Useage
This Gas-leak detector is a very sensitive, self-sufficient warning system. The device
consists of a gas sensor, an acoustic signal generator, a visual status-display and a power
supply.
The device responds to the following types of gas: natural gas and propane. The device
serves to recognize gas leaking from small liquefied-gas containers, such as camping-gas
cartridges, gas lighters, gas soldering torches, etc.
The device is not suitable for continuous operation, but only for short-time operation (note
lifetime of battery).
The device is to be considered as an aid only and must only be used for small gas
containers, such as lighters, camping-gas containers etc.. If there is reason to
believe that gas is leaking, especially in case of complex gas systems, such as
heaters or ovens, you should not carry out the measurement yourself, but contact
an expert. The device is not suitable for those types of measurements. Do not put
yourself at risk. In case of leaking gas, leave everything else, especially the repair,
to an expert who is familiar with the relevant dangers and regulations.
The device is not designed for industrial use.
Also note all other safety instructions contained in this operating manual.
Safety and danger instructions
An exclamation mark placed in the center of a triangle refers to important
advice contained in the operating manual. Please read the complete
operating manual before commissioning the product, since it contains
important information on the proper operation of the device.
We accept no responsibility for property damage or personal injuries caused by
improper use or non-observance of safety instructions! Furthermore, in all such
cases guarantees become invalid.
Do not attempt to disassemble the device, there are no user serviceable components
inside.
GAS LEAK DETECTOR
TEN01068
Advertisement
Table of Contents
Summary of Contents for Tenma TEN01068
- Page 1 GAS LEAK DETECTOR TEN01068 Useage This Gas-leak detector is a very sensitive, self-sufficient warning system. The device consists of a gas sensor, an acoustic signal generator, a visual status-display and a power supply. The device responds to the following types of gas: natural gas and propane. The device serves to recognize gas leaking from small liquefied-gas containers, such as camping-gas cartridges, gas lighters, gas soldering torches, etc.
- Page 2 Make sure that the products is commissioned properly. Adhere to the instructions in this operating manual. Never pour liquids over the gas-leak detector. This may damage the device. If this occurs accidentally remove the batteries immediately. Do not expose the device to high temperatures, dampness or strong vibrations, nor to high humidity.
- Page 3 Carrier sling The carrier sling is intended to prevent accidental slipping of the gas-leak detector. Fasten the carrier loop to the respective fastening eyelets at the end of the detector. Cover The cover portents the sensitive gas sensor from damage. Remove the cover before operation and replace it when you have finished operating the detector.
- Page 4 Commissioning and operation To ensure proper commissioning it is absolutely necessary that you read this operating manual, including the safety instructions, completely and carefully! Remove the cover (7) Switch on the gas-leak detector by sliding the ON/OFF button (5) to the position “ON”. ...
- Page 5 The STATIC test should always be carried out before a gas-detection operation. If there are strong charges, a gas-detection operation should not be carried out, since the static charge is renewed when a person moves around and new sparks may be created during the gas-detection operation.
- Page 6 Technical data Operating voltage 3VDC (2x micro batteries, alkaline) Power consumption approx.200mA Types of gas to which the device responds: Propane and natural gas (for the most part a mixture of hydrocarbons, natural gas, normally consisting of 80-95% methane+ various other gases, such as carbon dioxide, carbon monoxide and helium) Sensitivity: Propane...
