VESTEL QN65B/4F User Manual

65” (164cm) digital signage display

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

65" (164cm) DIGITAL SIGNAGE DISPLAY

USER MANUAL

QN65B/4F

ENGLISH

Table of Contents

Need help?

Do you have a question about the QN65B/4F and is the answer not in the manual?

Questions and answers

Summary of Contents for VESTEL QN65B/4F

Page 1 65” (164cm) DIGITAL SIGNAGE DISPLAY USER MANUAL QN65B/4F ENGLISH...
Page 3: Table Of Contents
Contents Important Safety Information ........2 General View ............6 Control Buttons on the Display .......7 Connecting the IR Receiver........8 Turning the Display On/Off ........8 Remote Control ............9 First Time Installation..........10 Using Main Display Menu ........10 Vsign Lite .............. 11 Media Playback via USB Input ......12 CEC and CEC RC Passthrough ......13 Usage of the Start URL ........13 Settings Menu Content .........15...
Page 4: Important Safety Information
• Please place the product in a position that electric Important Safety Information cables cannot be affected by the operations on the product. CAUTION • Follow all warnings and instructions marked on the RISK OF ELECTRIC SHOCK product. DO NOT OPEN •...
Page 5 • Do not shake the product. Ensure that it stays in a Safety checks balanced stance on its position. Upon completion of service or repair work, request the service technician to perform safety checks to ensure • Do not throw or drop any object on your product. that the product is in proper operating condition.
Page 6 monitor where it cannot be pushed, pulled over, or Foreseeable misuse and incorrect use knocked down. • For apparatus intended to be used in vehicles, ships • Care should be taken to route all cords and cables or aircraft or at altitudes exceeding 2000m above sea connected to the monitor so that they cannot be level, for outdoor use or in general for the application pulled or grabbed by curious children.
Page 7 • Remove dead batteries from equipment and all Markings on the Product batteries from equipment you know you are not going to use for a long time. Otherwise the batteries may The following symbols are used on the product as leak and cause damage.
Page 8: General View
General View Front Side 1. LCD Panel Rear Side (1) 1. RS232 9. IR Input 2. VGA 10. Headphone/Line Out 3. Ethernet 11. DP In 4. USB (2.0) 12. DP Out 5. USB (2.0) 13. HDMI1 In 6. HDMI2 In 14.
Page 9: Control Buttons On The Display
Rear Side (2) 1. SPDIF Optical Out 2. Audio In 3. RJ12 (for sensor) 4. RJ12 (service use only) Control Buttons on the Display To turn on the Display: Press the centre of the joystick in and hold it down for a few seconds, the Display will turn on.
Page 10: Connecting The Ir Receiver
Connecting the IR Receiver Before plugging the Display into the mains supply, connect the supplied IR receiver to the IR input on the Display. Place the IR receiver in sight of your own remote control. Simply operate your remote control whilst pointed at the IR receiver and it will relay the control signal to your Display.
Page 11: Remote Control
16. Play: Starts to play selected media Remote Control 17. Stop: Stops the media being played 18. Rapid advance: Moves frames forward in media such as movies 19. No function 20. Info: Displays information about on-screen content 21. No function 22.
Page 12: First Time Installation
sub-menu options of the highlighted menu press OK First Time Installation button. When you highlight a menu option some of the sub-menu items of this menu may appear on the When turned on for the first time, the language upper side of the menu bar for quick access. To use selection screen will be displayed.
Page 13: Vsign Lite
