Table of Contents

HAYMAN BAR CART
ASSEMBLY INSTRUCTIONS
Item No. 0253121
!
READ & SAVE BELOW INSTRUCTIONS BEFORE ASSEMBLY
1. PLEASE SEPARATE AND IDENTIFY ALL PARTS, MAKING SURE THAT YOU HAVE ALL OF THE PARTS LISTED.
2. TO AVOID ANY SCRATCHES DURING ASSEMBLY, ASSEMBLE ON A SOFT MAT OR SIMILAR.
3. ASSEMBLE STEP BY STEP FOLLOWING THE INSTRUCTIONS.
4. WASHERS MUST BE USED.
5. DURING ASSEMBLY DO NOT OVER FASTEN SCREWS & NUTS.
6. DO NOT COMPLETELY TIGHTEN EACH SCREW AND NUT UNTIL THEY ARE ALL FIXED IN PLACE.
5-1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HAYMAN 0253121 and is the answer not in the manual?

Questions and answers

Summary of Contents for Mimosa HAYMAN 0253121

  • Page 1 HAYMAN BAR CART ASSEMBLY INSTRUCTIONS Item No. 0253121 READ & SAVE BELOW INSTRUCTIONS BEFORE ASSEMBLY 1. PLEASE SEPARATE AND IDENTIFY ALL PARTS, MAKING SURE THAT YOU HAVE ALL OF THE PARTS LISTED. 2. TO AVOID ANY SCRATCHES DURING ASSEMBLY, ASSEMBLE ON A SOFT MAT OR SIMILAR. 3.
  • Page 2 PARTS LIST PARTS QTY. CODE Base shelf Cart top Support tube 2PCS Bottle support frame Glass storage frame Tray shelf HARDWARE LIST CODE PARTS QTY. 6PCS Bolt - M6*20 8PCS Bolt - M6*40 4PCS Bolt - M6*20 Washer 6PCS Washer 8PCS Allen Key 6PCS...
  • Page 3 Secure the glass storage frame (G) to Place cart top (D) upside down on cart top (D), using bolts (K) with Allen a clean protected surface. Secure Key (N). Please note the storage frame legs (A) (B) to cart top using bolts should be at the end close to leg (B) (J) and washer (M) with Allen Key with the wheels...
  • Page 4 Insert bottle storage rack (F) to Insert the bottle storage rack into the support tube (E). other support tube (E). Then repeat step 4 to secure the support tube to the legs (A&B). Remove screw holding handle into leg (A) and Turn your cart right way up and pull out as pictured.
  • Page 5 What is polywood Polywood is designed for outdoor use and can withstand all types of weather. Polywood is made of a synthetic plastic material that looks and functions much like natural wood. It is developed for those who prefer attractive and stylish garden furniture that does not require significant maintenance work.
