AFR Series Atlas Furniture Racks
Product Features
•
Slim profile optimized for mounting in cabinets
•
Includes four lacer bars.
Available Options
•
AFR16RK: Runner kit for 16" deep AFR
•
AFR18RK: Runner kit for 18" deep AFR
•
8RU – 16RU 16" deep
•
8RU – 16RU 18" deep
CAUTION: Place heavier components at the bottom of the enclosure to ensure rack stability. When more than one component is placed in the
enclosure, begin at the bottom of the enclosure and place equipment at the lowest available point, evenly distribute weight (horizontally) within the
enclosure.
Component weight should be distributed as follows:
•
/
of the total component weight (at a minimum) placed in the bottom third of the cabinet
1
2
•
/
of the total component weight (at a maximum) placed in the middle third of the cabinet
1
4
•
/
of the total component weight (at a maximum) placed in the top third of the cabinet
1
4
CAUTION: All installation and assembly steps must be performed by qualified personnel.
CAUTION: Ensure that the floor has a structural load capacity that will support the weight of the cabinet fully loaded with equipment.
CAUTION: Some parts of the enclosure system, such as the lacer bars, may not be effectively bonded to the Protective Earth Terminal (PET). If these
parts need to be bonded to the PET it should be done in accordance with Article 250 of the National Electrical Code.
CAUTION: Power cord(s), for fans or other accessories, need to be secured to ensure that they are routed away from pinch points and moving parts.
CAUTION: Do not attempt to unload or move the enclosures alone. Make sure to have sufficient amount of personnel and equipment to safely move
this product.