Select All: Selects all files. Vsign Lite Delete All: Clears all selected options. Vsign Lite is a signage application runs without CMS Play All: Plays selected files in order of selection. and managed through Display. Display software is Send All: Sends selected files to USB. integrated with it.
Page 14: Media Playback Via Usb Input
2.3.1. Creation of the Templates It is recommended to use the Display’s USB input/s directly, if you are going to connect a USB hard disk. Scroll to one of the previously defined templates Note: When viewing image files the Media Browser menu and press OK.
Page 15: Cec And Cec Rc Passthrough
directory of the removable device, Media Browser the screen and the Display will turn itself off after a will play the Photos in a sequence (in file name order) period of 5 minutes. instead of Video or Audio files. If not, it will be checked Note: The setting of the USB Auto Play option in the for Video content and as last Audio.
Page 16 • Open this file with a text editor software such as Notepad. • Write the desired URL (for example, www.starturl. com) in the file and save changes. • Connect the USB strorage device to the Display. Highlight USB Operations option in the Settings>Signage>USB menu and press OK.
Page 17: Settings Menu Content
Settings Menu Content Picture Menu Content You can change the picture mode to suit your preference or requirements. Picture mode can Mode be set to one of these options: Text, Game, Sports, Signage and Natural. Contrast Adjusts the light and dark values on the screen. Brightness Adjusts the brightness values on the screen.
Page 18 Press OK to open the Audio Link menu screen. Using this screen you can discover Audio Link (Optional) and connect the sound devices to your Display wirelessly. Sets the sound to obtain fixed output level between sources. If the Dolby Audio menu item is set to an option other than Off the AVL setting options will change.
Page 19 Controls Sets the OSD (On Screen Display) rotation of your Display. Landscape, Portrait 1 OSD Orientation and Portrait 2 options are available. Sets the rotation of the browser. Landscape, Portrait1 and Portrait2 options are available. One of the portrait options will be set by default depending on the model. Browser This option will rotate the browser only and the changes will be applied after the Orientation...
Page 20 Select ASCII/HEX protocol for UART 1. Default value is HEX. There is no need to restart the Display after selection in order to work with the protocols correctly. If the selection is changed, the latest selected protocol will be preserved and started when the Display is booted up.
Page 21 Clone to USB Copies the database files from the unit to a connected USB device. Clone from USB Copies the database files from a connected USB device to the unit. Copy app cache Copies app cache data from a connected USB device to the unit. from USB Note: This feature may not be available depending on the model of your unit.
Page 22 Press OK to open the OPS Settings menu screen. Three sub-menu options are available. OPS Information: Displays read-only information about the OPS unit, if supported. OPS Status: Displays whether the OPS module is on or off. Allows the change of status via soft PSON signal (0.5s) Boot Signal: Enables or disables sending of a PSON signal.
Page 23 System Menu Content Language Sets the OSD menu language preference. Date/Time Sets date and time. Enables or disables selected source options. There will be Regular, Enhanced and Disabled options available for HDMI sources, if your Display supports Ultra HD. Regular and Enhanced options are affecting the colour settings of the selected HDMI source.
Page 24: Connectivity
the current IP and MAC addresses, if a connection is Connectivity established. Wireless Access Point (Optional) To configure wired or wireless settings you should If the network type is set as Wired Device access point access the Network menu in the Settings menu. feature will be available.
