- Page 1 OPERATOR’S MANUAL SOD ROLLER / HANDLER COMPACT TOOL CARRIER SERIAL NUMBER: ___________________ Manual Number: OM655 Part Number: 75555...
- Page 2 MODEL NUMBER: ___________________ Rev. 6 800-456-7100 I www.paladinattachments.com 503 Gay Street, Delhi, IA 52223, United States of America Copyright © 9513 1-31-20-9...
- Page 5 • job site organization, working material condition, environment Based on the uncertainty of the prime mover, operator, and job site, it is not possible to get precise machine and operator sound pressure levels or vibration levels for this attachment. 75555...
- Page 6 NOTE: A list of all Paladin Patents can be found at http://www.paladinattachments.com/patents.asp. 10344 1-31-17-5 THIS PAGE IS INTENTIONALLY BLANK 75555...
-
Page 7: Safety Statements
Remove and replace any damaged, fatigued, or excessively worn parts. Make certain all safety decals are in place and are legible. Keep decals clean, and replace them if they become worn or hard to read. 10338 5-10-16-2 75555... - Page 8 • Wear safety glasses, protective clothing, and use a piece of cardboard or wood when searching for hydraulic leaks. DO NOT USE YOUR HANDS! SEE ILLUSTRATION. CARDBOARD HYDRAULIC HOSE OR FITTING MAGNIFYING GLASS 10339 8-16-05 75555...
- Page 9 WARNING! CALIFORNIA PROPOSITION 65 WARNING This product may contain a chemical known to the state of California to cause cancer, or birth defects or other reproductive harm. www.P65Warnings.ca.gov 75555...
-
Page 10: Equipment Safety Precautions
TRANSPORTING THE ATTACHMENT • Travel only with the attachment in a safe transport position to prevent uncontrolled movement. Drive slowly over rough ground and on slopes. 75555... - Page 11 Worn, damaged, or illegible safety decals must be replaced. New safety decals can be ordered from BRADCO. • Never make hydraulic repairs while the system is under pressure. Serious personal injury or death could result. • Never work under a raised attachment. 75555...
- Page 12 Allow the surface to fully dry. Remove the backing from the safety decal, exposing the adhesive surface. Apply the safety decal to the position shown in the diagram above and smooth out any bubbles. 75555...
- Page 13 9518 1-31-20-3 DECALS WARNING! HIGH PRESSURE FLUID DANGER! PINCH POINTS PART #40151 PART #40149 NOTE: CONTACT YOUR LOCAL DEALER FOR LOGO DECALS. 75555...
- Page 14 This knowledge will be helpful when reading through this manual or when ordering service parts. MOUNTING FRAME LEFT SIDE ( INCLUDES APPROPRIATE MOUNTING FOR YOUR LOADER) HYDRAULIC CYLINDERS DISC LEFT ARM RIGHT ARM RIGHT SIDE 75555...
-
Page 15: Installation
Follow your power unit operator's manual for detaching (removing) an attachment. NOTE: Frequent lubrication of grease fittings at the end of the cylinder and pivot points with a multi-purpose grease will greatly increase life of the product. 75555... - Page 16 9515 6-23-14-2 75555...
-
Page 17: Operation
920 lbs. The following chart can work as a guide when determining the amount of water added to the drum. Check your prime mover’s rated lift capacity before adding water. 9516 6-23-14*2 75555... - Page 18 LAWN ROLLER prime mover to obtain the DRUM correct position for installing the disc’s. FILL PLUG .50 ” X 1.00” CAPSCREW LONGEST END OF SHAFT DISC LAWN ROLLER OPERATING TIPS 75555...
-
Page 19: Removal From Storage
LIFT POINTS Lifting points are identified lifting decals where required. Lifting at other points is unsafe and damage attachment. attach lifting accessories around cylinders that damage hoses or hydraulic components. • Attach lifting accessories unit recommended lifting points. 75555... -
Page 20: Tie Down Points
WARNING! Verify that all tie down accessories (chains, slings, ropes, shackles and etc.) are capable of maintaining attachment stability during transporting and are attached in such a way to prevent unintended disengagement or shifting of the unit. Failure to do so could result in serious personal injury or death. 10248 6-24-14-2 75555... -
Page 21: Maintenance And Service
Flesh injected with hydraulic fluid may develop gangrene other permanent disabilities. injured injected fluid, see doctor once. your doctor familiar with this type of injury, research immediately determine proper treatment. 75555... - Page 22 ASSEMBLY PROCEDURE IMPORTANT: Replace all seals even if they do not appear to be damaged. Failure to replace all seals may result in premature cylinder failure. NOTE: Seal kits will service most cylinders of similar bore size and rod diameter. 75555...
- Page 23 Thread Diameter POUNDS - FEET 7/8" 150-200 *1" 230-325 1-1/8" 350-480 1-1/4" 490-670 1-3/8" 670-900 * 1" Thread Diameter WITH 1.25" Rod Diameter Min. 230 ft. lbs. Max. 250 ft. lbs. 75555...
-
Page 24: Troubleshooting
Obstruction in hydraulic Remove obstruction and lines. replace if necessary. Loose or damaged hydraulic Tighten or replace fittings. connection. Arms open and close too Warm oil with engine at Cold Oil idle. slowly. Replace cylinder packings. Oil leaking past cylinder packings. 75555... - Page 25 Arms fail to maintain their Broken or leaking hydraulic Replace broken hose and position. lines. check for leaks. Oil leaking past cylinder Replace cylinder packings. packings. 9520 6-24-14-2 SPECIFICATIONS SOD LAYER 75555...
-
Page 26: Bolt Torque Specifications
25.40 1037 1245 1-1/8 25.58 1014 1088 1224 1475 1660 1-1/4 31.75 1054 1291 1429 1547 1700 2097 2305 1-3/8 34.93 1241 1428 1683 1936 2023 2312 2743 3135 1-1/2 38.10 1649 1870 2236 2535 2686 3026 3642 4103 75555... - Page 27 To facilitate parts ordering when contacting the factory, please have the product control number (PCN or C/N) or model and serial number of your product ready to ensure that you receive the correct parts for your specific attachment. 75555...
-
Page 28: Warranty
UPS Next Day orders must be received by 1:30 PM (Eastern Standard Time.) WARRANTY For any parts and/or warranty support please contact us toll free at 888-888-1085 or complete our warranty submission claim form at the link below: https://www.spartanequipment.com/pages/warranty-submission-claim-form.html 503 Pulaski Highway Joppa, MD 20185 888-888-1085 orders@spartanequipment.com 75555...
