Chefman Conical Burr RJ44-SS-TCB Quick Start Manual

®
Conical Burr
DIGITAL COFFEE
GRINDER
QUICK START GUIDE
• Features
• Before First Use
• How to Adjust the Grind Size
• How to Grind Coffee
• Cleaning and Maintenance
©CHEFMAN 2021
RJ44-SS-TCB
FEATURES
®
1.
2.
3.
4.
5.
6.
7.
8.
9.
10. Stainless-Steel Base
11. Brush
12. Ground Coffee Container Lid
13. Ground Coffee Container
14. Rubber Mat
1
2
11
3
Coffee Bean Hopper Lid
4
5
Coffee Bean Hopper
Removable Upper Conical Burr
6
Grind Selector Ring
7
Control Panel
8
LED Display
9
+5 SEC Button
MAX TIME Button
10 12
START/STOP Button
14
13
BEFORE FIRST USE
1. Remove the hopper: Press the release lever on the back of the grind selector ring, rotate
counterclockwise until the unlock icon ( ) aligns with the up arrow ( ) on the lever, then lift up.
2. Wash the ground coffee container, hopper, and their lids with hot soapy water; rinse
and dry thoroughly.
3. Wipe down the base with a damp cloth.
4. Replace the hopper: Set the hopper on the base, aligning the unlock icon ( ) with the up
arrow ( ) on the lever. Rotate clockwise until the lock icon ( ) aligns with the up arrow ( ).
You should hear the hopper click into place. NOTE: If the hopper is not fully attached, the
coffee grinder will not work.
HOW TO ADJUST THE GRIND SIZE
The coffee grinder has 31 grind-size options. To adjust the grind size, rotate the ring just
under the hopper, and select the appropriate grind for the type of coffee you're making.
• A finer grind exposes more surface to the water and extracts flavor more rapidly, which
is appropriate for a quick-brew method like espresso.
• A coarser grind, which exposes little surface, is appropriate for the longer brewing cycle
of French press.
When the beans are ground too finely for a particular brewing method (for instance, an espresso
grind used in a drip coffee machine), the resulting coffee will taste too bitter and strong.
Conversely, when too coarse a grind is selected, the resulting coffee tastes too weak and watery.
Use the chart below to choose your grind size.
French Press/
Coffee Type Pour-Over Drip Coffee Siphon Espresso Turkish Coffee
Cold Brew
Medium
Grind Size Extra Coarse Coarse Medium Fine Fine Extra Fine
Coarse
Grind Setting 31-26 25-19 18-11 10-6 5-3 2-1