Page 25 Connecting to your mobile device via WLAN other WLAN 11b appliances. The standard values of the transmission speed are the theoretical maximum • If available, you can download a virtual remote values for the wireless standards. They are not the controller application from the server of your mobile actual speeds of data transmission.
Page 26: Apps
• Set the device to pairing mode Connectivity Troubleshooting • Start device discovery on the Display Wireless Network Not Available Note: Refer to the user manual of the wireless device to learn how to set the device to pairing mode. •...
Page 27: Internet Browser
In order to open the Start url that is defined the in and press the OK button to start a search for the Settings>Signage>Link Options menu highlight the related websites. Custom App option and press OK. Highlight a Speed Dial thumbnail and press the OK Notes: button to visit the related website.
Page 28: Hdmi Out
the signal is stable and there is no cable loss, there will be no Controlling With An External PC limitation in case the source content is not HDCP-encrypted. When using cascade-connected Displays, it is recommended to set the DP Stream Setting as SST on all Displays in SST operation mode.
Page 29 and utility. A suitable utility can be used such as described below. Secure Commands This feature is controlled by the Secure Command Another example; profile option. If option is enabled, all commands will Volume level can be changed by using “VOLUME” be registered as secure.
Page 30: Rs232/Lan Command Tables
RS232/LAN Command Tables AUDIO COMMANDS Command Description Parameter Return VOLUME Set volume level. integer n (0 ≤ n ≤ 100) #*set volume to n GETVOLUME Volume level information. no parameter #*volume level is ... #*set headphone volume to n Set headphone volume HEADPHONEVOLUME integer n (0 ≤...
Page 31 #*DAP (Dolby Audio Processing Availability) is inactive Get DAP (Dolby Audio #*DAP (Dolby Audio Processing GETDAPAVL no parameter Processing) AVL state. Availability) Mode is off #*DAP (Dolby Audio Processing) state is ... SETDYNAMICBASS Set dynamic bass state. integer n (0 = off, 1 = on) #*set dynamic bass state to n #*the dynamic bass state is ...
Page 32 #*volume LEVEL is decreased to .. Decrease Volume Level VOLUMEDOWN no parameter by 1 step #*Volume level is at min value. You can not decrease volume level further #*Fixed Volume is set to ... #*Fixed volume availability is set to ... #*Headphone volume control availability is set to ...
Page 33 Sets the browser settings string #*Setting URL is set SETSETTINGSURL (URL set by the command is openned with long press on CMS key) Gets the browser settings no parameter #*Setting URL is ... GETSETTINGSURL Sets the start URL string #*Start URL is set SETSTARTURL Gets the start URL no parameter...
Page 34 GENERAL DISPLAY COMMANDS Command Description Parameter Return Turns the led on/off. Led is ON (Used for setting the led integer n (0 = off, 1 = on) statu of current state) Led is OFF Get led on/off state. #*LED is on GETLED (Used for getting the led no parameter...
Page 35 Load factory settings to NVRAM. #*Factory Settings were loaded to FACTORY Settings are updated with no parameter NVRAM. defaults. Clears flash. string-integer n (n = 0, n = 1, Send key.., n = up, .., n = menu, n key sent ..ext.) Reset process was successfully RESET...
Page 36 VIDOFF Select video off. no parameter Video off. VIDON Select video on. no parameter Video on. #*video is on GETVIDSTATE Get video state. no parameter #*video is off Display the current date TIME no parameter Time = ... and time. #*set time mode to n SETTIMEMODE Set time mode...
