Instruction Manual
for
Origin Dehumidifier
OS110 / OS165
----------------------------------------------------
Thanks for choosing Origin de-humidifiers and we highly recommend you to have a
careful reading of the instructions before using the devices. It will provide you with
necessary information for proper use and maintenance.
Advertisement
Table of Contents
Related Manuals for Origin OS110
Summary of Contents for Origin OS110
- Page 1 Origin Dehumidifier OS110 / OS165 ---------------------------------------------------- Thanks for choosing Origin de-humidifiers and we highly recommend you to have a careful reading of the instructions before using the devices. It will provide you with necessary information for proper use and maintenance.
-
Page 2: Table Of Contents
Contents Chapter 1. Operation Safety ......................3 1.1 Safety and Warning........................3 1.2 Appliance Range of the Machine....................3 4 1.3 Contents of the Manual ........................ 4 Chapter 2. Installation of Equipment ..................5 2.1 Brief Introduction ......................... 5 2.2 Shipping and Storage........................5 2.3 Inspection............................. -
Page 3: Chapter 1. Operation Safety
Chapter 1. Operation Safety 1.1 Safety and Warning The dehumidifier meets the safety requirements of AUE and European standards. The design and manufacturing have taken the safety of personnel and equipment in into consideration. In each chapter of this manual, there is information about security, which clearly points out the dangerous operation, and signs the warning signs in the front. -
Page 4: Appliance Range Of The Machine
the indoor air or outdoor mixing air through the surface air cooler and send them into the room, so that the indoor temperature can be lowered to meet the comfort requirements of people. The equipment is applicable to the working temperature range of 5-38℃, beyond which will affect the normal use of the equipment. -
Page 5: Chapter 2. Installation Of Equipment
Chapter 2． Installation of Equipment 2.1 Brief Introduction The dehumidifier can be installed in many places which depending on the user's needs. If there are requirements, it can be used with the existing power system or existing duct system together. This section covers the description of required job of dehumidification equipment from leaving the factory to being installed. -
Page 6: Electrical Connections
Electrical Connections NOTICE! All electrical connections works must be done by local professionals and shall be carried out by qualified personnel. Dehumidifier control circuit has been marked with different color to prevent confusion, unit design adopts three-phase ac power supply, electric equipment installation and configuration are in accordance with the voltage and frequency of equipment nameplate on the calibration. -
Page 7: Chapter 3. Matters Need Attention
3. Matters Need Attention This section describes important aspects of safety matters to prevent personal injury or property damage to users and others. Please read the text on the basis of fully understanding the following contents (logo, icon), and be sure to follow the safety precautions listed. - Page 8 Do not put your hand into the air inlet, do not climb or sit on the dehumidifier. This can cause the device to deform or cause a fire. In thunderstorms, the power must be disconnected. Failure to disconnect the power supply may result in lightning strikes and damage to the dehumidifier.
-
Page 9: Chapter 4. Appearance And Structure
4. Appearance And Structure OS110 OS165... -
Page 10: Chapter 5. Function Of Button
5. Function Of Button... - Page 12 Press “Set ” for 10 seconds to enter to the Internal parameter modification mode, Che display will show , at this time, you can use the “Add” and “Subtract” to select the target, and press “Set” to confirm. When you confirm the display data will flicker, use the “Add” and “Subtract” again to adjust the data, and press “Set”...
- Page 13 4. The system has auto memory. When all the mode setting has been finished, if there is sudden power cut during operation, or the power jack slips out, the system may store the current status before the power is cut and enter the operation before power cut automatically after power is supplied;...
-
Page 14: Chapter 6. Operating Instructions
6. Operating Instructions When the substrate is powered on for the first time, the substrate enters the standby state, press the power button and set the required humidity 3% less than the current humidity to enter the running state, If the setting humidity is higher than ambient humidity, the dehumidifier will not work. -
Page 15: Chapter 7. Troubleshooting
Chapter 7. Troubleshooting Problems Phenomenon/Reason Solutions 1.Could be a power outage. 2. The power switch is not on. 1.Please wait for power supply. 3.Maybe the fuse has blown out. 2. Turn on the power switch. Dehumidifier does not 4.It’s not the definite starting up time. 3.Change the fuse. -
Page 16: Chapter 8. Instruction On Code Of Failure
Chapter 8. Instruction on Code of Failure The dehumidifier is able to automatically judge failure. If there is any failure, there will be failure code displayed on the humidity display window. Failure Display Problem Solution Temperature sensor failure Replace the Temperature sensor Humidity sensor failure Replace the Humidity sensor ℃... -
Page 17: Chapter 10. Electric Schematic Diagram
Check if there is damage and Check if there is damage and displacement. It should be replaced if there displacement. It should be replaced Seal is wear or damage. if there is wear or damage. Temperature and Humidity Check whether all external Control temperature and humidity probes are properly working. -
Page 18: Chapter 11. Technical Specification
11. Technical Specification Model OS 110 Extraction capacity (30°C, 80% RH) 110 ltrs/day Air Flow 900 m Power rating 1660 watts Power source 220V/50HZ Temperature Operating range 5°C - 35°C Operating humidity 40%-80% RH% Tank capacity 6.5 ltrs (SS tank) Water Pump Max : 4 - 4.5 meters height Noise Level (approx.) -
Page 19: Chapter 12. Packing List
12. Packing List: 12.1 Dehumidifier *1piece 12.2 Instruction Manual *1 piece... - Page 20 Origin Corporate Services Pvt Ltd Address: 906, Dalamal Tower, Nariman Point, Mumbai - 400 021. Tel : +91 915 200 49 49 |+91 22 49267267 | +91 22 49267201 Web Site : www.origincorp.com | Email : response@origincorp.com...
