MBRP500TP2
ITEM NUMBER(S): BRP500TP2, BRP520TP3, BRP650HP2
MANUAL SERIAL TAG HERE
Owner's Manual
Brave Water Pump
WARNING
Read and understand all instructions.
Failure to follow all instructions may result in serious injury or property damage.
WARNING: Wear appropriate protective gear. This list includes, but is not limited to:
-safety glasses, protective boots with slip resistant soles, gloves, hearing protection.
• WARNING: Keep guards in place and in working order. Never operate the product without the guards in place.
• WARNING: LETHAL EXHAUST GAS! An internal combustion engine discharges carbon monoxide, which is a
poisonous and odorless invisible gas. Death or serious illness may result if inhaled. Operate only in an area with
good ventilation.
• DANGER: Do not smoke when refueling.
• WARNING: Do not use pump in explosive atmosphere.
• WARNING: Do not pump volatile or flammable liquids such as gasoline, fuel oil, kerosene, etc.
• CAUTION: Do not attempt to operate pump, if any parts are missing or damaged.
• CAUTION: For proper handling techniques and cautions when pumping certain chemicals, contact your chemical
supplier or local agencies (fire dept etc)
• CAUTION: The engine is hot enough to cause injury, do not touch the exterior of the engine, especially the muffler
and surrounding area.
• WARNING: Even though this unit will operate with minimal supervision, it should not be left operating by itself.
Depending on the application and area unit is operating (high traffic, people in area, etc.) will dictate the necessity
of having someone watching over the unit.
• CAUTION: Do not allow pump to be located in freezing or colder weather. Damage to pump will result.
• CAUTION: Do not run pump dry, as permanent damage to the mechanical seal will result.
STOP!
ADD OIL TO ENGINE BEFORE USING: Engine is shipped without oil. DO NOT start engine without first adding oil.
INSPECT COMPONENTS: Closely inspect to make sure no components are missing or damaged.
Any Questions, Comments, Problems or Parts Orders
Call Brave Support 1-800-350-8739
