ASSEMBLY GUIDE
STONE AIO HEIGHT ADJUST STAND
Stone height adjust stand for use
with Stone AIO PC M770/M780.
3
Using the Velcro fasteners secure the power
supply unit onto the back of the height adjust
stand and connect the AC power cable.
Call 08448 22 11 22 Email sales@stonegroup.co.uk
2
Slide the rear panel upwards to release it then lift away from the unit.
4
Route the front panel USB and Audio
cables alongside the power supply unit as
demonstrated by the blue cable.
At this point you can also add any other
cables you require such as LAN or
peripherals (keyboard/mouse) to the cable
management system.
1
Using the tool provided remove the screw(s)
holding the rear panel in position, these are
located at the top.
5
Now replace the rear panel ensuring that all
of the cables which you require are threaded
through one of the openings provided so that
you can connect them to the Stone AIO PC.
stonegroup.co.uk
Advertisement
Summary of Contents for Stone AIO PC M770
- Page 1 AC power cable. demonstrated by the blue cable. through one of the openings provided so that you can connect them to the Stone AIO PC. At this point you can also add any other cables you require such as LAN or peripherals (keyboard/mouse) to the cable management system.
- Page 2 ASSEMBLY GUIDE STONE AIO HEIGHT ADJUST STAND Replace the screws which hold the rear panel Mount the PC unit onto the height adjust stand VESA bracket in position using the tool provided. ensuring the four T bolts slot into position correctly.
