USER MANUAL

50FT. POWER-FEED

ELECTRIC DRAIN CLEANER WITH GFCI

PEDC-50

WHAT'S IN THE BOX

Arrow Cutter

Boring Bulb Cutter

x 1

Expanding Finish Cutter

Spiral Saw Tooth Cutter

x 1

WARNING! To reduce the risk of injury, the user must read and understand the user manual before

operating this product. Save this manual for future reference.

C-Cutter

x 1

Screwdriver

x 1

BY THE PEOPLE FOR THE PEOPLE

Spade Cutter

Retrieving Auger

x 1

Spanner

x 1

Funnel Auger

x 1

Gloves

x 1

MADE IN CHINA

Table of Contents

Need help?

Do you have a question about the PEDC-50 and is the answer not in the manual?

Questions and answers

Summary of Contents for Populo PEDC-50

Page 1 BY THE PEOPLE FOR THE PEOPLE USER MANUAL 50FT. POWER-FEED ELECTRIC DRAIN CLEANER WITH GFCI PEDC-50 WHAT’S IN THE BOX Arrow Cutter Boring Bulb Cutter C-Cutter Spade Cutter Retrieving Auger Funnel Auger Expanding Finish Cutter Spiral Saw Tooth Cutter Screwdriver...
Page 2: Electrical Safety Warnings
Note: The supply of 120V 60Hz on Populo tools are interchangeable for use in the United States and Canada. Note: The power outlet used for the power tools must be protected by a 30mA ground fault circuit interrupter or earth leakage circuit breaker.
Page 3: Ground Fault Circuit Interrupter (Gfci)
GROUNDING WARNINGS(CONT.) Figure c: Grounding Adapter connection 6. The adapter should not be used if a three-slot grounded receptacle is available. 7. A qualified electrician should be consulted if there is any doubt as to whether an outlet box is properly grounded. 8.
Page 4: General Power Tool Safety Warnings
GENERAL POWER TOOL SAFETY WARNINGS WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. The term “power tool” in the warnings refers to your mains operated (corded) power tool or battery operated (cordless) power tool.
Page 5 WARNING! Read all safety warnings and instructions listed below. Failure to follow the warnings and instructions may result in serious injury. WARNING! This tool vibrates during use. Repeated or long term exposure to vibration may cause temporary or permanent physical injury, particularly to the hands, arms and shoulders.
Page 6 SYMBOLS AND DEFINITONS SYMBOLS DEFINITONS This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death. Indicates a hazardous situation which, if not avoided, will result in death or serious injury. Indicates a hazardous situation which, if not avoided, could result in death or serious injury.
Page 7: Know Your Product
KNOW YOUR PRODUCT 1. Handle 2. Rotation Switch(FOR/REV/OFF) 3. Tool Holder 4. Power Cord With GFCI 5. Foot Switch 6. Wheel 4004713 7. Drive Belt 8. Handle locking Knob 9. Belt Guard 10. Drum 11. Cable 12. Tension Knob 13. Power-Feed Lever SPECIFICATIONS Electrical Rating: 120VAC 60Hz 5.3A Motor Speed: 1716 RPM...
Page 8: Unpack And Set-Up
UNPACK AND SET-UP WARNING! Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this manual including all text under subheadings therein before set up or use of this product. Wear ANSI-approved splash-resistant safety goggles, NIOSH-approved dust mask/respirator under face shield, and heavy-duty LEATHER gloves, and other appropriate protective equipment when setting up the Drain Cleaner.
Page 9: Work Area Set-Up
UNPACK AND SET-UP(CONT.) WORK AREA SET-UP 1. Verify that work area has adequate lighting for the job. 2. Make sure work area is free of flammable liquids, vapors or dust that may ignite. Sparks can be generated during drain cleaner operation.
Page 10 UNPACK AND SET-UP(CONT.) ASSEMBLY WARNING! TO PREVENT SERIOUS INJURY FROM ACCIDENTAL OPERATION: Turn the Rotation Swich of the tool to its “OFF” position and unplug the tool from its electrical outlet before assembling or making any adjustments to the tool. Follow the below steps to quickly assembly the machine.
Page 11: Power-Feed Operation
OPERATION POWER-FEED OPERATION WARNING! To prevent serious injury from twisted or broken cables, cable ends whipping around, appliance tipping, chemical burns, infections, electric shock and other causes: Follow operating instructions for your model explicitly. Since drains likely contain hazardous chemicals or bacteria, wear appropriate protective equipment, such as: •...
Page 12 OPERATION(CONT.) WORKING THROUGH A BLOCKAGE 1. If cutting tool becomes lodged in a blockage and drain cleaner is still operating, cable will start to wind up or twist. If so, release pressure from foot switch and drain cleaner motor will stop. WARNING! Do not let cable build up outside drain.
Page 13: Installing Replacement Cable
TROUBLESHOOTING MAINTENANCE Procedures not specifically explained in this manual must be performed only by a qualified technician WARNING! TO PREVENT SERIOUS INJURY FROM ACCIDENTAL OPERATION: Turn the Rotation Switch of the tool to its “OFF” position and unplug the tool from its electrical outlet before performing any inspection, maintenance, or cleaning procedures.
Page 14: Caring For The Environment
TROUBLESHOOTING TROUBLE SHOOTING Use the table below to troubleshoot problem may get your problem solved in an effective way before contacting our customer service, if the problem continues after troubleshooting, please always contact with our Customer Service. Problem Possible Cause Remedy Motor shuts off during use.
Page 15: Warranty
● Professional, industrial or high frequency use. ANY QUESTIONS, PLEASE CONTACT OUR CUSTOMER SERVICE CENTER: tools@populo.com TO ENSURE THE QUICKEST RESPONSE POSSIBLE, PLEASE HAVE THE PRODUCT CODE AND ORDER NUMBER, DATE OF PURCHASE AVAIABLE SO OUR CUSTOMER SERVICE REPRESENTATIVE CAN ANSWER ANY QUESTIONS YOU MAY HAVE RELATING TO THE WARRANTY POLICY OR PROCEDURE.
