Summary of Contents for Step comm Earlite 1100

  • Page 1 Earlite 1100 ™ User’s Guide STEP Communications 625 River Oaks Parkway San Jose, CA 95134 Tel. 408-474-0272...
  • Page 2 Communications Corp. can void the user's authority to operate the equipment. BLUETOOTH is a trademark of the Bluetooth SIG, Inc. The Bluetooth logo and trademarks are owned by Bluetooth SIG, Inc. Earlite 1100 is a trademark of STEP Communications Corporation Copyright © 2003 STEP Communications Corporation All rights reserved...

  • Page 3: Guidelines For Safe And Efficient Use

    Guidelines for Safe and Efficient Use Clean your earpiece with a lightly dampened soft cloth only. Solvents or other chemicals may damage your earpiece and void your warranty Keep your earpiece away from extreme temperatures, water, exceptionally high humidity environments, dusty environments, open flame or fire.
  • Page 4 E A R L I T E 1 1 0 0 ™ I N T R O D U C T I O N What is Bluetooth Wireless Technology? ™ Bluetooth wireless technology makes it possible to connect compatible communication, computing and other consumer electronic devices without using cables.
  • Page 5 You can handle incoming and outgoing calls, and adjust the volume using the single ‘rocker switch’ on your Earlite 1100 earpiece. Simply rotate the rocker switch forward two times to increase the volume or back two times to decrease the volume for each incremental level.

  • Page 6: Table Of Contents

    E A R L I T E 1 1 0 0 ™ I N T R O D U C T I O N Contents Overview ……………………………………….…. 1 Getting Started …... …………………………….…. 2 Features & Controls …………………………….…. 3 Using the Multi-Function Control ………………….. 4 Charging Your Earpiece ……………………………...

  • Page 7: E A R L I T

    Earlite 1100 earpiece has to be compatible with Bluetooth wireless technology and support the headset profile version 1.1. To be able to use the Earlite 1100 earpiece together with a mobile phone, you need to have a phone with built-in Bluetooth capability or a phone with an optional STEP 2000 wireless Bluetooth adapter connected to it.

  • Page 8: Getting Started

    ™ Before you use the Earlite 1100 earpiece with a phone or other devise for the first time, you should do the following: Charge the earpiece. Decide on which ear you want to wear the earpiece (it can be worn on your right or left ear) Pair the earpiece with a device, for example, a mobile phone, PDA or desktop computer.

  • Page 9: Features & Controls

    E A R L I T E 1 1 0 0 ™ Features & Controls...

  • Page 10: Using The Multi-Function Control

    1 1 0 0 ™ Using the Multi-function Control ™ The multi-function control on the Earlite 1100 is used to perform a variety of functions, including turning the earpiece on, turning the earpiece off, adjusting the volume, performing basic call functions and pairing your earpiece to your phone or Bluetooth device.

  • Page 11: Charging Your Earpiece

    Charging Your Earpiece The earpiece comes with a built-in rechargeable Lithium- Polymer battery that will provide you with approximately 4 hours of talk time or 110 hours of standby time. Be sure to charge the earpiece for a minimum of 4 hours before using the unit for the first time.

  • Page 12: Charging & Led Status Matrix

    ™ Your Earlite 1100 will be fully recharged after approximately 4 hours of charging, and approximately 80% of a full charge after only 2 hours of charging. The table below explains the various modes of the LED indicator during charging.

  • Page 13: Connecting Your Earpiece To The Charger

    Connecting Your Earpiece to the Charger ™ Your Earlite 1100 is shipped with an auto-switching power supply able to be used with voltages between 100V-240V AC. The plug configuration of the power supply is appropriate to the country in which your earpiece was purchased.
  • Page 14 E A R L I T E 1 1 0 0 ™ Note: the charging adaptor is ‘keyed’ to fit only one way into your earpiece. Do not force the adaptor cable into the connecting port of the earpiece as this may damage your earpiece and void your warranty.

  • Page 15: Adjusting Your Earpiece For Maximum Comfort

    You can also adjust the fit of your earpiece by gently forming or bending the neck of the unit so that it is placed deeper into your ear. Remember though, that the Earlite 1100 was designed to deliver clear sound without blocking your ear, and thereby removing surrounding natural sounds.
  • Page 16 1 1 0 0 ™ Preparing to Wear Your Earpiece ™ Your Earlite 1100 can be worn on either your right or left ear. The unit is set up at the factory for use on your right ear. If you...
  • Page 17 E A R L I T E 1 1 0 0 ™ Forming the Neck of Your Earpiece ™ The neck of your Earlite 1100 can be positioned or bent to conform to the shape of your ear to provide maximum comfort and sound delivery.
  • Page 18 E A R L I T E 1 1 0 0 ™ Putting on the Earpiece When putting on the earpiece, first place the ear bud at the entrance of your ear, with the ‘body’ of the earpiece slightly above your ear. Gently place the body of the earpiece behind your ear using a slight rotational motion as...