Page 37 integer n (0 = digital_ #*no services of selected type network_type_terrestrial, 1 = available BROADCAST Set broadcast type. digital_network_type_cable, 2 = digital_network_type_ #*Set broadcast ... satellite) string-integer n (picture, MAINMENUITEM Select main menu item. sound, settings, installation, #*selectMainMenuItem() set to n channellist, mediabrowser) SHOWBUILDOPTIONS Show build options.
Page 38 integer n (0,14 = TV, 1,15 = SCART1 (CVBS), 3 = SCART2 (CVBS), 5 = FAV, 6 = S-Video, 7 = HDMI1, 8 = HDMI2, 9 = HDMI3, 10 = HDMI4, 11 = YPbPr, 12 = Pc, 13 = SCART2 (S-VIDEO), 16 = Select source.
Page 39 #*tv_portal_status:0 #*Portal status 0 is sent to listening socket(if open) Gets tv is portal mode GETPORTALMODE no parameter or not. #*tv_portal_status:1 #*Portal status 1 is sent to listening socket(if open) #*Time is set succesfully. Sets front panel clock SETFRONTPANEL- string-integer n( 10:00, time( values : 10:00 , #*Given time parameter is wrong! CLOCK...
Page 40 #*TV will be sent to Active Standby state! Enter active standby ENTERACTIVESTANDBY no parameter state #*TV is in Active Standby state already! #* TV is not in Active Standby EXITACTIVESTANDBY Exit active standby state no parameter state! #*Wake on Lan is set to enable. integer n ( n = 1 (enable), n = SWOL Set Wake on Lan option...
Page 41 #*Error! Security Type can not be changed when Access Point is active #*Error! Security type parameter sets the security type of string n (‘none’ or ‘WPA2- should be given SETWIFIAPSECURITY- access point. The value PSK’ note: string is case TYPE should be "none"...
Page 42 Clone from FTP server #* Invalid parameter string "<ip-of-ftp-server/ Before this process, path>" please check network #* "file_name" is cloned NETCLONE configuration (If a static successfully ftp://user_name:password@ ip address is set, it will ip_addr/source_path also be cloned) #* "file_name" clone is failed #*Network type is set to: <network- type>...
Page 43 Speed test is started. INTERNETSPEED start internet speed test no parameter Prints "No internet connection found" message if fails. GETINTERNETSPEED get internet speed no parameter #*The internet speed is ... Mbps #*SUCCESS Hostname ABC is Creates the file (if does written into the file not exist) "/conf/ip_tuner/ SETHOSTNAME...
Page 44 #*The horizontal position is ... GETHPOS Get horizontal position. no parameter #*GETHPOS is available only for VGA Source. #*set vertical position to ... #*invalid value entered VPOS Set vertical position. int n (-25 ≤ n ≤ 25) #*VPOS is available only for VGA Source.
Page 45 PICTURE COMMANDS Command Description Parameter Return #*Video is frozen FREEZE Freeze/Unfreeze no parameter #*Video is unfrozen Set energy saving #*setEnergySaving() set to n Set energy saving mode. (if ENERGYSAVING mode. (if enabled from enabled from profile) profile) #*Wrong parameter entered Get energy saving GETENERGYSAVING mode.
Page 46 #*Picture brightness value is set to n Set picture brightness #*Same value is set. Do nothing. SETBRIGHTNESS int n (0 ≤ n ≤ 100) value. #*Incorrect parameter entered! Value must be in the range 0-100 Get picture sharpness GETSHARPNESS no parameter #*THE SHARPNESS VALUE : ...
Page 47 #*Colour shift is set to n #* Same value is set. Do nothing. SETCOLOURSHIFT Set colour shift. int n (-50 <= n <= 50) #*Incorrect parameter entered ! Value must between defined ranges GETCOLOURSHIFT Get colour shift. no parameter #*Colour shift is ... #*NoiseReduction set to n str-int n (n = OFF, n = LOW, SETNOISEREDUCTION...
Page 48 #*ADC Auto Calibration completed R_Gain= ... G_Gain= ... Start ADC auto int n (0 = SCART-RGB, 1 = ADCCAL B_Gain= ... calibration. YPbPr, 2 = PC/VGA) R_Offset= ... G_Offset= ... B_Offset= ... Set 3D mode values #*set3DMode() set to n (values are off, auto, int n (n = off, auto, side by SET3DMODE...
Page 49 PRINTSWPROFILE Prints sw profile values. no parameter PRINTDEVPROFILE Prints dev profile values. no parameter VIDEO WALL COMMANDS Command Description Parameter Return SETROWCOUNT Set row count. integer n (0 ≤ n ≤ 100) #*set row count to n GETROWCOUNT Get row count. no parameter #*row count is ...
