Manual
Somfy 230V RTS/IO
remote controlled motor
Introduction
Up
Stop
Down
Choose
channel
Quick start guide
Connecting the power
1
230V AC
Attention! Do not connect multiple
motors simultaneously, but one by one.
2
1 x
ON
230V
Always choose the right channel
before pairing or copying
a remote/channel.
www.diaz.be
Programming button
BLUE: NEUTRAL
BROWN: PHASE
1 x
5 sec
MOTOR
1 x
OK
If your motor
does not respond
as described
in this manual,
please proceed to
(pg 3).
1
Advertisement
Table of Contents
Summary of Contents for Diaz Somfy 230V
- Page 1 Manual Somfy 230V RTS/IO remote controlled motor Introduction If your motor does not respond as described Stop in this manual, Down please proceed to troubleshooting Choose Programming button (pg 3). channel Quick start guide Connecting the power BLUE: NEUTRAL 230V AC...
- Page 2 Go to 5 sec 3 sec Adjust lower limit limit Pair/remove additional remote/channel PROG. A PROG. B PROG. A PROG. B 3 sec PAIRED ADDITIONAL Favorite position Set-up Place prod. 5 sec in desired favorite position Go to favorite position www.diaz.be...
- Page 3 Connecting the first remote control 230V Check/adjust rotational direction Warning! Risk of damage. Stop the blind in time. 3 sec Set-up upper- and lower limit END RESET 3 sec Place prod. Place prod. in desired in desired upper limit lower limit www.diaz.be...
