Summary of Contents for MYiR MY-WF003U
- Page 1 MY-WF003U USB Wi-Fi Module MY-WF003U USB WiFi Module User Manual V1.2 2015/4/1...
- Page 2 MY-WF003U USB Wi-Fi Module Version Record Version Description Release Time V1.0 Initial version 2013/11/20 V1.1 Add AM335x, AM437x, Z-turn eval board support 2015/3/18 V1.2 Firmware copy 2015/4/1...
-
Page 3: Table Of Contents
MY-WF003U USB Wi-Fi Module Table of Contents Chapter 1 Overview ..........................4 1.1 Product Introduction ..........................4 1.2 Product Images ............................ 4 Chapter 2 Features ........................... 5 2.1 Hardware and Software Features ...................... 5 2.2 Products Supporting List ........................6 Chapter 3 Interface Definition ......................... -
Page 4: Chapter 1 Overview
Chapter 1 Overview 1.1 Product Introduction MY-WF003U is a USB WiFi Module released by MYIR especially for working on MYIR's MYD-SAMA5D3X, MYD-SAM9X5andMYD-SAM9X5-V2 series ARM development boards. It is relying on the WiFi IEEE 802.11b/g/n standards and its network speed can achieve 150Mbps when using the IEEE 802.11n standard.It is connected with other terminals through a USB2.0 Host port to build a wireless... -
Page 5: Chapter 2 Features
Chapter 2 Features 2.1 Hardware and Software Features The MY-WF003U USB WiFi Module is using USB 2.0 interface for connections, it is small in size with high performance and low power consumption and can be connected to Routers or many kinds of mobile terminals for extensive communications. -
Page 6: Chapter 3 Interface Definition
MY-WF003U USB Wi-Fi Module Chapter 3 Interface Definition The USB2.0 interface definition is as below in table 3-1: Signal Definition Image VBUS Table 3-1 Signal Definition of USB 2.0 Interface of MY-WF003U 6/15... -
Page 7: Chapter 4 Testing Usb Wifi In Linux
MY-WF003U USB Wi-Fi Module Chapter 4 Testing USB WiFi in Linux 4.1 Cross-compiler Installation For different platforms, please use different toolchains. Take arm-2010q1 as an example. ⑴ Decompress the cross-compiler tool arm-2010q1-202-arm-none-linux- under the “Cross_Tools” folder in DVD. For decompressing to /usr/local/arm/ as an example: $ sudo tar xvjf arm-2010q1-202-arm-none-linux-gnueabi.tar.bz2 -C /uar/local/arm... -
Page 8: Atmel Sama5 Series
$ cd rtl8188C_8192C_usb_linux_v4.0.2_9000.20130911 ⑶ Compile driver $ export CROSS_COMPILE=/usr/local/arm/arm-2010q1/bin/arm-none-linux-gnueabi- $ make ARCH=arm KSRC=/media/data/myir/myd-sam9x5/Linux/linux-2.6.39 CROSS_COMPILE indicates the corresponding folder and prefix of the cross-compile tool. KSRC means the Linux kernel source code location of the target board. These two variables are assigned according to actual conditions. -
Page 9: Z-Turn
⑷ Copy the firmware to Board. Copy the firmware to /lib/firmware/rtlwifi/rtl8192cufw_TMSC.bin of Board, you can find it in the CD ROM ‚MY-WF003U USB WIFI Module/Linux/Tools/firmware/rtl8192cufw_TMSC.bin”. ⑸ Load driver module on development board Copy rtl8192c-common.ko、rtlwifi.ko、rtl_usb.ko、rtl8192cu.ko to development board，And execute following command to insmod driver on development board: # insmod rtl8192c-common.ko... -
Page 10: Configure Wlan Through Wap Tool
4.5 Configure WLAN through WAP Tool Insert the MY-WF003U USB WiFi Module and then use WAP to configure wlan. How to use wap tool and steps to configure wlan is as follow. -
Page 11: Using The Command Line Configuration
It is always needed that network can be connected automatically when power on. Here use below to implement this function through using the MY-WF003U USB WiFi module. ⑴ Copy the former compiled driver file 8192cu.ko to the development board driver automatically... - Page 12 ⑵ Modify the network configuration file Modify the file “/etc/network/interfaces” and add below contents to enable wlan0 in order to connecting to the network and acquiring the IP (DHCP) automatically. Here connecting with MYIR, as an example. The network configuration is as below:...
-
Page 13: Warranty & Technical Support Services
Delivery Time MYIR will always keep a certain stock for its regular products. If your order quantity is less than the amount of inventory, the delivery time would be within three days; if your order quantity is greater than the number of inventory, the delivery time would be always four to six weeks. - Page 14 2) Please do not use finger nails or hard sharp object to touch the surface of the LCD. 3) MYIR suggests user purchasing a piece of special wiper to wipe the LCD after long time use, please avoid clean the surface with fingers or hands to leave fingerprint.
- Page 15 During the warranty period, the shipping cost which delivered to MYIR should be responsible by user; MYIR will pay for the return shipping cost to users when the product is repaired. If the warranty period is expired, all the shipping cost will be responsible by users.
- Page 16 Mouser Electronics Authorized Distributor Click to View Pricing, Inventory, Delivery & Lifecycle Information: MYIR Tech MY-WF003U...
