Press the RUN TIME button to set how long you want the device
Reset
plugged into the timer to be on (after the delay start countdown is
over).
Each press of the button increases the run time by 1 minute. Press
and hold the button to scroll fast. Set from 1 minute (00:01) up to
24 hours (24:00).
Example: The Run Time is set for 4 hours. When the program is
activated, the RUN TIME will count down from 4:00 down to 00:00. The
words RUN TIME will ash during the countdown.
When the timer display shows 00:00 the Run Time icon will stop
ashing and the device that is plugged into the timer will turn o .
DCIT 0011 DC
TIMER ON REPEAT OFF
REPEAT OFF
RUN TIME
DELAY START RUN TIME
REPEAT RUN TIME
RANDOM DELAY START ON/OFF REPEAT
Reset
DCIT 0011 DC
TIMER ON REPEAT OFF
REPEAT OFF
RUN TIME
DELAY START RUN TIME
REPEAT RUN TIME
RANDOM DELAY START ON/OFF REPEAT
REPEAT MODE
DCIT 0010 DC
TIMER ON REPEAT OFF
DELAY START RUN TIME
DELAY START ON/OFF REPEAT RUN TIME
RUN TIME
Reset
Reset
To make the program repeat daily at the same time, press the REPEAT
button.
REPEAT ON will display in the upper right corner of the screen and the
current timer program will repeat every day.
To cancel the daily repeat function, press the REPEAT button again and
REPEAT ON will be changed to REPEAT OFF.
RANDOM VACATION MODE DCIT 0011 DC only
TIMER ON
DELAY START
RANDOM DELAY START ON/OFF
RUN TIME
Reset
The Random mode changes the RUN TIME start and end times by up to +/-
30 minutes creating a more "lived in" appearance.
If RANDOM is turned on, the timer will start up to + or - 30 minutes from
the programmed start time and will end up to + or - 30 minutes from the
end of the programmed run time.
Example: If the RUN TIME is set to start at 6:00PM, when in RANDOM mode,
it could start as early as 5:30PM or as late as 6:30PM. The timer will turn on
at randomly selected times within this range daily until the RANDOM mode
is turned o .
If the If the RUN TIME is set to stop at 10:00PM, when in RANDOM mode, it
could stop as early as 9:30PM or as late as 10:30PM. The timer will turn o at
randomly selected times within this range daily until the RANDOM mode is
turned o .
DCIT 0011 DC
TIMER ON REPEAT OFF
DELAY START RUN TIME
RANDOM DELAY START ON/OFF REPEAT RUN TIME
Reset
REPEAT OFF
RANDOM
RUN TIME
REPEAT RUN TIME
Reset
