Summary of Contents for Monet DESAUW FWA500

Page 1 ONET  INCORPORATED 877.642.4900...
Page 5: Table Of Contents
ABLE OF ONTENTS Table of Contents…………………………………………………………………………1 FWA-500 Introduction……………………………………………………………………2 Overview………………………………………………………………………………….3 Caution……………………………………………………………………………………4 Caution – Maintenance……………………………………………………………………5 Always Work Safely………………………………………………………………………6 General Warnings…………………………………………………………………………7 Safety Decals………………………………………………………………...……………8 Safety Decals……………………………………………………………………….……..9 Automatic Safety Devices………………………………………………………………..10 Air Brake System…………………………………….…………………………………..11 Inspecting Air Brakes……………………………………………………………………12 Inspecting Air Brakes……………………………………………………………………13 Air Brake Adjustment……………………………………………………………………14 Brake Pad Replacement………………………………………………………………….15 Manual Safety Devices…………………………………………………………………..16 Pre-Start Checklist……………………………………………………………………….17 Pinch Points and E-Stops……...…………………………………………………………18...
Page 6 The Fastest, Safest, Easiest Way to Cut Floor Truss Webs DeSauw ® ONET 3100 D OGWOOD RIVE , MO 65251-7226 ULTON DeSauw ® Component Saws are manufactured by Monet DeSauw ® , Inc., Fulton, MO 65251 877-642-4900 DDITIONAL NFORMATION LEASE CALL ©2001 M ONET...
Page 7 Increase Your Profit Margin… The DeSauw ® FWA 500 combines efficient setup features with high feed rates, which make it the industry’s most reliable, and most productive floor web saw. Consistently Accurate Components at Lower Labor Costs! Electronic digital readouts for setting saw blade angulations, magazine feed, and external cut- off blade have always made the FWA 500 the #1 CHOICE for cutting large volumes of floor webs.
Page 8: Caution
CAUTION! This product requires extreme caution at all times. DeSauw component saws are designed to safely produce the proper cuts on truss members. Safety devices are installed at the factory and should not be removed for any reason. The DeSauw operates on 3-phase, 480-volt electricity. All external electrical panels and controls are protected, but access to inner workings should be restricted to authorized personnel only.
Page 9 IN ORDER TO HAVE AN EFFECTIVE BRAKE SYSTEM, REPAIR ANY LEAKS IMMEDIATELY! DO NOT ADJUST REGULATOR OR PRESSURE SWITCHES WITHOUT FIRST NOTIFYING MONET DESAUW TECHNICIANS. SERVICE HOTLINE: 1-877-642-4900...
Page 10: Always Work Safely
The machine is designed and produced exclusively for cutting truss components. All other use will be considered to be contrary to the use specified by MONET DESAUW, who cannot be held liable for damage to property or the machine, or for personal injuries which may result.
Page 11: Safety Decals
Read this manual carefully before starting, using, carrying out maintenance or performing any other type of operation on the saw. The time spent reading this manual will allow you to get to know your saw, thereby saving time and effort. This will also help prevent accidents from taking place. Read all the safety decals on the machine and follow the instructions thereon before starting, operating, or carrying out maintenance on the machine.
Page 12 Moveable End Electrical Cabinet Operator’s Side Catcher’s Side...
Page 13 Blade #3 Guard...
Page 14: Automatic Safety Devices
(if drive is OK the display should read “Rdy”). When fault code is determined, user should contact Monet DeSauw technician for assistance. DO NOT attempt to change parameters in drive without consulting a qualified technician.
Page 15: Air Brake System
ACCESS TO MAIN ELECTRICAL PANELS SHOULD BE LIMITED ONLY TO QUALIFIED WARNING PERSONNEL. THE VOLTAGE WITHIN SHOULD BE CONSIDERED LETHAL AND CAN CAUSE SERIOUS DAMAGE. Air-Brake System The DeSauws use a pneumatic braking system to stop the spinning of saw blades.
Page 20: Manual Safety Devices
Manual Safety Devices Emergency Stop Buttons The FWA-500 is equipped with a momentary stop button located on fixed end Panel. When activated, these buttons will stop the entire system of motors and activate the air brake system to halt spinning of saw blade #3.
