Summary of Contents for Joroto ME15
- Page 3 NOTICE PLEASE NOTICE BELOW SAFETY INSTRUCTION IN ORDER TO AVOID ACCIDENT 1. The device is suitable for home use and is a fitness product for non- medical purposes. 2. Avoid using it in places with high temperature, humidity and water splashes.
- Page 4 18. Please use the product strictly in accordance with the product manual. 19. It is forbidden to use this device with eyes closed. 20. It is best to wear appropriate sports clothes when using this product to exercise, do not wear robes or other clothes to prevent tripping 21.
- Page 5 COMPONENTS 26L/26R Part Number: Description Q’ty Main frame Basement Stabilizer Left pedal Right pedal Stabilizer cover...
-
Page 6: Accessories List
ACCESSORIES LIST Part name Q’ty Drawing Inner hexagon bolt M8*20 Arc washer Φ8*22*1.5 M6*15inner hexagon bolt Cushion Inner hexagon spanner L6 Inner hexagon spanner L5 Before assembling please check whether all needed parts are available (at the below of the instruction you will find an explosion drawing with all single parts (marked with numbers) which this item consists of. -
Page 7: Assembly Steps
ASSEMBLY STEPS 1. As shown in the pic: lock stabilizer(32#) onto main frame(1#) use inner hexagon bolt M8*20(27#) and washer(33#). 2. As shown in the pic: lock basement(2#) under the main frame(1#) use bolt (3#x4) and cushion (45#x4). 3. As shown in the pic: lock the left crank(26L#) on the left pedal on main frame using bolt(27#) + washers(33#x2), lock the right crank(26R#) on the right pedal on main frame use bolt(27#) + washers(33#x2). -
Page 8: Exploded Drawing
EXPLODED DRAWING 24 25 EXPLODED DRAWING AND PART LIST PART NAME Q’TY Main Frame Basement M6*15 Screw Ф10 Circlip for shaft 6000 Bearing Flywheel Magnetic kit M5*15 Bolt M6 Nut M6*30 Threaded Rod Flywheel shaft Chain cover ST5*20 Bolt ST5*15 Bolt Turntable Bracket Turntable... - Page 9 M8 Nylon Nut Bearing 6000 Transportation wheels Pedal tube R/L Decoration cover R/L D shape Washer Ф8*Ф25 Washer Spring Washer M8*20 Outer hexagon Bolt Pedals R/L M8*20Inner hexagon Bol Big Washer Decoration Cover Flange nut Front stabilizer tube plug R/L Front Stabilizer Ф8*Ф20 Washer M6 Nylon Nut...
- Page 10 INSTRUCTION OF METER Function: Press the function key to select time, times, total times and calories. When pressed for more than 4 seconds, the meter will be reset, and all data except the total number of times will be cleared. Scanning: Press the "MODE"...
-
Page 11: Exercise Instruction
EXERCISE INSTRUCTION Using this equipment provides you with several benefits, it will improve your physical fitness, strong muscle, in conjunction with calorie controlled diet help you lose weight. 1 Warm-up Period This stage helps get the blood flowing around the body and the muscles working properly. - Page 12 2 The Exercise Phase This is the stage where you put the effort in. After regular use , your leg muscles will become flexible. Sports coordination is very important to you, maintain a steady tempo throughout. The rate of exercise should be sufficient to raise your heart beat into the target zone shown on the graph below.
- Page 13 Lion Health Technology (Beijing) Co., Ltd. Add: Room 2-4, Building No.26, Xiju North Street, West Third Ring South Road, Fengtai District, Beijing PRC Email: support@jorotofitness.com https://jorotofitness.com...
