- Page 1 Toll-free: 800 CASCADE (227.2233) Telephone: 503-669-6257 cascadewedgelock@cascorp.com NORTH AMERICA THIS OPERATORS MANUAL MUST BE KEPT WITH THE CARRIER MACHINE AT ALL TIMES...
-
Page 3: Table Of Contents
CONTENTS NORTH AMERICA PAGE SECTION 1: SAFETY 1.0 I-LOCK™ SAFETY SYSTEM 1.1 INTEGRATED DESIGN FEATURES 1.2 SAFE COUPLER USE SECTION 2: OPERATION 2.0 CONNECTING TO THE FIRST PIN 2.1 CONNECTING TO THE SECOND PIN 2.2 TO DISENGAGE THE SECOND PIN 2.3 TO DISENGAGE THE FIRST PIN... -
Page 4: Section 1: Safety
1.0 I-LOCK™ SAFETY SYSTEM The I-LOCKTM Coupler by Wedgelock must be installed correctly utilizing our 3 hose circuit technology. Correct installation ensures that the I-LOCK™ Coupler’s built in safety features operate in accordance with the way in which the coupler has been designed. -
Page 5: Integrated Design Features
WEDGE LOCKING PRINCIPLE Another safety feature of the I-LOCK™ Coupler is the Wedge Locking Principle. The locking principle of the primary wedge provides at least 2.5 times the locking force compared with a swinging jaw coupler. -
Page 6: Safe Coupler Use
Never place your hands inside the coupler or anywhere near the linkage mechanism while the hydraulic system is pressurized or the carrier machine is turned on. Never use the Primary Locking Wedge or I-LOCK™ Safety Knuckle as a lifting device. FOR INFORMATION RELATING TO “SAFE LIFTING PROCEDURES” REFER TO SECTION 5 OF THIS MANUAL. -
Page 7: Connecting To The First Pin
(Fig 2.0.1) Buzzer Mode The Audible Buzzer is sounding (Fig 2.0.2) (once every second) I-Lock™ Coupler Mode The Primary Wedge is retracted The Safety Knuckle is in the safe position (Fig 2.0.2) Operator Action Using the excavator arm control levers move front jaw of the coupler over the first pin (front pin) of the attachment. -
Page 8: To Disengage The Second Pin
*Depress the Momentary Switch for more than one second to activate the release of the Safety Knuckle. Using the excavator arm control levers crowd the I-Lock™ Coupler away from the first attachment pin. (Fig 2.3.1) Switch Mode The Lock-Out Switch is ON (Fig 2.3.2) -
Page 9: Ready To Re-Connect
Audible Buzzer will return to sounding once every second. (Fig 2.4.1) (Fig 2.4.1) The I-Lock™ Coupler is ready to be re-connected to the next attachment. (Fig 2.4.2) To re-connect to your next attachment refer to: SECTION 2.0 CONNECTING TO THE FIRST PIN (Fig 2.4.2) -
Page 10: Normal Operating Procedure - Flow Diagram
SECTION 2: OPERATION NORTH AMERICA 2.5 NORMAL OPERATING PROCEDURE - (FLOW DIAGRAM) Normal Operation Timer Adjustment Power Off Power Off Turn Power ON Press and hold MOMENTARY SWITCH using LOCK OUT SWITCH 1 beep / Wedge retracts Turn Power ON using second 4 short beeps then 1 beep /... -
Page 11: Section 3: Maintenance
MAX PRESSURE (Fig 3.0.1) WARNING: Wedgelock Quick Couplers that incorporate a factory fitted lifting eye will be labeled and marked with a Working Load Limit (WLL). The lifting eyes are designed in accordance with BS-2573:Part1. It is highly recommended that a Bow Type Shackle be used to connect to the lifting eye. -
Page 12: Section 4: Trouble Shooting
SECTION 4: TROUBLE SHOOTING NORTH AMERICA 4.0 TROUBLE SHOOTING GUIDE PROBLEM CHECK REMEDY Check hydraulic line to I-Lock™ If damaged or leaking repair or Safety Knuckle replace Check operating pressure of Adjust operating pressure on hydraulic line to I-Lock™ Safety... - Page 13 SECTION 4: TROUBLE SHOOTING NORTH AMERICA 4.0 TROUBLE SHOOTING GUIDE – cont’d PROBLEM CHECK REMEDY 3. The I-Lock™ Safety Knuckle Check for damage to Knuckle Replace parts if required is slow to or partially activates. blade or Knuckle damage (cont’d)
-
Page 14: Section 5: Safe Lifting Procedure
The following diagram indicates the safe working loads of the certified lifting eyes that are either part of the side plate or welded to the rear plate of your Wedgelock Coupler. If you can’t identify the working load limit from either the aluminum data plate that is stamped on the coupler or the chart below please contact Cascade Corproation immediately for further assistance. -
Page 15: Section 6: Warranty
Standard Limited Warranty Policy WARRANTY INCLUSIONS Cascade Corporation warrants all Wedgelock Quick Couplers to be free from defect in material and workmanship for a period of 12 months (365 days) or 2000 machine hours, whichever occurs first, from the date of delivery to the End User or Dealer (“the Customer”). - Page 16 SECTION 6: WARRANTY NORTH AMERICA WEDGELOCK OBLIGATIONS At its option, Cascade Corporation may repair or arrange for the repair and/or full or partial replacement of a defective part or attachment. Any repair work may be carried out at Cascade Corporation's own...
-
Page 17: Section 7: Warranty Registration
SECTION 7: WARRANTY REGISTRATION NORTH AMERICA 7.0 WARRANTY REGISTRATION FORM Once you have read and understood both the INSTALLATION and OPERATORS manuals please complete and return this form by email to Cascade Corporation to ensure that your product purchase is registered and covered under our standard warranty terms. Send to: CascadeWedgelock@cascorp.com INSTALLER TO COMPLETE I acknowledge that I have read and understood the Installation &... - Page 18 NORTH AMERICA PO Box 20187 • Portland, OR 97294-0187 • USA • 800 CASCADE (227.2233) • Tel 503.669.6257 • www.wedgelockusa.com Cascade and Wedgelock are registered trademarks of Cascade Corporation. Form 6827659 150 GE 2/12 © Cascade Corporation 2013. All rights reserved.
