Unilevel UNG660 Instruction Manual

Green 360 horizontal line plus vertial line
Hide thumbs
1
2

Advertisement

Table of Contents

Green 360 Line Laser Instruction Manual
The UNG660 is an auto levelling 360 degree green line laser with an additional vertical line. The
laser features a class 3r <5mW green output. The UNG660 is ideal for all manner of internal fit
out applications and can be used outdoors with an OPTIONAL LLR705 Line Receiver. The laser
comes with a magnetic mounting base which also allows the laser to mount on to either a survey
or camera style tripod if required. The laser is powered by a Li-ion rechargeable battery.
Laser Output 360 degree
Horizontal
Laser Output Vertical
Locking Switch
Horizontal Line
Switch

Operation

First insert the Li-ion rechargeable battery making sure the three
terminal are facing inside the battery compartment. The battery is
charged using the supplied charger. To charge remove battery from
the laser and plug directly into the battery. Note: the power socket
on the laser itself is for service use only. The charger will NOT plug
into it and charge the battery.
www.redbacklasers.com.au
UNG660
Green 360 Horizontal Line
plus Vertial Line
Low battery warning light
Vertical Line Switch
Pulse Mode / Manual Mode Button
Soft Carry Bag
Magnetic Mount with
5/8" and 1/4" Tripod Mounts
Li-ion Battery & Charger