Page 50 #*Video Wall is ON or OFF GETVIDEOWALL- Get video wall enable no parameter ENABLED value #*Video wall is disabled in profile MEDIA BROWSER COMMANDS Command Description Parameter Return set view style (Flat or #*The view style is set to ... (Flat SETVIEWSTYLE string n (Flat, Folder) Folder)
Page 51 FTP server user =... FTP server password =... string string (ip_addr user- password) #Set FTP Props operation SFTP Set FTP Properties (ex: 10.0.0.251 vestel- SUCCESSED vest123) Update software (SW Auto Upgrade should #Web Software Update search no parameter be enabled - see WAU...
Page 52 STWA Stop wake up alarm no parameter #WakeupAlarm stopped !!! string-string (alarm url - emergency message) Send emergency alarm #Emergency Alarm is set !!! [message content should be "word1+ word2+word3 ..."] STEA Stop emergency alarm none #Emergency Alarm is stopped !!! string-int (message text - 0) Send Message [message content should be...
Page 53 #SetMacAdress Succesfull #*FAILURE - Wrong parameter value! string-int ( ex: eth0- Set mac address #*FAILURE - Invalid parameter! 00:09:df:86:34:25) #*FAILURE - Invalid mac address! #*FAILURE - Could not write MAC address! #*Hwaddr: mac_address - get_mac_address Get mac address none Succesfull Set static IP, Default Gateway and string ( ex: 192.168.0.15-...
Page 54 string n ( on time_off time_ source in format: hh:mm_ hh:mm_source ) ------------------------------------ new command is available with Ronesans_B2B r232185 - Raphael V7.36.0.0: "SETSCHEDULEOP number_enabled_ontime_ offenabled_offtime_days_ source" set scheduler #*Schedule parameters are ... (set/ SETSCHEDULEOP (SETSCHEDULEOP parameters not set). 4_1_08:00_1_22:00_ 0111110_HDMI) Available source names: LastSource...
Page 55 Sets signage id automatically. For usage the AUTOSETSIGNAGEID feature the no parameter #*AdvancedVideoWall profile item AdvancedVideoWall is disabled. profile item should be enable. #*FAILURE, wait to check C2 availability (process still not finished) Returns the handshake result #*FAILURE, C2 is not READY C2CONNECTION no parameter between G6F and C2...
Page 56 #*Video Wall is ON or OFF GETVIDEOWALL- Get video wall enable no parameter ENABLED value #*Video wall is disabled in profile MEDIA BROWSER COMMANDS Command Description Parameter Return set view style (Flat or #*The view style is set to ... (Flat SETVIEWSTYLE string n (Flat, Folder) Folder)
Page 57 FTP server user =... FTP server password =... string string (ip_addr user- password) #Set FTP Props operation SFTP Set FTP Properties (ex: 10.0.0.251 vestel- SUCCESSED vest123) Update software (SW Auto Upgrade should #Web Software Update search no parameter be enabled - see WAU...
Page 58 #*FAILURE, lacking parameter! #*FAILURE, parameter exceeds the limit! string (red_green_blue_ #*FAILURE, no parameter after '_' LED Bar Color drive white) (color level value as character! string) #*FAILURE, all colors are not processed #*SUCCESS Sends message C2MSG to UART2 (C2 string #*SUCCESS, Message Send: %s connection) #*FAILURE, lacking parameter!
Page 59: Rs232 Hex Commands
RS232 HEX Commands Protocol Test Steps • Before testing, please know the board type you have. There are two types of board. The UART 0 and UART 1 connections of the these boards are explained below: 1. RJ12 is connected to UART 0, DSUB9 is connected to UART 1. Therefore, UART 0 and UART 1 could be tested separately in this type of the board 2.
Page 60 Reply sent by display for Command received by display successful operation Byte Number Header Data Notes Header Data Setting Action Type code Size flag code Name Operation Quick standby should be enabled to be able to turn on tv with this command. XY can be either 00 or 01.