Page 21: Pre-Start Checklist
Pre-Start Checklist In order to ensure the safety of the operator and operation of the saw, it is necessary to proceed through the following pre-check inspection procedure. Make sure the safety disconnects on the fixed end is in the “Off” position.
Page 22 4. Check all electrical leads for loose wires. Follow local electrical code procedures. CAUTION: ONLY AUTHORIZED PERSONELL SHOULD BE ALLOWED ACCESS TO THE ELECTRICAL PANELS, THE CONTENTS CONTAIN HARMFUL AND POTENTIALLY LETHAL VOLTAGE. POWER SHOULD BE SHUT OFF BEFORE ANY ELECTRICAL MAINTENANCE IS PERFORMED Mushroom E-stop Cutoff blade guard...
Page 23: Installation
Installation 1. Set the saw in place, hook up power in the fixed end cabinet (wire can enter the cabinet either in the top or bottom)  480-volt, 3 phase, 60 hertz, 60-amp wye connection  DO NOT USE CONDUIT FOR A GROUND 2.
Page 24 1/16”  If draft is needed or there is too much, adjust the pivot of the blade to have the desired 1/16”. Consult with Monet Desauw if you are unsure how to do this step.
Page 25: Calibration
It might be necessary to use a marker to draw the direction. Put a square along the 3-1/2” dimension and note how square it is.  Consult a technician at Monet Desauw Inc if the saw is out of adjustment. Saw Calibration...
Page 26 Using a framing square, measure from the bottom of the board to the BOTTOM of the cut. The measurement should be ¾”. If it is not, raise or lower the blade until it is ¾”. Recut the board until you achieve this measurement. The moveable end should look like this: Using a framing square, measure from the bottom of the board to the TOP of the cut.
Page 27 If the intersecting cuts are not in the center of the board, only adjust the front two blades, blades 2 and 4, in or out until ¾” is found. DO NOT adjust the back blades as they are already set. The FWA 500 Design: Due to the versatility of the FWA 500, each of its Saw Blade Motor Slides can be positioned for each of these 3 different types of web cuts.
Page 28: Square End Blocks
Setting the Angle of the Cut o Since Floor webs consist of 2 angles on each web end, which are 90 degrees from each other, the internal blades on each end are permanently mounted at 90 degrees from each other. o Both blades at each end will move together when angle changes are made.
Page 29: Two Piece Webs
Crank front motor slide plates away from hinged bolt stops and flip stop over on anchor plate away from motor slide plate. Crank slide plate in until crank pinion is against anchor plate. When this is done make sure the front 2 blades are not touching metal. Rear Blades: Crank 2 rear blades away from bolt stops far enough to keep the teeth from touching the webs.
Page 30 The FWA 500 has a ruled scale mounted on the front, left side of the frame. There are 2 red pointers positioned over the frame scale with a calibrated location for making square end blocks, and two & four angle webs respectively. Positioning the carriage for a desired web length is as easy as aligning the respective pointer with the frame scale.
Page 31: Maintenance Schedule
MAINTENANCE SCHEDULE - SERVICE SCHEDULE...
Page 32 FREQUENCY WHAT TO DO WITH WHAT  Blow off entire machine to remove sawdust, Low Pressure shop air (30 psi). DAILY especially on quadrants, chains, and Clean at beginning of shift with sprockets. kerosene/transmission mix –  Inspect for missing or broken guards or quadrants and slides only safety devices.
Page 33 Electrical Symptom Possible Cause Remedy Nothing Works (1) Disconnect switched to OFF. (1) Visual Check (2) Power Supply to saw OFF. (2) Visual Check (3) Line fuse blown. (3) Replace (4) Safety feature activated (4) Check: E-Stop Buttons Cable Pull Switch Bump Bar Air supply to saw Saw motors/Waste...
Page 34 Mechanical Symptom Possible Cause Remedy Quadrant Head will not (1) Electrical Fault (1) Refer to Electrical operate. troubleshooting. (2) Gear motor not (2) Replace. functioning. (3) Obstruction in driving (3) Clean and Lubricate. chain or slide/casting assembly. (4) Gearbox stripped or (4) Replace.