  • Page 19: Pairing The Earpiece To Your Phone

    Pairing the Earpiece to Your Phone Before you start using the earpiece for the first time, you must pair the earpiece with the device you want to use it with, such as a mobile phone. ™ 1. Activate the Bluetooth pairing function on your phone or other device.
  • Page 20 screen prompts on your phone or other device to pair it with the earpiece. 4. When prompted, enter the earpiece passkey of 0000. If the pairing is successful, your earpiece indicator light will flash green. If your phone or device does not find the earpiece, turn off the earpiece by pressing down the multi-function control for approximately 5 seconds, reset your phone or device to the beginning of the Bluetooth pairing process and repeat steps...

  • Page 21: Resetting The Earpiece

    When pairing the earpiece to a new Bluetooth want to reset the Earpiece to its default settings. This clears all current pairings. To reset the Earpiece: 1. With the Earpiece turned off, depress and hold down the Multi-function control for 12 seconds. LED will flash green for approximately 2-3 seconds, then red and green for approximately 7-8 seconds, then orange.

  • Page 22: General Operation

    To turn the Earpiece on: Press and hold down the multi-function control for approximately 2 seconds or until you hear two short tones (a low tone followed by a high tone) To turn the Earpiece off: Press and hold down the multi-function control for approximately 4 seconds or until you hear two short tones (a high tone followed by a low tone)

  • Page 23: Adjusting The Volume

    E A R L I T E 1 1 0 0 ™ Adjusting the Volume You can adjust the earpiece listening volume during a call by rocking the multi-function controller wheel forward twice for each volume level increase you desire. To decrease the volume, rock the multi-function controller wheel backwards twice for each volume level decrease you desire.

  • Page 24: Making And Receiving Calls

    1 1 0 0 ™ Making and Receiving Calls ™ Once you have paired the Earlite 1100 with your phone, you can make and receive calls using the earpiece as long as it is turned on and within range of the phone (up to 10m./30 ft).
  • Page 25 calls with your voice commands. To make a call using voice dialing 1. Make sure the phone and the earpiece are on and within range of each other. Press down the multi-function control once. 2. After the beep, voice dial as you normally would. 3.
  • Page 26 1. When the phone rings or when you hear your phone ring through the earpiece, briefly press down the multi-function control once. 2. End the call by pressing down the multi-function control on your earpiece, or the END or NO key on the phone. Answering a second call (if your phone supports multiple incoming calls) You must use the phone keypad to answer and handle a...

  • Page 27: Muting A Call

    E A R L I T E 1 1 0 0 ™ Muting a Call If you need to ‘mute’ a call during your conversation, rotate and hold the multi-function control forward or backward for approximately 5 seconds (be sure not to press down on the multi- function control as this will end your call).
  • Page 28 E A R L I T E 1 1 0 0 ™ Transferring Communication & Sound from your Phone to the earpiece If you initiate a call without using the earpiece, you can transfer the call to the earpiece if the earpiece is on, paired with the phone and within range.

  • Page 29: Quick Reference Guide

    E A R L I T E 1 1 0 0 ™ Quick Reference Guide To turn the unit on: depress & hold down the multi- function control for 2 seconds or until the LED flashes green To initiate the pairing process: the unit must first be turned off.

  • Page 30: Troubleshooting

    E A R L I T E 1 1 0 0 ™ Troubleshooting ™ As new phones and Bluetooth devices are being released at an increasing rate, there may be updated pairing and operational instructions available on-line for your particular device. For additional instructions and instructions for new devices, please visit www.stepcommunications.com/userguide/update To view an interactive list of FAQs (Frequently Asked...

  • Page 31: Technical Specifications

    Frequency Response 300 to 3400 Hz Distortion (THD %) 2% (typical) Microphone Frequency Response 300 to 3400 Hz S/N Ratio 36 dB @ 1 KHz Wireless Link Type Bluetooth Radio Module (Profile v1.1) Frequency 2.4 GHz - ISM Band (2400-2483.5 MHz) Useful Range 10 meters from device Compliance...

  • Page 32: End User Limited Product Warranty

    E A R L I T E 1 1 0 0 ™ End User Limited Product Warranty STEP Communications warrants this product to be free from defects in manufacturing for 1 year from the date of original retail purchase when used in strict accordance with the guidelines set forth in the User Manual.
