4. Antenna Mounting
4.1 Connect the antenna cables according the port layout (Figure 1)
4.2 Tighten the SMA connectors | Drive type: Hex 8mm | Torque: 0.35 - 0.6 Nm (Figure 2)
D
4.3 Recommended torque wrench for SMA brass connectors (Figure 3)
Figure 1
C
B
Figure 2
A
Figure 3
Torque Wrench: 74Z0079-NIST HUBER+SUHNER