Page 35 Vibrating Conveyor Symptom Possible Cause Remedy Breaking of Fiberglass (1) Loose bolts. (1) Tighten. leaves (2) Excessive weight or (2) Prevent. stepping on top pan. (3) Accumulation of scrap (3) Clean area. in system. Excessive Noise (1) Loose mounts (1) Tighten. (2) Loose connecting rod (2) Tighten.
Page 43 Monet Desauw, Inc. FWA-500 Maintenance...
Page 44 Angle Encoder Rack Adjustment •Loosen Allen head Bolts •Adjust the gear rack to make sure the gear is on the rack between 0 and 45 degrees •Rotate the gear rack so that the gear is engaged at 0 degrees •Tighten up the Allen head bolts Be sure to follow all Lock out/ Tag out procedures before attempting any WARNING...
Page 45 Angle Encoder Rack Adjustment...
Page 46 Angle Encoder Adjustment •Loosen Allen head bolts on encoder mount •Adjust mount until gear meshes in rack •After proper lash tighten the Allen head bolts and rotate arm using the push buttons insuring there is a constant mesh Be sure to follow all Lock out/ Tag out procedures before attempting any WARNING maintenance to the machine.
Page 47 Angle Encoder Adjustment...
Page 48 Setting The Angle Digital Readout (Scale Factor)
Page 49 Angle Encoder D.R.O. Adjustment...
Page 50 Chain Tension •In-feed Conveyor Chain Loosen up the top and bottom three bolts. Adjust screw to maintain chain tension. You should be able to pick up the conveyor chain two inches in the center of the conveyor. •Upper Hold-down Chain- Loosen two Allen head bolts.
Page 51 Lower Conveyor Chain Adjustment Video...
Page 52 Upper Hold Down Chain Tension...
Page 53 Lumber Conveyor Timing •Loosen up the four bolts on the moveable end off-fall side of the machine •Phase forwards or backwards to get the two flights lined up •Adjusting Chain- •Take a marker and make a line on the sleeve and the sprocket.
Page 54 Lower Feed Conveyor Timing...
Page 55 Carriage Chain Tension •Loosen the two jam nuts •To tighten chain you need to draw the outer nut against the mount •The chain needs to sag one inch for the proper tension Be sure to follow all Lock out/ Tag out procedures before attempting any WARNING maintenance to the machine.
Page 56 Carriage Chain Adjustment...
Page 57 Guide Bearings Locating Bearings •1 ¾ inch bearings that roll along the frame to keep the carriage parallel to the fixed end •There are two bearings on the outside and two bearings on the inside Parallelism •Using a tape measure, measure in between the conveyors on both ends of the machine •The two need to be within 1/16 of an inch of each others distance •If they are not parallel you must adjust the guide bearings Adjusting Bearings...
Page 58 Adjust Guide Bearings Video...
Page 59 Center Line Adjustment • Attach the two centerline jigs to the brackets located where the board enters the saw. • With the string tight, the blades should be touching the string on the leading edge of the blade and no more than a 1/16 on the rear edge of the blade.
Page 60 Center Line Adjustment Video...
Page 61 Electrical Cabinet Components •Variable Speed Frequency Drive •Control Relays •Transformer for 110 •Fuses and Fuse Blocks •Motor Starters- control 5hp motors and waste disposal •The Disconnect...
Page 62 Electrical Cabinet Components •Variable Speed Frequency Drive...
Page 63 Electrical Cabinet Components •Control Relays...
Page 64 Electrical Cabinet Components •Transformer for 110...
Page 65 Electrical Cabinet Components •Fuses and Fuse Blocks...
Page 66 Electrical Cabinet Components •Motor Starters...
Page 67 Electrical Cabinet Components •Lock Out/ Tag Out Disconnect...
Page 68 Monet DeSauw Inc. ‘ The Most Reliable!’ Contact Us: Monet DeSauw, Inc. 3100 Dogwood Drive Fulton, MO 65251 United States Call 1-877-642-4900 Check us out on the web at: www.desauw.com Email Us at contact@desauw.net...
