EAGLE VISION PHI-E Instructions Manual

Tv & video & pc interface controller for sxga & xga resolutions tft lcd
Hide thumbs

Advertisement

Quick Links

Download this manual
TV & VIDEO & PC INTERFACE CONTROLLER
FOR SXGA & XGA RESOLUTIONS TFT LCD
CONTENTS
Page: 1. Introduction, How to proceed, Usage Note, Disclaimer
0
2. System design - Diagram of a suggested system
0
3. Specifications
4. Assembly notes - Important information about system elements
6. Connection & Operation - How to use the controller
15. Connectors, Pinouts & jumpers - Essential connection information
20. Mechanical - Controller dimensions
21. Application notes
22. Troubleshooting
23. Warranty, Caution & Limitation of Liability, Trademarks
24. Contact details
It is essential that these instructions are read and understood before connecting or
powering up this controller.
MODEL: PHI-E
INSTRUCTIONS

Advertisement

loading
Need help?

Need help?

Do you have a question about the PHI-E and is the answer not in the manual?

Questions and answers

Related Manuals for EAGLE VISION PHI-E

Summary of Contents for EAGLE VISION PHI-E

  • Page 1 TV & VIDEO & PC INTERFACE CONTROLLER FOR SXGA & XGA RESOLUTIONS TFT LCD MODEL: PHI-E INSTRUCTIONS CONTENTS Page: 1. Introduction, How to proceed, Usage Note, Disclaimer 2. System design - Diagram of a suggested system 3. Specifications 4. Assembly notes - Important information about system elements 6.
  • Page 2 INTRODUCTION PHI-E Designed for LCD monitor and other flat panel display applications the controller provides easy to use interface controller for:  TFT LCD panels of 1280×1024, 1024×768, 800×600, 640×480 resolutions.  TV signal input (optional add-on board required).  Computer video signals of VGA, SVGA, XGA and SXGA standard.
  • Page 3 15. TV tuner add-on board (PAL or SECAM or NTSC) 16. TV tuner cable 17. Extended Video signals Input 18. Extended Power Input (12V DC) Eagle Vision Displays provides a range of parts, such as listed above, to make up complete display solutions.
  • Page 4 SPECIFICATIONS Panel compatibility Compatible with 1280x1024, 1024×768, 800×600 & 640×480 resolutions of TFT LCD panels from manufacturers such as: LG, Samsung, AUO, Hydis, etc Some factory adjustment may be required for individual panel timings. NO, of colors Up to 3×8 bit providing 16.7million Panel power +3.3V DC, +5V DC, +12V DC Panel signal...
  • Page 5 ASSEMBLY NOTES This controller is designed for monitor and other flat panel display applications using 1280x1024, 1024×768, 800×600, and 640×480 resolution TFT panels with a VGA, SVGA, XGA or SXGA signal input. The following provides some guidelines for installation and preparation of a finished display solution.
  • Page 6 12. Audio add-on board & cable: It’s for Audio signal input and contacted with external speakers. According to audio control signal from MCU, audio signal is selected. Composite audio signals (Left/Right), and TV Tuner audio signals (Left/Right), etc. 13. Power Input: 12V DC is required, this should be a regulated supply. The power rating is depending on the panel and inverter used.
  • Page 7 CONNECTION & OPERATION CAUTION: Never connect or disconnect parts of display system when the system is powered up as this may cause serious damage. CONNECTION It is useful to have the relevant connection diagram available at this time: 1. LCD panel & Inverter: Connect the inverter (if it is not built-in the panel) to the CCFT lead connector of the LCD panel.
  • Page 8 General:  If you are using supplied cables & accessories, ensure they are correct for the model of panel and controller.  If you are making your own cables & connectors refer carefully to both the panel & inverter specifications and the section in this manual, "Connectors, Pin-outs & Jumpers" to ensure the correct pin-to-pin wiring.
  • Page 9 LCD DISPLAY SYSTEM SETTINGS NOTE: By way of explanation the following refers to a set of sample buttons that may be obtained as an option. In addition to power On/Off and connection for backlight brightness the controller provides an On Screen Display of certain functions, which are controlled by 7 momentary type buttons (digital type).
  • Page 10 OSD Functions OSD Structure (Picture Menu) PICTURE Menu Explanation Brightness  Select “Brightness“ function from the OSD picture menu.  Press VOL+ / VOL- button to select a desire brightness for the display. GEOMTRY Contrast  Select “Contrast” function from the OSD picture menu. ...
