Storage Desk
Bureau avec rangement
Dear Customer,
DO NOT RETURN THIS PRODUCT TO YOUR RETAILER.
If
you
experience any problems during assembly, please contact Star customer service at 1-800-311-5611. Or email to
help@starquality.ca
All parts should be identified and matched up against the parts list. It is advisable to assemble on carpet to avoid scratches.
Cleaning Instructions:
Use a soft cloth with mild cleaning solution. Never use anything abrasive or any harsh chemicals.
Cher Client,
NE PAS RETOURNER CE PRODUIT À VOTRE DÉTAILLANT.
Si vous avez des problèmes lors de l'assemblage, s'il vous plaît veuillez
800-311-5611. Ou par courrier électronique à help@starquality.ca
Vous devez pouvoir identifier toutes les pièces et les assortir à la liste des pièces. Il est conseillé de faire le montage sur un tapis pour
éviter les éraflures.
Instructions de nettoyage:
Utilisez un chiffon doux avec un détergent doux. N'utilisez jamais d'abrasif ni de produits chimiques corrosifs.
Attention : Do not tighten the screws before all screws are in place.
Attention : Ne pas serrer les vis avant que toutes les vis sont en place.
contacter le service à la clientèle
KB 12-4824
AI KB12-4824 201409 V1 ls
Star au 1-
