Firesense Dalton 63224 Manual

Square aluminum lpg fire pit

Advertisement

Quick Links

Dalton Square Aluminum LPG Fire Pit
*ELECTRONIC IGNITER!
Requires AAA Battery (not included)
This fire pit requires a minimum 18 inches of cross-ventilation in all directions.
Failure to provide proper ventilation can void the warranty.
ATTACH YOUR
RECEIPT HERE
Keep a copy of your proof of
purchase or order confirmation
which will be needed if you
need to contact us about
warranty coverage.
Purchase Date:
Before returning to your retailer, our Florida-based customer service team is available to help:
Installation Precaution
866
Conforms to ANSI STD Z21.97-2014,
Certified to CSA STD 2.41-2014 Outdoor decorative gas appliances
Item#: 63224
WARNING
FOR YOUR SAFETY
1. Improper installation, adjustment,
alteration, service or maintenance can
cause injury or property damage.
2. Read the installation, operation, and
maintenance instructions thoroughly
before installing or servicing this
equipment.
3. Failure to follow these instructions
could result in fire or explosion, which
could cause property damage, personal
injury, or death.
WARNING
For Outdoor Use Only
WARNING
This product can expose you to chemicals including
Carbon Monoxide, Lead, Chromium (hexavalent
compounds), Di(2-ethylhexyl) phthalate (DEHP) and
Diisononyl phthalate (DINP), which are known to the
State of California to cause cancer and birth defects
or other reproductive harm. For more information, go
to www.P65Warnings.ca.gov.
02032022

Advertisement

loading
Need help?

Need help?

Do you have a question about the Dalton 63224 and is the answer not in the manual?

Questions and answers

Summary of Contents for Firesense Dalton 63224

  • Page 1 Item#: 63224 Dalton Square Aluminum LPG Fire Pit *ELECTRONIC IGNITER! Requires AAA Battery (not included) WARNING FOR YOUR SAFETY 1. Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. 2. Read the installation, operation, and maintenance instructions thoroughly before installing or servicing this equipment.
  • Page 2: Table Of Contents

    www.balkenehome.com TABLE OF CONTENTS Table of Contents Page 2 Page 2 Before You Begin Package Contents Page 3 Safety Information Page 4 Assembly Pages 5-8 Operating Instructions Pages 9-12 Conversion to Natural Gas Pages 13-15 Care and Maintenance Page 16 Troubleshooting Page 17 Warranty Information...
  • Page 3 Removable Burner Cover Burner Table Top Door Panel Side Panels Door Frame Leg Support Legs Tank Support Protective Cover Fire Glass Stud (6x40mm) Bolt (8x20mm) Washer/Spring Washer (M8) Bolt (6x16mm) Washer (M6) Spring Washer (M6) Qty: 13 Qty: 5 Qty: 5 Qty: 6 Qty: 18 Qty: 13...
  • Page 4: Safety Information

    SAFETY INFORMATION SAFETY INFORMATION DANGER DANGER This appliance has been tested to and FOR YOUR SAFETY EXPLOSION—FIRE HAZARD • Keep solid combustibles, such as building If you smell gas: complies with the ANSI Z21.97-2014, Outdoor Decorative Gas Appliances CGA CR 97-003 materials, paper, or cardboard a safe distance 1.
  • Page 5: Assembly

    ASSEMBLY PREPARATION Before beginning assembly, empty contents of carton and make sure all parts are present. Place all parts on a soft, level surface for assembly. NOTE: It is best to use TWO PEOPLE to assemble this gas fire pit. Estimated Assembly Time: 60 Minutes | DO NOT over tighten hardware! Assemble the fire pit base: Locate Door Panel D, 3 Side Panels E, Side Panel...
  • Page 6 ASSEMBLY Attach Tank Support bar to Leg F/G by aligning holes at each end of Tank Support bar with holes at the bottom of Legs. Insert Bolt P through Washer Q into holes. Tighten gently with Hex Wrench W. Then attach Tank Support ring to the leg of Door Panel D by aligning hole in front of Tank Support ring with hole in Leg.
  • Page 7 ASSEMBLY Pour the Fire Glass L around the Burner. Be careful not to obstruct the pilot light housing. Put the Removable Burner Cover A on the Burner when not in use. When the fire pit is not in use or after use, when the fire pit has cooled COMPLETELY, cover it with the Protective Cover K.
  • Page 8 ASSEMBLY Connect hose and regulator to cylinder. The propane gas and cylinder are sold separately. Use a standard 20lb propane cylinder have this book. Storage of an appliance indoors is permissible only if the cylinder is disconnected and removed from the appliance. A cylinder must be stored outdoors in a well-ventilated area out of the reach of children.
  • Page 9: Operating Instructions

    OPERATING INSTRUCTIONS Contact us for assistance: (866) 985-7877 | www.balkenehome.com...
  • Page 10 OPERATING INSTRUCTIONS LEAK CHECK WARNING! Hose / Regulator Regulator / Cylinder Connection Connection If bubbles appear at any connection there is a leak. is at hose/ If NO bubbles appear at any connection, the connections are secure. NOTE: Whenever gas connections are loosened or removed, you must perform a complete leak test. Complete installation.
  • Page 11 OPERATING INSTRUCTIONS CAUTION WARNING DANGER! WARNING Very hot while in operation! FOR OUTDOOR USE ONLY FOR YOUR SAFETY CARBON MONOXIDE HAZARD OPERATION CHECKlIST: For a safe and pleasant heating experience, review this checklist before each use: BEFORE TURNING GAS SUPPLY ON:...
  • Page 12 OPERATING INSTRUCTIONS DANGER! NOTE: FOR OUTDOOR USE ONLY CARBON MONOXIDE HAZARD BEFORE LIGHTING : WHEN FIRE PIT IS ON: Troubleshooting LIGHTING : NOTE: Use only your hand to depress or turn the gas control knob. Never use tools. If the knob will not depress or turn by hand, DO NOT try to repair it.
  • Page 13: Conversion To Natural Gas

    CONVERSION TO NATURAL GAS WARNING Orifice Chart Propane (Pressure 11”) NG (Pressure 7”) NG Hose and Regulator Conversion Tools Required: • WARNING...
  • Page 14 CONVERSION TO NATURAL GAS WARNING! WARNING! WARNING! Thermocouple Wire Tank Access Door Flex Line Connector Valve Connector Valve Burner Pipe Air Shutter Burner Pipe Propane Orifice Connector Valve Propane Orifice Natural Gas Orifice Connector Valve Burner Pipe Flex Line Connector Valve Burner Conversion Label Conversion Kit...
  • Page 15 CONVERSION TO NATURAL GAS Natural Gas Hook-Up Purge the gas supply line of any trapped air prior to the first firing of the unit. WARNING!
  • Page 16: Care And Maintenance

    CARE & MAINTENANCE STORAGE Between Uses: During periods of extended inactivity or when transporting: Note: In a salt-air environment (such as near an ocean), corrosion occurs more quickly than normal. Frequently check for corroded areas and repair them promptly. Note: WARNING SERVICE: Caution:...
  • Page 17: Troubleshooting

    TROUBLESHOOTING CORRECTIVE ACTION PROBLEM POSSIBLE CAUSE...
  • Page 18 an additional year Before returning 9 a.m. – 6 p.m., EST, Mon – Fri...
