GOAL ZERO BOLT 160L Quick Start Manual

Get to Know Your Gear
The BOLT can be used in high and low beam modes.
Twist the silver ring on the head of the BOLT to
Getting Started
1. Be sure to ACTIVATE YOUR WARRANTY at www.GOALZERO.com/warranty
2. Use with GOAL ZERO GUIDE 10 PLUS Rechargeable power pack and NOMAD 3.5
Solar Panel. Will also charge from wall, outlet and USB charger like a laptop.
All manuals and user guides at all-guides.com
How to Use Your Gear
LIGHT IT
FOCUS IT
adjust the focus of the beam.
CHARGE IT
Recharge from any USB.
POWER IT
Click button to switch between high and low.
On/Off Button
Switch between 100 and 50% brightness by pressing power
button on and off; or by pressing half way while unit is on.
Focus Zoom
Twist the ring at the head of the flashlight to adjust from
wide angle to spot.
Indicator Light
The charging indicator light is below the flashlight head. Red
light indicates charging. Green light indicates full charge.
USB Charging
To charge, rotate the rubber ring below the indicator light
to reveal mini-USB port. Plug into the mini-USB, then plug
other end of the cord into a USB power source.
Technical Specs
Usage
Run time 3+ hours
Recharge time 5 hours
Inputs
Charging port Mini-USB jack, 5V, 0.5A max (2.5W)
Outputs
Light Power: 3W, white CREE LED
Life-span: 10s of thousands of hours
Visible distance: 120 meters
Internal
Battery Lithium-ion 18650, 3.7V, 2Ah (7.4 Wh)
Battery mgmt. Integrated and fully automatic
General
Weight 6 oz (0.17 kg)
Dimensions 1.5x1.5x6.5 in (3.8x3.8x16.5 cm)
Warranty 12 months
Optimal operating temp. 32-104ºF (0-40ºC)
Comes With
USB charger
AC wall charger
