- Page 1 Microprocessor-based control units with remote control function HS520 - HS515 - HS510 USER and PROGRAMMING MANUAL...
- Page 2 Some products incorporate rechargeable or non rechargeable batteries as emergency power supply. Their wrong connection may damage the product, properties and the operator’s safety (burst and fire). Your dealer: 2 - HS520 - HS515 - HS510 USER and PROGRAMMING MANUAL...
-
Page 3: Generals
1. GENERALS HS520 control unit has been designed to manage a single residential unit system, with the possibility to ena- ble the 4 partitions/sectors separately and assign them up to 15 users. Each user can also be assigned a per- sonal 6-figure code, an M4 key, and a TAURUS remote control device. - Page 4 4 - HS520 - HS515 - HS510 USER and PROGRAMMING MANUAL...
- Page 5 HS520 - HS515 - HS510 USER and PROGRAMMING MANUAL - 5...
-
Page 6: User Interface
OFF = No alarms in progress. ON = Tamper alarm cycle (Relay enabled). Slow blinking = Presence of events on tamper memory. Fast blinking = Intrusion alarms memories display. 6 - HS520 - HS515 - HS510 USER and PROGRAMMING MANUAL... -
Page 7: System Anomaly Status Display
Press STOP key to go back to normal display mode. If operator/user does not press STOP key, normal di- splay mode will be resumed automatically 60 seconds after the last key has been pressed. HS520 - HS515 - HS510 USER and PROGRAMMING MANUAL - 7... -
Page 8: Answering Machine Function
Events are logged with data&time info and event log can be displayed on NADIR remote keypad too. HS series control unit feature a FIFO memory: last 100 events will be kept but only HS520 and HS515 units will keep these data in case of total power cut. -
Page 9: Control Units Controls
(in case of number 9, digit 8 or 0). This will disarm control unit and trigger DURESS alarm code. The event is controlled by the phone dialer function. 4.2 Unit arming with user code 4.3 Special functions with user code HS520 - HS515 - HS510 USER and PROGRAMMING MANUAL - 9... -
Page 10: Unit Disarming With Proximity User Key
(3 seconds in case of control unit armed from the reader installed next to it). 4.7 Remote control device functions HS520 unit can be armed/disarmed (according to settings) using TAURUS remote control when in connec- tion with HALLEY radio module. Below image illustrates additional functions of TAURUS remote control com- patible with HS520 unit. -
Page 11: Control Units Setup
5. CONTROL UNITS SETUP 5.1 Setup menu with user code when installer code is unavailable. HS520 - HS515 - HS510 USER and PROGRAMMING MANUAL - 11... -
Page 12: Menu Available For Users After The Creation Of Installer Code
5.2 Menu available for users after the creation of installer code 12 - HS520 - HS515 - HS510 USER and PROGRAMMING MANUAL... -
Page 13: Menu Available For Installers After Having Setup The Relevant Access Code
5.3 Menu available for installers after having setup the relevant access code HS520 - HS515 - HS510 USER and PROGRAMMING MANUAL - 13... -
Page 14: Control Mode System Maintenance
5.4 Control mode SYSTEM MAINTENANCE Table 0 14 - HS520 - HS515 - HS510 USER and PROGRAMMING MANUAL... - Page 15 Table 1 HS520 - HS515 - HS510 USER and PROGRAMMING MANUAL - 15...
-
Page 16: Control Mode System Setup
5.5 Control mode SYSTEM SETUP Table 2 16 - HS520 - HS515 - HS510 USER and PROGRAMMING MANUAL... - Page 17 Table 3 HS520 - HS515 - HS510 USER and PROGRAMMING MANUAL - 17...
- Page 18 Table 4 18 - HS520 - HS515 - HS510 USER and PROGRAMMING MANUAL...
- Page 19 Table 5 HS520 - HS515 - HS510 USER and PROGRAMMING MANUAL - 19...
- Page 20 Table 6 20 - HS520 - HS515 - HS510 USER and PROGRAMMING MANUAL...
- Page 21 Table 7 HS520 - HS515 - HS510 USER and PROGRAMMING MANUAL - 21...
- Page 22 Table 8 22 - HS520 - HS515 - HS510 USER and PROGRAMMING MANUAL...
- Page 23 Table 9 HS520 - HS515 - HS510 USER and PROGRAMMING MANUAL - 23...
- Page 24 Table 10 24 - HS520 - HS515 - HS510 USER and PROGRAMMING MANUAL...
- Page 25 Table 11 HS520 - HS515 - HS510 USER and PROGRAMMING MANUAL - 25...
- Page 26 Table 12 26 - HS520 - HS515 - HS510 USER and PROGRAMMING MANUAL...
- Page 27 Table 13 IMPORTANT: To properly use HS515 unit with a system based on CP100MAP.NET graphic map software, request the relevant configuration instructions. HS520 - HS515 - HS510 USER and PROGRAMMING MANUAL - 27...
-
Page 28: Control Units Tables
6. CONTROL UNITS TABLES ZONE EVENT ZONE No. CONNECTED SENSOR NAME GENERATED PARTITIONS (SECTORS) / ZONES DEFINITION 28 - HS520 - HS515 - HS510 USER and PROGRAMMING MANUAL... - Page 29 Entry time:........General alarm: ..... Tamper alarm: ............Exit time : ..................System control timer: ..........POWER FAILURE alarm delay: ............................System autonomy in case of extended power failure period: .................... HS520 - HS515 - HS510 USER and PROGRAMMING MANUAL - 29...
- Page 30 Sales Agent: ..................Phone number: ..............Technical manager: ................... Phone number: ..............Installation date: ..............Maintenance contract: - NO Remote assistance: Remote help: Mainatenance plan: every..........- NO - NO 30 - HS520 - HS515 - HS510 USER and PROGRAMMING MANUAL...
- Page 31 Actions: ................................................Intervention date: ............. Intervention date: ............. Reason(s): Reason(s): ..................................Problem found : ............Problem found : ..............................................Actions: ............... Actions: ................................................HS520 - HS515 - HS510 USER and PROGRAMMING MANUAL - 31...
-
Page 32: Table Of Contents
7. CONTENTS ................32 Microprocessor-based control units with remote control function models HS520, HS515 and HS510 USER and PROGRAMMING MANUAL Pr.
