- Page 1 Arrow WAN 2 Compact multiprotocol radio module Code INSTRUCTIONS FOR INSTALLATION, USE AND MAINTENANCE Translation of the original instructions. Before installing and using the device, please read this manual carefully and keep it with the product. Code 5000099C - 07/2022 - R1...
-
Page 2: Table Of Contents
Symbols used in this manual Warranty and relative meaning Conditions of sale and warranty The conditions of sale and warranty are avail- able on the website www.maddalena.it. WARNING! Indicates particularly important infor- Warranty limitations mation. Maddalena S.p.A. declines all responsibili-... -
Page 3: General Information
– This manual is the property of – In the event of complete destruction Maddalena S.p.A. and may not be of the device, with the electrolyte reproduced or transferred to third escaping, avoid skin and eye contact parties: all rights reserved. -
Page 4: Restrictions
1.2 Restrictions 1.3 Device description Arrow is a compact radio module for WAN 2 Maddalena MVM range water meters that PROHIBITED detects, transmits and remotely reads con- – Make modifications and/or attempt sumption values and alarms using wireless to repair the product. Any interven- transmission technology. -
Page 5: Usage Limits
1.4 Usage limits 1.5 Structure The product may only be used with compat- ible meters and in accordance with the cor- responding limits of use (see section "Radio module technical specifications"). 1 Antenna 2 NFC 3 Battery 4 Meter interface (two-way inductive sen- sor) 5 Protective cover... -
Page 6: Identification
1.6 Identification The Arrow module, identified by the la- WAN 2 bel (A), is strictly associated with a single me- ter. Two elements are required for this as- sociation, performed during installation: the serial number of the mechanical meter and the serial number of module Arrow WAN 2 1870028654... -
Page 7: Radio Module Technical Specifications
1.7 Radio module technical specifications Features Description Sensor 3-coil inductive (bidirectional) Compatible meters MVM volumetric meters Sensor resolution 1L (DN<40); 10L (DN40) Consumption exceeded, no consumption, reversed meter, Alarms backflow, leakage, flat battery, magnetic tampering, mechanical tampering Configuration Through the Android via NFC port (ISO 15693) Power supply Lithium-ion battery Battery lifespan... -
Page 8: Installation
Installation PROHIBITED Packaging material must be prop- 2.1 Receipt of the product erly disposed of and kept out of Arrow modules are supplied in two dif- WAN 2 children’s reach as it may repre- ferent formats: sent a hazard. Disposal must be 10-piece pack, already assembled on performed in line with applicable the meter... - Page 9 – Attach the Arrow module (2) to the – Attach the eyelet (3) to the catch (4) and WAN 2 relevant housing. realign the module. WARNING! Do not apply pressure to force the eyelet in. – Lower the module and offset it. –...
-
Page 10: Use
The normal operating phase is remote WARNING! reading of meters through radio modules. Reading of data can be per- In AMR (fixed) mode, each radio module formed using various software. transmits the reading at a programmable Please consult the metering op- frequency. -
Page 11: Synchronisation Of Mechanical Reading
WARNING! It is necessary to use a smart- phone with the Android operat- ing system and the relevant app provided by Maddalena S.p.A.. The app must be installed and set correctly before proceeding with the activation of Arrow WAN 2... -
Page 12: Maintenance
Maintenance 4.2 Cleaning No particular cleaning procedures are re- quired. However, the installation area 4.1 Battery should be kept clean and periodic checks The radio module is fitted with a lithium bat- should be performed to ensure the required tery that cannot be recharged or replaced. environmental conditions are met. - Page 16 Tel. +39 0432 634811 www.maddalena.it Maddalena S.p.A. reserves the right to change its products at any time and without prior notice, with the aim of improving them and without compromising primary features. All the graphic illustrations and/or photographs appearing in this document can be represented with optional accessories that vary in relation to the country where the device is used.