  • Page 11 OSD Structure (Source Menu) SOURCE Menu Explanation Video 1  Select “Video1“ function from the OSD source menu.  Press VOL+ / VOL- button to enable/disable the video1 source. GEOMTRY Video 2  Select “Video2“ function from the OSD source menu. ...
  • Page 12 OSD Structure (OSD Menu) OSD Menu Explanation OSD H-Position  Select “OSD H-Position“ function from the OSD osd menu.  Press VOL+ / VOL- button to adjust a desire OSD horizontal position for the OSD display. GEOMTRY OSD V-Position  Select “OSD V-Position“ function from the OSD menu. ...
  • Page 13 OSD Structure (SETUP Menu) SETUP Menu Explanation AUTO Power  Select “AUTO Power ” function if you want that your system data like this; volume, channel, kind of source, etc are saved whenever it’s time to turn off the system. GEOMTRY Reset ...
  • Page 14 OSD Structure (TV Menu) TV Menu Explanation AIR: CATV  Select “AIR: CATV“ function from the OSD TV menu to select TV source type; AIR, CATV.  Press VOL+ / VOL- button to select TV source type. GEOMTRY Channel  Select “Channel” function from the OSD TV menu to select the channel to be modified in channel memory.
  • Page 15 OSD Structure (Screen Menu) Screen Menu Explanation H-Position  Select “H-Position“ function from the OSD screen menu.  Press VOL+ / VOL- button to adjust a desire horizontal position for the display. GEOMTRY V-Position  Select “V-Position“ function from the OSD screen menu. ...
  • Page 16 Connectors, Pinouts & Jumpers The various connectors are: J501 J500 J502 J301 J503 J700 100 mm (3.9” ) J203 PHI-E JSP100 JP100 J200 J201 J702 Max. 15 mm (0.6”) 120 mm (4.7”) Summary: Ref. Purpose Description J200 OSD controls Molex connector 10-pin (53015-10 (Molex))
  • Page 17 J200 – To OSD controls: Molex connector 10-pin Symbol Description DGND Ground IR remote control signal REMOCON IR Power supply (5.0 V) PWR_LEDG Green LED Signal Red LED Signal PWR_LEDR PWR_UP Power control signal Function control signal (For SELECT, MENU, VOL_DN key) Function control signal (For VOL_UP, CH_DN, CH_UP key) Ground DGND...
  • Page 18 J500 – To LCD panel (TTL): Header Hirose 40-pin (HEADER 20x2/SM) Symbol Description Symbol Description VCC-PL Panel VCC G channel Green Data6 VCC-PL Panel VCC G channel Green Data7 VCC-PL Panel VCC G channel Green Data4 VCC-PL Panel VCC G channel Green Data5 FPDCLK Clock output G channel Green Data2...
  • Page 19 JSP100 – To Main power input: Power jack (2.5 internal pin) Description +12VDC in middle pin Ground JP100 – To Main power input: Molex connector 2pin (53015-02) Description +12VDC in middle pin Ground J700 – To S-Video signal Input (Mini din 4-way) Description Open Open...
  • Page 20 J201 – To TV tuner add-on board: Molex Connector 12-pin Symbol Description 5Vcc 5V DC TV_CVBS Composite video signal In TV_AUDIO Audio signal In Ground FM_SDA C Bus Data out FM_SCL C Bus Clock out FM_CE Chip Enable signal out N.C.
  • Page 21 J501 J500 J502 J301 J503 J700 100 mm 90 mm (3.9”) (3.5”) J203 PHI-E JSP100 JP100 J200 J201 J702 Max. 15 mm (0.6”) 120 mm (4.7”) The maximum thickness of the controller is 20.0 (with no piggy-back or daughter boards), including any underside components &...
  • Page 22 Generally the situation is: Brightness can be controlled by using a VR Brightness controlled by adding a circuit such as PWM (Pulse Width Modulation). Pin 1 should be matched to the inverters specification for the 'BL_BRIGHT' pin. (PHI-E) Symbol Description BL_BRIGHT PWM signal for backlight control.
  • Page 23 TROUBLESHOOTING General A general guide to troubleshooting a flat panel display system it is worth considering the system as separate elements, such as:  Controller (jumpers, PC settings)  Panel (controller, cabling, connection, panel, PC settings)  Backlight (inverter, cabling, backlight tubes) ...
  • Page 24 The manufacturer's liability for damages to customer or others resulting from the use of any product supplied hereunder shall in no event exceed the purchase price of said product. TRADEMARKS The following are trademarks of Eagle Vision Displays:  Eagle Vision Displays  PHI-E...
  • Page 25 CONTACT DETAILS PHI-E Eagle Vision Displays (a division of Global Eagle Technologies, Inc.) Tel: (408) 982-0260 Fax: (408) 982-0774, Email: Sales & Business Dev. - tedh@evdisplays.com Eagle Vision Displays 1111 Space Park Dr. Tech Support - girish@evdisplays.com Santa Clara, Ca 95054...