Page 61 Reply sent by display for Command received by display successful operation Byte Number Header Data Notes Header Data Setting Action Type code Size flag code Name Operation XY can be either 00 or 01. 00 means OFF, 01 means ON. INCREMENT DECREMENT range: 0x64-0x1E...
Page 62 INCREMENT DECREMENT INCREMENT DECREMENT INCREMENT DECREMENT EXECUTE Toggles video freeze status. English - 60 -...
Page 63: Maximum Pixel Rates
Maximum Pixel Rates For UHD panels, Source Max. Resolution Colour Space Bits/Component Pixel/Rate HDMI 4K@60Hz YCbCr4:4:4/RGB 8 bit 594MHz 4K@30Hz / OPS (Optional) YCbCr4:4:4/RGB 8 bit 594MHz 4K@60Hz 4K@30Hz YCbCr4:4:4/RGB 8 bit 297MHz Input Matrix Input Dot clock Timing fH (kHz) fV (Hz) (MHz) HDMI...
Page 64: Supported Media Formats From Usb
Supported Media Formats from USB Video File Formats Video Codec Resolution Bit Rate Container MPEG program stream (.DAT, .VOB, .MPG, .MPEG), MPEG MPEG1/2 transport stream (.ts, .trp, .tp), MP4 (.mp4, .mov), 3GPP (.3gpp, .3gp), AVI (.avi), MKV (.mkv), ASF (.asf) MPEG program stream (.MPG, .MPEG), MP4 (.mp4, .mov), 1080Px2@30fps, MPEG4...
Page 65 AAC (.aac), AVI (.avi), Matroska (.mkv, .mka), 3GPP (.3gpp, .3gp), MP4 (.mp4, .mov, m4a), MPEG transport stream (.ts, .trp, AAC, HEAAC 8KHz ~ 48KHz .tp), MPEG program stream (.DAT, .VOB, .MPG, .MPEG), FLV (.flv), RM (.ra) 128bps ~ 8KHz ~ 48KHz 320Kbps WMA 10 Pro M0 48KHz...
Page 66: System Features
Wireless LAN Transmitter Specifications System Features Max Output Panel Frequency Ranges Power Panel type 65” (164cm) 24/7 ELED 2400 - 2483,5 MHz (CH1-CH13) < 100 mW Resolution 3840x2160 UHD 5150 - 5250 MHz (CH36 - CH48) < 200 mW Horizontal 89°...
Page 67: Accessories Included
couraged to try to correct the interference by one of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit Products different from that to which the receiver is connected.
Page 68: Creston Connected
Creston Connected - In order to work with Crestron Connected protocol, “CrestronConnected” profile option should be enabled. - Flash UI which is served by the display device is not supported. Flash UI which is served by the control system can be used. Flash UI will not be directly connected to display device but will be connected indirectly over control system in this case.
Page 69: Vesa Wall Mount Measurements
Vesa Wall Mount Measurements Hole Pattern Sizes (mm) Screw Sizes min. (mm) Length (X) max. (mm) Thread (Y) Installation On An Indented Wall Plane view Side view Minimum 50 mm Minimum 70 mm Minimum 50 mm Minimum 50 mm Ambient temperature range: 0-35ºC When installing the product on an indented wall, allow at least the space specified above between the product and wall for ventilation and ensure that the ambient temperature is kept between 0ºC-35ºC.
Page 70 Safety Warnings Laite on liitettävä suojakoskettimilla varustettuun pistorasiaan. Apparatet må tilkoples jordet stikkontakt. Apparaten skall anslutas till jordat uttag. Equipment connected to the protective earthing of the building installation through the mains connection or through other equipment with a connection to protective earthing – and to a cable distribution system using coaxial cable, may in some circumstances create a fire hazard.
Page 71 TR: İşbu belgede; VESTEL Elektronik Sanayi ve Ticaret A.Ş., Il fabbricante, VESTEL Elektronik Sanayi ve Ticaret A.Ş., telsiz ekipmanı tipi MONITOR’nin 2014/53/AB sayılı direktife dichiara che il tipo di apparecchiatura radio MONITOR è uygun olduğunu beyan eder. AB uygunluk beyanının tam conforme alla direttiva 2014/53/UE.
Page 76 Società Unipersonale Via Polidoro da Caravaggio, 6 20156 Milano (MI) Phone: +39 02 842 48577 Fax: +39 02 842 48617 info@givesit.it www.givesit.it Vestel UK Ltd Vestel House, Waterside Drive Langley, Berkshire SL3 6EZ Phone: 44 3330 146 400 info@vestel-uk.com www.vestel.co.uk 50543635...
