    INTRODUCTION Thank you for selecting Tannoy loudspeakers developed in the UK by our dedicated team of design engineers. They are the choice of discriminating music lovers the world over. Musical excellence is designed into our loudspeakers from the start.

  • Page 3: Amplifier Choice

    Consult the enclosed product specification sheet as this clearly shows the acceptable power range for amplifier matching to your speakers. The high peak power handling of Tannoy loudspeakers permits responsible use with more powerful amplifiers - please read the Warranty.

  • Page 4: Installation

    INSTALLATION To avoid potential damage to your loudspeaker, ensure that the amplifier is switched OFF prior to connecting or disconnecting any cables. Before switching on double check that all connections are secure and that polarity is correct. WARNING: SEE THE SECTION ON SCREENING IF POSITIONING NEAR TO A TELEVISION SCREEN. CONNECTION IN SINGLE WIRE MODE (See fig.

  • Page 5: Connection Of Earth Or 'Ground' Lead

    POSITIONING AND FINE-TUNING (See fig. 5) To get best results from your new Tannoy Dimension loudspeakers it is worthwhile spending a little time finding the optimum set-up configuration. Begin by angling the speakers towards your chosen listening position, usually this is on the centre line of the room, so that when seated you can just see the inner side panel of each speaker.

  • Page 6: Dimension Home Theatre 5.1 - General Info

    DIMENSION HOME THEATRE 5.1 – GENERAL INFORMATION (See fig. 6) Unlike other forms of encoded surround audio, 5.1 offers full bandwidth capability for the surround and centre channels, with the ability to treat the subwoofer as a single discreet channel for special effects playback or, for music applications, as a dedicated low frequency instrument channel.

  • Page 7: Technical Specifications

    TECHNICAL SPECIFICATIONS PERFORMANCE Recommended amplifier power - Watts RMS 40 - 160 Continuous power handling - Watts RMS Peak power handling - Watts Sensitivity (2.83Volts @ 1 m) 90dB Nominal impedance - Ohms Frequency response -6dB 42Hz - 54kHz Dispersion 90 º...

  • Page 8: Set-Up Diagrams

    SET-UP DIAGRAMS FIG. 1 TERMINAL PANEL CONNECTIONS HIGH FREQUENCY NEGATIVE(-) TERMINAL LOW FREQUENCY NEGATIVE(-) TERMINAL 'EARTH' OR 'GROUND' TERMINAL BI-WIRE MODE AND EARTH (GROUND) FIG. 3 LEAD CONNECTION TO 'GROUND' OR 'EARTH' CONNECTION ON AMPLIFIER (OPTIONAL) LINK WIRES REMOVED SINGLE WIRE MODE AND EARTH (GROUND) FIG.
  • Page 9 SET-UP DIAGRAMS FIG. 5 POSITIONING RECOMMENDATIONS - TWO CHANNEL STEREO 0.5 METRES OR MORE FIG. 6 POSITIONING RECOMMENDATIONS - HOME CINEMA 1.5 TO 4.5 METRES 1 METRE OR MORE...
