Summary of Contents for ADVANCE Easy Moving VACU MATIC FREE
- Page 1 ASSEMBLY, USE AND MAINTENANCE MANUAL Fuel extraction system VACU MATIC FREE...
- Page 3 INSTRUCTION MANUAL • Type: fuel extraction system • Model: Vacu Matic Free • Revision 1.0.5 FUEL EXTRACTION SYSTEM INDEX INTRODUCTION 1.1 Use of this manual WARNINGS TECHNICAL DATA, EXPLODED VIEW DRAWINGS AND DIMENSIONS 3.1 Identifi cation plate 3.2 Safety symbols...
- Page 4 Suction case with motorized nozzle 1 INTRODUCTION Dear customer, the manufacturer would fi rstly like to thank you for the choice you made in buying an product, whose technical features will certainly meet Your needs. Our products have been designed and manufactured in total compliance with the current regulations, by choosing the best materials to obtain durability and ease of use of the product.
- Page 5 3 TECHNICAL DATA, EXPLODED VIEW DRAWNGS AND DIMENSIONS English Article AP3400.00.09 IP Protec on degree Opera ng temperature min/max °C 0 ÷ 40 Degree of humidity min/max 30 ÷ 95 Power supply V ac Frequency Motor power Max absorp on 0,14 Fuse 5x20 T2A...
- Page 6 Suction case with motorized nozzle 3.1 Identifi cation plate Do not remove or damage the identifi cation plate. Type of equipment Manufacturer identifi cation ......................CE Mark of Model: conformity P/N: S/N: Serial number Item number Technical data of the equipment 3.2 Safety symbols DANGER OF VOLTAGE OR ELECTRICAL CURRENT Danger of serious personal injuries.
-
Page 7: Packaging Content
4 PACKAGING CONTENT After opening the packaging, verify that the material contained in it conforms to the following list: 1) Extraction system 2) Assembly, use and maintenance manual English 3) Flow regulator 4) gum sleeves + 2 hose clamps 5) Warranty form Check that the product corresponds to the one ordered and that no transportation damage is evident. -
Page 8: Installation
Suction case with motorized nozzle 5.1 Characteristics of the storage tank The application of the suction case must be made at the lowest point of the hopper part of the tank. Tanks can be constructed in any form, size, and material. The hopper walls must be all connected at the point where the case is installed, so the warehouse will be able to be completely empty. - Page 9 by the components chosen for your system, is more generous, but even in these cases it is neces- sary to evaluate in advance the characteristics and technical data provided for each component installed. 4- paths with many curves or with very close curves should always be avoided. English 5- the minimum radius of the curves must be equal to or greater than 0.5 meters.
- Page 10 Suction case with motorized nozzle 6.3 Connection to the piping network CAUTION To transport fuel, use only antistatic pipes that are correctly connected to a grounding point, in order to avoid dangerous accumulation of static electricity. To connect the suction case extraction system to the installation, use always a section of antistatic fl exible hose;...
- Page 11 6.4 Electrical Connection Before making the electrical connection, check that the supply voltage corresponds to the one required and that the electrical system to which the product is connected is English done in compliance with current regulations. Connect the two wires of the activation line called AUX to the corresponding AUX cable of the integrated vacuum unit (if present) or to the corresponding terminals called AUX located inside the control panel (if present).
- Page 12 Suction case with motorized nozzle 7 START UP The operation of the suction case is managed by the fuel transport control system, which can be found in the integrated vacuum units or in the control panels; it usually happens with a delay of about 3 seconds from the start of the system: this to allow the emptying of any remaining fuel traces in the pipes.
- Page 13 8 MAINTENANCE AND END-OF-LIFE Before carrying out any maintenance operation, it is obligatory to disconnect the power supply cable from the main socket and to aerate the premises in which it is installed for English at least 15 minutes. Complex or long maintenance operations must be done out of fuel storage and heating unit premises.
-
Page 14: Safety Requirements
Suction case with motorized nozzle 9 SAFETY REQUIREMENTS FOR FUEL STORAGE TANKS SAFETY REQUIREMENTS for pellet storage tanks with capacity up to 10 t Keep the doors closed. Access is permitted only to authorized personnel under the supervision of a person outside Do not smoke and approach fl... -
Page 15: Warranty
10 WARRANTY PRODUCT LIMITED WARRANTY CONDITIONS English The Manufacturer guarantees to the original purchaser the absence of defects in material and workmanship of the product for the period stated, from the date of purchase. Except as prohibited by applicable law, this warranty is non transferable and it is limited to the original purchaser. - Page 16 Suction case with motorized nozzle 11 CERTIFICATION Declaration of absence of harmful substances The manufacturer declares that their products and equipment are made with materials compliant with the current regulations regarding protection of health and the environment and does not contain substances classifi...
- Page 17 English 18/07/22 Rev:1.0.5...
- Page 18 Suction case with motorized nozzle 18/07/22 Rev:1.0.5...
- Page 20 F0920525.2 info@advanceeasymoving.com - www.advanceeasymoving.com...
