SAVE THESE INSTRUCTIONS
BROCKPORT MOTION CHAIR ASSEMBLY INSTRUCTIONS
ASSEMBLE ON A FLAT, PROTECTED SURFACE
PART LIST
FIGURE
A
B
C
D
E
F
F
G
H
I
J
K
L
M
STYLE #: 61SRR4507BRK
QUANTITY
1 PC
1 PC
1 PC
1 PC
1 PC
1 PC
1 PC
14 PCS+1 PC
4 PCS+1 PC
10 PCS+1 PC
4 PCS+1 PC
1 PC
1 PC
1 PC
DESCRIPTION
RIGHT ARM
LEFT ARM
SEAT
BACK
GLIDER
BASE
BASE
FLAT WASHER
PLASTIC WASHER
LONG BOLT
(M6*40)
SHORT BOLT
(M6*30)
WRENCH
SEAT CUSHION
BACK CUSHION
Page 1/3
Page 1/3
Advertisement
Table of Contents
Related Manuals for Kohl's 61SRR4507BRK
Summary of Contents for Kohl's 61SRR4507BRK
- Page 1 SAVE THESE INSTRUCTIONS BROCKPORT MOTION CHAIR ASSEMBLY INSTRUCTIONS STYLE #: 61SRR4507BRK ASSEMBLE ON A FLAT, PROTECTED SURFACE PART LIST FIGURE QUANTITY DESCRIPTION RIGHT ARM 1 PC LEFT ARM 1 PC 1 PC SEAT BACK 1 PC GLIDER 1 PC 1 PC...
- Page 2 BROCKPORT MOTION CHAIR STYLE #: 61SRR4507BRK ASSEMBLY INSTRUCTIONS (CONTINUED) STEP 1 A. PLACE RIGHT ARM (A) ON A FLAT, PROTECTED SURFACE. B. CONNECT BACK (D) TO RIGHT ARM (A) WITH FLAT WASHER (G) AND LONG BOLT (I) USING WRENCH (K). DO NOT TIGHTEN COMPLETELY.
- Page 3 BROCKPORT MOTION CHAIR STYLE #: 61SRR4507BRK ASSEMBLY INSTRUCTIONS (CONTINUED) STEP 5 A. TIGHTEN ALL BOLTS FROM ALL STEPS SECURELY USING WRENCH (K). B. INSERT THE UPPER CHAIR FRAME TO BASE (F) BY USING A TWISTING MOTION AS YOU INSERT. STEP 6 A.
