Summary of Contents for Ariva HbbTV T800i
- Page 1 User manual English Version 01...
- Page 2 Ferguson Sp. z o.o.
-
Page 3: Table Of Contents
Content 1 Reference ......................5 1.1 General Features ..................5 2 Product Overview ....................6 2.1 Front Panel ....................6 2.2 Rear Panel ....................6 2.3 Side Panel ....................7 2.4 Remote Control Unit (RCU) ................7 3 System ........................9 3.1 Information ....................10 3.2 Factory Reset ..................... - Page 4 Ferguson Sp. z o.o. 5.5 HbbTV ......................13 5.6 LCN ......................13 5.7 Auto Sleep ....................13 6 USB ........................14 6.1 PVR ......................14 6.2 Movie ......................14 6.3 Music ......................14 6.4 Photo ......................14 6.5 PVR Config ....................14 6.6 Format ......................
-
Page 5: Reference
Reference General Features DVB-T2 Compliant (MPEG-II/ MPEG-IV/ H.264/ H.265) PAL/NTSC Conversion Favorite group and parental lock supported Multi-language menu supported Multi-language audio supported Multi-language subtitle 7 days Electronic Program Guide (EPG) Teletext output through VBI and OSD ... -
Page 6: Product Overview
Ferguson Sp. z o.o. Product Overview Front Panel 1. POWER LED: Power Indicator. 2. SIGNAL LED: Signal Indicator. 3. Display: It displays channel information. 4. POWER: Switch between operation and standby modes. 5. ▲/ ▼: Change channels while watching programmers or change option from up to down. -
Page 7: Side Panel
2. LAN: Connect to the internet using an Ethernet cable. 3.COAXIAL: Digital Audio output. 4. HDMI: Connect to the TV using a HDMI cable. 5. TV SCAET: Connect to the TV using a Scart cable 6. DC 12V: Connect to the power. Side Panel 1. - Page 8 Ferguson Sp. z o.o. 8. RECALL: Show the previous viewed channels list. Or switch to the previous viewed channel. 9. FAV: Display favorite channel list you set before. 10. VOL-◄/VOL+►: Change volume in viewing mode; move up and down in the menu. 11.
-
Page 9: System
22. ►: Play the USB media or play the timeshift. 23. I I: Pause/time shift. 24. ►►: Fast Forward. 25. ●REC: Record. 26.I◄◄: Previous. 27. ►► I: Next. 28.■：Stop. 29. F1: Additional function button for the menu. 30. TIMER: Enter the timer menu quickly. 31. -
Page 10: Information
Ferguson Sp. z o.o. Information Information show you the Hardware Version/ Software Version/ Loader Version/ HbbTV Version/ STB Identifier /MAC Address. Factory Reset This operation will delete all channels and others settings. Software Upgrade Copy the extracted upgrade software to the USB. Find the software, select and press OK button to upgare. -
Page 11: Channel Manage
4.1.1 Antenna Power Here you can set the 5V power on or off. 4.1.2 Search Mode Auto: Search automatically and save the found channels. Manual: You can choose different Frequency to search for programs. 4.1.3 Frequency Here you can choose different Frequency to search for programs. 4.1.4 4.1.4 Band Width It can fit to the Frequency menu. -
Page 12: Parental Guidance
Ferguson Sp. z o.o. Lock: Lock the program you want. Skip: set the programs to skip. Parental Guidance Allows you to set age limits for the program, Here you can set Off/ 4/ 5/ 6/ 7 /8 /9 /10 /11 /12 /13 /14 / 15/ 16/ 17/ 18. Program Guide You can view the EPG information of all channels in time and date order. -
Page 13: Osd Language
OSD Language Set the menu language. Audio Language Set the preferred audio language. Subtitle Language Set the subtitle language. Audio Description If you set ON, it will open the audio description. HbbTV If you set ON, it will open the HbbTV function. If you set ON, it will open the LCN. -
Page 14: Usb
Ferguson Sp. z o.o. Here you can playback the files you recorded. And the recorded files are saved in folder name PVR. Movie It supports: .mkv, .avi, .mp4, .vob, .ts, .mt2s, .flv, .mpg, .3gp, .mov format movie files. It will enter full screen mode after press OK button. Music It supports .mp3, .mp2, .aac format music files. -
Page 15: Format
Here you can set the partition and timeshift limit size. Format If you press OK button, it will see notification: all data will be delete, do you want to format this partition? Settings Password... -
Page 16: Time Offset
Ferguson Sp. z o.o. The default password is 0000, if you want to change the password, should input the old password, new password and confirm password. Time Offset Time Zone: Here you can set Auto or Manual. Time Offset: If you set time zone is manual, you can use ◄/ ► button to set the time offset. -
Page 17: Av Setting
AV Setting Digital Audio: Here you can set PCM or RAW. Aspect Mode: Set the display format according to the screen ratio. Select TV screen mode either 4:3 or 16:9 according to the TV type,Here you can set 16:9 Pillar Box/ 16:9 Full Screen/ 16:9 Extended/ 4:3 Letter Box/ 4:3 Pan &... -
Page 18: Timer
Ferguson Sp. z o.o. WLAN: Here you can plug in the WIFI dongle, and show the AP list. Ethernet: Here you can plug in the network cable, and show the IP Address. Timer Here you can set events. It will record or play the program automatically according to the timer event list that you set. - Page 19 HbbTV system is a combination of two networks, broadcast and broadband. broadcast network is a DVB network (DVB-T/T2, DVB-S, and DVB-C). A hybrid receiver has the capability of connecting to broadband and broadcast networks in parallel HbbTV service is divided into two types based on their relationship with the content of TV: programs: HbbTV service related to the content of on-air TV program: ...
- Page 20 Ferguson Sp. z o.o. Connect to network (WLAN or Ethernet), play the DVB program with HbbTV function , the red button displays HbbTV services. In order not to annoy the user with undesired overlays and to allow a uniform experience for the application start, first a small icon on the TV is displayed which informs the user that HbbTV services are available.
-
Page 21: Trouble Shooting
Trouble Shooting Before contacting service centre, please read the tips below carefully. If the problem persists after completing the following procedure, please contact your local product distributor or service centre for further instructions. 1. No message displayed on the front display. (The product will not switch on.) •... - Page 22 • Make sure the Ethernet cable is inserted firmly to the LAN router. • Make sure the WiFi can work on other device. SIMPLIFIED DECLARATION OF CONFORMITY Producer: Ferguson Sp. z o.o., ul. Dworska 1, 61-619 Poznań Name: Ferguson Ariva T800i HbbTV Device type: Digital terrestrial TV receiver...
- Page 23 The above-mentioned product complies with Directive 2014/53/EU of the European Parliament and of the Council of 16 April 2014 on the harmonization of the laws of the Member States relating to the making available on the market of radio equipment and repealing Directive 1999/5/EC.
- Page 24 Ferguson Sp. z o.o.
